Skewed Class Distributions and Mislabeled Examples

1
Skewed Class Distributions and Mislabeled Examples

• Jason Van Hulse
• Taghi M. Khoshgoftaar
• Amri Napolitano
• Department of Computer Science and Engineering
• Florida Atlantic University

2
Overview

• Introduction
• Datasets
• Noise Injection Procedure
• Learners
• Experimental Design
• Results
• Conclusions

3
Introduction

• Our research considers a synthesis of two
  important and pervasive problems encountered in
  data mining.
• Class imbalance or skewed class distributions in
  the case of a binary dependent variable, class
  imbalance occurs when the examples in one class
  (dramatically) outnumbers the examples in the
  other class.
• Class noise or labeling errors occur when an
  example has an incorrect class label.

4
Introduction

• Numerous works have considered the issues of
  class imbalance and class noise separately,
  however, there has been a lack of systematic
  study of the interaction between these two
  concepts.
• Therefore, our work presents a comprehensive
  empirical evaluation of learning from imbalanced
  data which contains labeling errors.
• Our experiments utilize a unique noise simulation
  methodology, allowing for the controlled
  evaluation of several important parameters
  governing the distribution of class noise.

5
Datasets

• The experimental datasets considered in these
  experiments come from the domain of empirical
  software engineering.
• The software measurement data used are from five
  NASA software projects, CM1, MW1, PC1, KC1, and
  KC3. The data was made available through the
  Metrics Data Program at NASA.
• Each module was characterized by 13 software
  measurements (independent variables). The quality
  of the modules (dependent variable) is described
  by their class labels, i.e., nfp (not-fault
  prone) and fp (fault-prone).

6
Noise Injection Procedure

• Before simulated noise was injected, a learnable
  subconcept was extracted from each dataset.
• This was done because the original dataset may
  contain some class noise, and injecting noise
  into a dataset which is already noisy can be very
  problematic.
• A technique called the RBCM-based noise filter,
  proposed in related work, was used to eliminate a
  subset of examples from each dataset.
• After the examples were eliminated from each
  dataset, numerous classifiers were built on the
  reduced dataset and all achieved perfect or
  near-perfect classification accuracy,
  demonstrating that the target concept in the
  reduced dataset is learnable.

7
Noise Injection Procedure

• Dataset statistics, by positive class (i.e.,
  fp) examples and negative class (i.e., nfp)
  examples, before and after filtering
• Dataset CM1 originally contained 48 fp and 457
  nfp examples, while after filtering, CM1
  contained 39 fp and 277 nfp examples.

8
Noise Injection Procedure

• Two noise simulation parameters were used
• The overall level of noise in the dataset ?
  10, 20, 30, 40, 50.
• The percentage of noise from the minority class ?
  0, 25, 50, 75, 100.
• Given ? ?0 and ? ?0, randomly select 2 ?0
  P ?0 examples from class P and corrupt the
  class to N, and randomly select 2 ?0 P
  (1-?0) examples from class N and corrupt to
  class P.
• P is the number of minority class examples in
  the dataset.

9
Noise Injection Procedure

• For example, suppose the dataset D (after
  filtering) contains 100 P and 900 N examples, and
  ? 30 and ? 25.
• Then 2 0.3 100 0.25 15 P examples from D
  are corrupted to class N, and 2 0.3 100 (1
  - 0.25) 45 N examples from D are corrupted to
  class P.

10
Noise Injection Procedure

• The below chart shows a sample (for ? 10) of
  the noise injection statistics for the filtered
  KC1 dataset.
• In the second row, which shows ? 10 and ?
  25, a total of 55 instances are corrupted, 14 of
  which had the class flipped from fp to nfp
  (denoted P ? N), while 41 examples have the class
  flipped from nfp to fp (denoted N ? P).
• After noise corruption, there are 298 fp examples
  (13.6 of which are mislabeled) and 1066 nfp
  examples (1.3 of which are mislabeled).

