Title: AgeStructured Population Growth


1
Age-Structured Population Growth
  • Projection Matrices

2
Age-Structured Matrices
  • Some definitions
  • A matrix is a shorthand way to write out an
    equation.
  • It consists of n rows and n columns of numbers
  • Simplifies the projection of age-structured
    populations

3
Vectors
  • A vector is a matrix with just one row or column
  • Vectors we are interested in are the vector (Sx)
    which describes the number of individuals in each
    age class at time x

4
Projection
  • To project forward, multiply the vector of
    population size (Sx) times the age-projection
    matrix of survival and fertility probabilities
  • Note-we use age classes and survival and
    fertility probabilities in matrices, ages and
    survivorship schedules and fecundity schedules in
    life-tables

5
Calculating Age Class Survival Probabilities
  • Use probability of surviving from one age class
    to the next
  • Similar to the gx calculations in Gotelli

6
Projecting forward
7
Calculating Age Class Fertility Probabilities
  • Note that fertility probabilities include both
    the per capita reproduction and the probability
    that those individuals survive to the next age
    class

8
Projecting Forward-Number in first age class
9
The Age-Projection Matrix
  • Has the fertility parameters (f1fn) in the top
    row
  • The first column of row 2 has p21, the survival
    probability of going from age 1 to age 2.
  • Survival probabilities of going from age class x
    to age class x1 are in a diagonal from p21 to
    the lower right.
  • All other entries in the matrix are 0.

10
Example of an Age-Specific Matrix
11
Using Matrices to Project Populations
12
Matrix calculations-some rules
  • In matrices, you do an element by element
    multiplication with the elements in the rows
    multiplied by the elements in the columns.
  • For example, a 3 by 3 matrix has 3 rows and 3
    columns. It can be multiplied by a vector of 3
    rows and a resulting vector of 3 rows results.
  • If the matrix is not square, ie rectangular, say
    4 by 7, the vector must be 4, not 7.
  • n(t1)An(t) where A is a Leslie Matrix

13
Matrix projections
  • Like life tables, matrix projections will show
    initial fluctuations in the rate of increase (r
    or ?) and the stable age structure.
  • Like life tables, matrix projections will
    eventually show a stable age structure and ? (the
    dominant eigenvalue)
  • You can also calculate the reproductive value
    using matrices (it is the left eigenvector of the
    matrix)

14
Matrix Modeling Software-Populus
  • Populus actually uses the matrix format to model
    life-tables
  • Can see the matrix equivalents of a life-table by
    viewing the Leslie matrix graph
  • All the derived parameters (rate of increase,
    stable age structure, and reproductive values)
    are the same for life-tables and matrices

15
(No Transcript)
16
Matrix Modeling Software-PopTools add-in for Excel
  • There is a free add-in for using Excel to do
    matrix calculations
  • It is available at http//www.cse.csiro.au/poptool
    s
  • Has a handy feature for making loop graphs

17
(No Transcript)
18
(No Transcript)
19
Life-Cycle Diagrams (made using PopTools)
Life-cycle diagrams show the links between nodes
(age classes) of survival (links from node x to
x 1 and fertility (from node xn to x0)
20
Matrix Modeling Software-Matlab
  • Advanced programming language using matrices
  • This is a course in itself but offers the most
    flexibility and customization in doing the
    modeling

21
(No Transcript)
22
PRIMER1 Master script for chapter 1 of
Jonathan Roughgarden, 1998, Primer of Ecological
Theory, Prentice Hall. Uses MATLAB and the
Symbolic Toolbox. (Does NOT use SIMULINK.) cd
c\primer diary on f 'q - h (b - a)' be
solve(f,'b') be expand(be) pretty(be)
latex(be) h 50 a 18 q 1000 eval(be) q
0 1000 1500 y eval(be)
23
Matrix Modeling Software-Ramas Ecolab
24
Select Age and Stage Structure
25
Enter Model Information
  • Fill out the following (required)
  • General information-Title, comments,
    replication, duration, stochasticity, constraints
  • Stages-names, weights, and number of stages
  • Stage Matrix-fertility and survival
    probabilities
  • Initial Abundance-initial population vector
  • Standard Deviation Matrix (Optional)
  • Density Dependence (Optional)
  • Management and Migration (Optional)

26
Run the model and examine results
27
(No Transcript)
