The Relational Data Model

1
The Relational Data Model

• Chapter 4

2
Data and Its Structure

• Data is actually stored as bits, but it is
  difficult to work with data at this level.
• It is convenient to view data at different levels
  of abstraction.
• Schema Description of data at some abstraction
  level. Each level has its own schema.
• We will be concerned with three schemas
  physical, conceptual, and external.

3
Three Schemas in the Relational Data Model
4
Physical Data Level

• Physical schema describes details of how data is
  stored tracks, cylinders, indices etc.
• Early applications worked at this level
  explicitly dealt with details.
• Problem Routines were hard-coded to deal with
  physical representation.
• Changes to data structure difficult to make.
• Application code becomes complex since it must
  deal with details.
• Rapid implementation of new features impossible.

5
Conceptual Data Level

• Hides details.
• In the relational model, the conceptual schema
  presents data as a set of tables.
• DBMS maps from conceptual to physical schema
  automatically.
• Physical schema can be changed without changing
  application
• DBMS would change mapping from conceptual to
  physical transparently
• This property is referred to as physical data
  independence

6
Conceptual Data Level (cont)
Conceptual view of data
Application
Physical view of data
DBMS
7
External Data Level

• In the relational model, the external schema also
  presents data as a set of relations.
• An external schema specifies a view of the data
  in terms of the conceptual level. It is tailored
  to the needs of a particular category of users.
• Portions of stored data should not be seen by
  some users.
• Students should not see their files in full.
• Faculty should not see billing data.
• Information that can be derived from stored data
  might be viewed as if it were stored.
• GPA not stored, but calculated when needed.

8
External Data Level (cont)

• Application is written in terms of an external
  schema.
• A view is computed when accessed (not stored).
• Different external schemas can be provided to
  different categories of users.
• Translation from external to conceptual done
  automatically by DBMS at run time.
• Conceptual schema can be changed without changing
  application
• Mapping from external to conceptual must be
  changed.
• Referred to as conceptual data independence.

9
Data Model

• Set of concepts and language for describing
• Conceptual and external schema (a schema
  description of data at some level (e.g., tables,
  attributes, constraints, domains)
• Data definition language (DDL)
• Integrity constraints, domains (DDL)
• Operations on data
• Data manipulation language (DML)
• Optional Directives that influence the physical
  schema (affects performance, not semantics)
• Storage definition language (SDL)

10
Relational Model

• A particular way of structuring data (using
  relations)
• Simple
• Mathematically based
• Expressions (? queries) can be analyzed by DBMS
• Queries are transformed to equivalent expressions
  automatically (query optimization)
• Optimizers have limits (gt programmer needs to
  know how queries are evaluated and optimized)

11
Relation Instance

• Relation is a set of tuples
• Tuple ordering immaterial
• No duplicates
• Cardinality of relation number of tuples
• All tuples in a relation have the same structure
  constructed from the same set of attributes
• Attributes are named (ordering is immaterial)
• Value of an attribute is drawn from the
  attributes domain
• There is also a special value null (value unknown
  or undefined), which belongs to no domain
• Arity of relation number of attributes

12
Relation Instance (Example)
Id Name Address Status
Student
13
Relation Schema

• Relation name
• Attribute names domains
• Integrity constraints like
• The values of a particular attribute in all
  tuples are unique
• The values of a particular attribute in all
  tuples are greater than 0
• Default values

14
Relational Database

• Finite set of relations
• Each relation consists of a schema and an
  instance
• Database schema set of relation schemas
  constraints among relations (inter-relational
  constraints)
• Database instance set of (corresponding)
  relation instances

15
Database Schema (Example)

• Student (Id INT, Name STRING, Address STRING,

• Status STRING)
• Professor (Id INT, Name STRING, DeptId DEPTS)
• Course (DeptId DEPTS, CrsName STRING,
• CrsCode COURSES)
• Transcript (CrsCode COURSES, StudId INT,
• Grade GRADES, Semester
  SEMESTERS)
• Department(DeptId DEPTS, Name STRING)

16
Integrity Constraints

• Part of schema
• Restriction on state (or of sequence of states)
  of data base
• Enforced by DBMS
• Intra-relational - involve only one relation
• Part of relation schema
• e.g., all Ids are unique
• Inter-relational - involve several relations
• Part of relation schema or database schema

17
Constraint Checking

• Automatically checked by DBMS
• Protects database from errors
• Enforces enterprise rules

18
Kinds of Integrity Constraints

• Static restricts legal states of database
• Syntactic (structural)
• e.g., all values in a column must be unique
• Semantic (involve meaning of attributes)
• e.g., cannot register for more than 18 credits
• Dynamic limitation on sequences of database
  states
• e.g., cannot raise salary by more than 5