11
Learners

• Our experiments utilized 11 different learners,
  all constructed using the Weka data mining tool
• C4.5 with the default Weka parameters (C4.5D)
• C4.5 without pruning and with Laplace smoothing
  (C4.5N)
• Two k nearest neighbor learners, with k 2, 5
  (2NN and 5NN)
• Naïve Bayes (NB)
• Logistic regression (LR)
• Multi-layer perceptron (MLP)
• Support vector machines, called SMO in Weka (SVM)
• Random forests (RF)
• RIPPER, a rule-based learner
• Radial basis function network (RBF)

12
Experimental Design

• For each of the five input datasets, 24 different
  combinations of ? and ? were considered (note
  that ? 50 and ? 100 could not be
  accommodated since there would be no minority
  class examples remaining).
• All learners were evaluated using 10-fold cross
  validation (CV).
• Noise was injected into the training dataset
  only, and performance was measured (using the
  area under the ROC curve or AUC) using the
  test-fold.
• The process of randomly corruption instances
  according to the parameters ? and ?, and
  performing CV, was repeated 10 times.
• 5 datasets 10 runs of 10-fold CV results in 500
  uncorrupted datasets, each of which are corrupted
  with 24 different combinations of ? and ?, for a
  total of 12,000 noisy datasets. 11 learners were
  constructed on each noisy dataset, so in total
  132,000 classifiers were built in these
  experiments.

13
Results

• The x-axis is the percentage of noise coming from
  the positive class , labeled min0, . . . ,
  min100, and the y-axis represents the AUC.
• Each level of noise is represented by a
  different line, labeled n10, . . . , n50.
• For almost all learners, increasing the level of
  noise ? with ? 0 does not dramatically impact
  learner performance.
• There is a very strong interaction between ? and
  ? related to the impact on learner performance.


14
Results

• The above table shows the AUC for each learner,
  averaged over all five datasets and all values
  for ?, for different levels of noise ?.
• Some learners (NB and MLP) are relatively robust
  to increases in class noise, while others (RBF,
  RIPPER, SVM, and C4.5D) suffer significantly as
  the percentage of class noise increases.
• For example, the AUC for RIPPER decreases from
  0.965 at 10 class noise to 0.836 at 50, for a
  decrease of 13.37.

15
Results

• The above table shows the AUC for each learner,
  averaged over all five datasets and all values
  for ?, for different levels of noise from the
  minority class ?.
• Again, some learners deteriorate significantly
  when more noise comes from the minority class
  (RIPPER, SVM, RBF, C4.5D, and LR), while NB, and
  to a lesser extent MLP and RF, are relatively
  robust.

16
Conclusions

• P ? N-type noise (i.e., examples whose correct
  class is P but are mislabeled as N) has a
  significant impact on the performance of learners
  built from imbalanced data.
• Conversely, the same level of N ? P-type noise
  does not cause as much harm.
• Therefore, if a data mining practitioner is
  considering filtering the training dataset when
  learning from imbalanced data, it may not be
  sensible to filter any positive examples
• The impact of mislabeled positive examples is
  relatively low.
• The cost of mistakenly filtering a correctly
  labeled positive example is high. Since the
  positive class is already relatively rare,
  mistakenly filtering correctly labeled positive
  examples further exacerbates the difficulties
  encountered when learning from imbalanced data.

17
Conclusions

• All of the learners were adversely impacted by
  noise, however some learners showed more
  stability at higher levels of noise. A more
  thorough evaluation of the robustness of learners
  in the presence of noise should be evaluated in
  future work.
• Future work should also consider multi-class
  problems.
• Additional learning algorithms can also be
  considered, and methods to optimize the
  performance of classifiers in the presence of
  noisy and imbalanced data should be evaluated.
• Finally, additional datasets from different
  application domains can be utilized.

18
Questions?