19
Key Constraint

• A key constraint is a sequence of attributes
  A1,,An (n1 possible) of a relation schema, S,
  with the following property
• A relation instance s of S satisfies the key
  constraint iff at most one row in s can contain a
  particular set of values, a1,,an, for the
  attributes A1,,An
• Minimality no subset of A1,,An is a key
  constraint
• Key
• Set of attributes mentioned in a key constraint
• e.g., Id in Student,
• e.g., (StudId, CrsCode, Semester) in Transcript
• It is minimal no subset of a key is a key
• (Id, Name) is not a key of Student

20
Key Constraint (contd)

• Superkey - set of attributes containing key
• (Id, Name) is a superkey of Student
• Every relation has a key
• Relation can have several keys
• primary key Id in Student (cant be null)
• candidate key (Name, Address) in Student

21
Foreign Key Constraint

• Referential integrity Item named in one
  relation must refer to tuples that describe that
  item in another
• Transcript (CrsCode) references Course(CrsCode
  )
• Professor(DeptId) references
  Department(DeptId)
• Attribute A1 is a foreign key of R1 referring to
  attribute A2 in R2, if whenever there is a value
  v of A1, there is a tuple of R2 in which A2 has
  value v, and A2 is a key of R2
• This is a special case of referential integrity
  A2 must be a candidate key of R2 (e.g., CrsCode
  is a key of Course in the above)
• If no row exists in R2 gt violation of
  referential integrity
• Not all rows of R2 need to be referenced
  relationship is not symmetric (e.g., some course
  might not be taught)
• Value of a foreign key might not be specified
  (DeptId column of some professor might be null)

22
Foreign Key Constraint (Example)
A2 v3 v5 v1 v6 v2 v7 v4
A1 v1 v2 v3 v4 -- v3
R1
R2
Foreign key
Candidate key
23
Foreign Key (contd)

• Names of A1 and A2 need not be the same.
• With tables
• ProfId attribute of Teaching references Id
  attribute of Professor
• R1 and R2 need not be distinct.
• Employee(IdINT, MgrIdINT, .)
• Employee(MgrId) references Employee(Id)
• Every manager is also an employee and hence has a
  unique row in Employee

Teaching(CrsCode COURSES, Sem SEMESTERS,
ProfId INT) Professor(Id INT, Name STRING,
DeptId DEPTS)
24
Foreign Key (contd)

• Foreign key might consist of several columns
• (CrsCode, Semester) of Transcript references
  (CrsCode, Semester) of Teaching
• R1(A1, An) references R2(B1, Bn)
• There exists a 1 - 1 correspondance between
  A1,An and B1,Bn
• Ai and Bi have same domains (although not
  necessarily the same names)
• B1,,Bn is a candidate key of R2

25
Inclusion Dependency

• Referential integrity constraint that is not a
  foreign key constraint
• Teaching(CrsCode, Semester) references
  Transcript(CrsCode, Semester)
• (no empty classes allowed)
• Target attributes do not form a candidate key in
  Transcript (StudId missing)
• No simple enforcement mechanism for inclusion
  dependencies in SQL (requires assertions -- later)

26
SQL

• Language for describing database schema and
  operations on tables
• Data Definition Language (DDL) sublanguage of
  SQL for describing schema

27
Tables

• SQL entity that corresponds to a relation
• An element of the database schema
• SQL-92 is currently the most supported standard
  but is now superseded by SQL1999
• Database vendors generally deviate from standard,
  but eventually converge

28
Table Declaration
CREATE TABLE Student ( Id INTEGER, Name
CHAR(20), Address CHAR(50), Status
CHAR(10) )

Id
Name
Address
Status
101222333 John 10 Cedar St
Freshman 234567890 Mary 22 Main St
Sophomore
Student
29
Primary/Candidate Keys
CREATE TABLE Course ( CrsCodeCHAR(6),
CrsName CHAR(20), DeptId CHAR(4), Descr
CHAR(100), PRIMARY KEY (CrsCode), UNIQUE
(DeptId, CrsName) -- candidate key )
Things that start with 2 dashes are comments
30
Null

• Problem Not all information might be known when
  row is inserted (e.g., Grade might be missing
  from Transcript)
• A column might not be applicable for a particular
  row (e.g., MaidenName if row describes a male)
• Solution Use place holder null
• Not a value of any domain (although called null
  value)
• Indicates the absence of a value
• Not allowed in certain situations
• Primary keys and columns constrained by NOT NULL

31
Default Value

• Value to be assigned if attribute value in a row

• is not specified

CREATE TABLE Student ( Id INTEGER, Name
CHAR(20) NOT NULL, Address CHAR(50),
Status CHAR(10) DEFAULT freshman, PRIMARY
KEY (Id) )
32
Semantic Constraints in SQL

• Primary key and foreign key are examples of
  structural (syntactic) constraints
• Semantic constraints
• Express the logic of the application at hand
• e.g., number of registered students ? maximum
  enrollment

33
Semantic Constraints (contd)

• Used for application dependent conditions
• Example limit attribute values
• Each row in table must satisfy condition

CREATE TABLE Transcript ( StudId INTEGER,
CrsCode CHAR(6), Semester CHAR(6),
Grade CHAR(1), CHECK (Grade IN (A, B,
C, D, F)), CHECK (StudId gt 0 AND StudId
lt 1000000000) )
34
Semantic Constraints (contd)

• Example relate values of attributes in different
  columns

CREATE TABLE Employee ( Id INTEGER,
Name CHAR(20), Salary INTEGER,
MngrSalary INTEGER, CHECK ( MngrSalary gt
Salary) )
35
Constraints Problems

• Problem 1 Empty table always satisfies all CHECK
  constraints (an idiosyncrasy of the SQL standard)

• If Employee is empty, there are no rows on which
  to evaluate the CHECK condition.

CREATE TABLE Employee ( Id INTEGER,
Name CHAR(20), Salary INTEGER,
MngrSalary INTEGER, CHECK ( 0 lt (SELECT
COUNT () FROM Employee)) )
36
Constraints Problems

• Problem 2 Inter-relational constraints should be
  symmetric
• Why should constraint be in Employee an not
  Manager?
• What if Employee is empty?

CREATE TABLE Employee ( Id INTEGER,
Name CHAR(20), Salary INTEGER,
MngrSalary INTEGER, CHECK ((SELECT COUNT
() FROM Manager) lt
(SELECT COUNT () FROM Employee)) )
37
Assertion

• Element of schema (like table)
• Symmetrically specifies an inter-relational
  constraint
• Applies to entire database (not just the
  individual rows of a single table)
• hence it works even if Employee is empty

CREATE ASSERTION DontFireEveryone CHECK (0 lt
SELECT COUNT () FROM Employee)
38
Assertion
CREATE ASSERTION KeepEmployeeSalariesDown
CHECK (NOT EXISTS( SELECT
FROM Employee E WHERE
E.Salary gt E.MngrSalary))
39
Assertions and Inclusion Dependency
CREATE ASSERTION NoEmptyCourses CHECK (NOT
EXISTS ( SELECT FROM
Teaching T WHERE --
for each row T check
-- the following condition
NOT EXISTS (
SELECT FROM Transcript R
WHERE T.CrsCode
R.CrsCode AND
T.Semester R.Semester) ) )
Courses with no students
Students in a particular course
40
Domains

• Possible attribute values can be specified
• Using a CHECK constraint or
• Creating a new domain
• Domain can be used in several declarations
• Domain is a schema element

CREATE DOMAIN Grades CHAR (1) CHECK (VALUE
IN (A, B, C, D, F)) CREATE TABLE
Transcript ( ., Grade Grades,
)
41
Foreign Key Constraint
CREATE TABLE Teaching ( ProfId INTEGER,
CrsCode CHAR (6), Semester CHAR (6),
PRIMARY KEY (CrsCode, Semester), FOREIGN KEY
(CrsCode) REFERENCES Course, FOREIGN KEY
(ProfId) REFERENCES Professor (Id) )
42
Foreign Key Constraint
CrsCode
x
CrsCode
ProfId
x
y
Course
Id
Teaching
y
Professor
43
Circularity in Foreign Key Constraint
A1
A2
A3
B1
B2
B3
x
x
y
B
y
A
candidate key A1 foreign key A3 references B(B1)
candidate key B1 foreign key B3 references A(A1)
Problem 1 Creation of A requires existence of B
and vice versa Solution CREATE TABLE A
( ) -- no foreign key
CREATE TABLE B ( ) -- include foreign
key ALTER TABLE A
ADD CONSTRAINT cons
FOREIGN KEY (A3)
REFERENCES B (B1)
44
Circularity in Foreign Key Constraint (contd)

• Problem 2 Insertion of row in A requires prior
  existence of row in B and vice versa
• Solution use appropriate constraint checking
  mode
• IMMEDIATE checking
• DEFERRED checking

45
Reactive Constraints

• Constraints enable DBMS to recognize a bad state
  and reject the statement or transaction that
  creates it
• More generally, it would be nice to have a
  mechanism that allows a user to specify how to
  react to a violation of a constraint
• SQL-92 provides a limited form of such a reactive
  mechanism for foreign key violations

46
Handling Foreign Key Violations

• Insertion into A Reject if no row exists in B
  containing foreign key of inserted row
• Deletion from B
• NO ACTION Reject if row(s) in A references row
  to be deleted (default response)

x
A
B
x
?
Request to delete row rejected
47
Handling Foreign Key Violations (contd)

• Deletion from B (contd)
• SET NULL Set value of foreign key in referencing
  row(s) in A to null

B
A
null
x
Row deleted
48
Handling Foreign Key Violations (contd)

• Deletion from B (contd)
• SET DEFAULT Set value of foreign key in
  referencing row(s) in A to default value (y)
  which must exist in B

y
B
A
y
x
Row deleted
49
Handling Foreign Key Violations (contd)

• Deletion from B (contd)
• CASCADE Delete referencing row(s) in A as well

A
B
x
x
50
Handling Foreign Key Violations (contd)

• Update (change) foreign key in A Reject if no
  row exists in B containing new foreign key
• Update candidate key in B (to z) same actions
  as with deletion
• NO ACTION Reject if row(s) in A references row
  to be updated (default response)
• SET NULL Set value of foreign key to null
• SET DEFAULT Set value of foreign key to default
• CASCADE Propagate z to foreign key

Cascading when key in B changed from x to z
B
z
A
z
51
Handling Foreign Key Violations (contd)

• The action taken to repair the violation of a
  foreign key constraint in A may cause a violation
  of a foreign key constraint in C
• The action specified in C controls how that
  violation is handled
• If the entire chain of violations cannot be
  resolved, the initial deletion from B is rejected.

y
x
y
x
B
C
A
52
Specifying Actions
CREATE TABLE Teaching ( ProfId INTEGER,
CrsCode CHAR (6), Semester CHAR (6),
PRIMARY KEY (CrsCode, Semester), FOREIGN KEY
(ProfId) REFERENCES Professor (Id) ON
DELETE NO ACTION ON UPDATE CASCADE,
FOREIGN KEY (CrsCode) REFERENCES Course
(CrsCode) ON DELETE SET NULL ON
UPDATE CASCADE )
53
Triggers

• A more general mechanism for handling events
• Not in SQL-92, but is in SQL1999
• Trigger is a schema element (like table,
  assertion, )

CREATE TRIGGER CrsChange AFTER UPDATE OF
CrsCode, Semester ON Transcript WHEN (Grade
IS NOT NULL) ROLLBACK
54
Views

• Schema element
• Part of external schema
• A virtual table constructed from actual tables on
  the fly
• Can be accessed in queries like any other table
• Not materialized, constructed when accessed
• Similar to a subroutine in ordinary programming

55
Views - Examples
Part of external schema suitable for use in
Bursars office
CREATE VIEW CoursesTaken (StudId, CrsCode,
Semester) AS SELECT T.StudId, T.CrsCode,
T.Semester FROM Transcript T
Part of external schema suitable for student with
Id 123456789
CREATE VIEW CoursesITook (CrsCode, Semester,
Grade) AS SELECT T.CrsCode, T.Semester,
T.Grade FROM Transcript T WHERE
T.StudId 123456789
56
Modifying the Schema
ALTER TABLE Student ADD COLUMN Gpa INTEGER
DEFAULT 0 ALTER TABLE Student ADD CONSTRAINT
GpaRange CHECK (Gpa gt 0 AND Gpa lt
4) ALTER TABLE Transcript DROP CONSTRAINT
Cons -- constraint names are useful DROP
TABLE Employee DROP ASSERTION DontFireEveryone
57
Access Control

• Databases might contain sensitive information
• Access has to be limited
• Users have to be identified authentication
• Generally done with passwords
• Each user must be limited to modes of access
  appropriate to that user - authorization
• SQL92 provides tools for specifying an
  authorization policy but does not support
  authentication (vendor specific)

58
Controlling Authorization in SQL
GRANT access_list
ON table
TO user_list access modes
SELECT, INSERT, DELETE, UPDATE, REFERENCES GRANT
UPDATE (Grade) ON Transcript TO prof_smith
Only the Grade column can be updated by
prof_smith GRANT SELECT ON Transcript TO joe
Individual columns cannot be specified
for SELECT access (in the SQL
standard) all columns of Transcript can be
read But SELECT access control to
individual columns can be simulated
through views (next)
User name
59
Controlling Authorization in SQL Using Views
GRANT access ON view TO user_list

• GRANT SELECT ON CoursesTaken TO joe
• Thus views can be used to simulate access
  control to individual columns of a table

60
Authorization Mode REFERENCES

• Foreign key constraint enforces relationship
  between tables that can be exploited to
• Control access can enable perpetrator prevent
  deletion of rows
• Reveal information successful insertion into
  DontDissmissMe means a row with foreign key value
  exists in Student

CREATE TABLE DontDismissMe ( Id INTEGER,
FOREIGN KEY (Id) REFERENCES Student
ON DELETE NO ACTION )
INSERT INTO DontDismissMe (111111111)
61
REFERENCE Access mode (contd)

• GRANT REFERENCES
• ON Student
• TO joe
