KeLPIO

1
KeLPIO
A Telescope-Ready Domain-Specific I/O Library for
Irregular Block-Structured Applications Bradley
Broom, Rob Fowler, Ken Kennedy Department of
Computer Science Rice University
2
Compiler Optimization of I/O

• I/O is very slow, and often significantly affects
  performance.
• I/O optimized software is often very complex
• Structure remapping.
• Asychronous, threaded I/O.
• Effective compiler optimization of I/O allows
  software to be
• Simpler,
• More easily developed, and
• More easily maintained.
• We prefer very high-level, domain-specific
  language facilities
• Simplify programming
• Simplify compiler analysis

3
Language Extensions for I/O

• One way is to add new language features to
  support I/O.
• Similar to HPF directives for automatic
  parallelization.
• But many problems
• Limited to comparatively low-level, general
  purpose facilities.
• Do not satisfy our desire for high-level I/O.
• Limited acceptance by user community.
• Limited compiler support.
• Reduced portability.
• Uncertain future.
• Adds to language proliferation.
• Should extend every language C, C, Java,
  Fortran, ...

4
Our Approach Telescoping

• Extend compiler optimization technology so that
  library calls are treated as language primitives.
• Programmer sees a standard language with a
  domain-specific I/O library.
• Compiler sees a domain-specific language with
  very high-level facilities for I/O.
• Requires an extensible compiler generation
  framework.
• Library developer, or domain expert, (or end
  user) should be able to add optimization rules
  and generate an optimizer.
• Libraries should be structured to facilitate
  optimization.
• KelpIO a high-level I/O library for irregular
  block-structured applications.

5
Agenda

• Introduction
• What is KelpIO?
• Why is it useful?
• Quick KeLP Review
• Brief Overview of KelpIO
• Optimizing KelpIO Programs
• Further Research

6
What is KeLPIO ?

• KeLP Kernel Lattice Parallelism
• A high-level C library for managing
  communication in (irregular) block-structured
  applications.
• KeLPIO KeLP Input/Output
• A library of KeLP-like Input/Output operations
• Provides I/O interface at same level as
  communication
• Uses existing low-level (parallel) libraries for
  actual I/O
• Support for
• Application I/O, Snapshoting, Checkpointing
• Out-of-core execution

7
KeLPIO Goals

• Provide a collection of intuitive, high-level I/O
  operations
• Be implemented with reasonable efficiency as a
  library
• Expose a multi-layered interface of increasing
  complexity, specificity, and efficiency
• To enable (compiler) transformation of high-level
  I/O operations into more efficient, but
  lower-level operations
• Be compatible with the KeLP library.

8
Agenda

• Introduction
• Quick KeLP Review
• Brief Overview of KelpIO
• Optimizing KelpIO Programs
• Further Research

9
Quick Review of KeLP

• C library for coordinating irregular
  block-structured scientific applications
• Based on intuitive, geometric, programming
  abstractions points, regions, ...
• Region arithmetic allows regions to be added,
  subtracted, ...
• Dimensionality is strongly typed PointX, RegionX
• Trailing X ? 1,2,3,4 denotes dimensionality

10
Main KeLP Concepts

• Application arrays are subdivided into blocks
  called GridXs
• GridX is a RegionX with processor assignment and
  data storage
• XArrayX manages a collection of GridXs
• Instantiates GridXs according to a FloorPlanX
• Provides (collective) iterators for accessing all
  GridXs in an XArrayX
• Inspector-Executor communications paradigm
• MotionPlanX describes required communication
• MoverX performs communication

11
Computational Building Blocks

• Application arrays are subdivided into blocks
  called GridXs
• A GridX consists of
• a RegionX denoting its extent
• a processor assignment
• data storage
• GridX data
• can be accessed from C,
• but Fortran interface often used by numerical
  kernels

12
Managing GridXs

• XArrayX manages a collection of GridXs
• GridXs can have overlapping RegionXs
• Provides (collective) operations for
• Instantiating GridXs according to a FloorPlanX
• Accessing GridXs and their data
• Iterating over all GridXs in an XArrayX
• Iterating over all GridXs on the local processor

13
KeLP's Communication Model

• Uses inspector-executor paradigm
• MotionPlanX describes required communication
• A collection of individual data motions, each
  containing
• Source and destination XArrayX
• Source and destination GridX
• RegionX to communicate
• MoverX performs communication described by
  MotionPlanX
• Variety of movers within KeLP framework
• Vectorizing Mover
• Adding Mover

14
KeLP Example

• Void fillGhost(DoubleArray2 X)
• MotionPlan2 M
• for (indexIterator1 ii(X) ii ii)
• int i ii(0)
• Region2 inside grow(X(i).region(), -1)
• for (indexIterator1 jj(X) jj jj)
• int j jj(0)
• if (i ! j) M.CopyOnIntersection(X,i,X,j,ins
  ide)
• DoubleArray2Mover DM(X,X,M)
• DM.execute()

15
Agenda

• Introduction
• Quick KeLP Review
• Brief Overview of KelpIO
• Application I/O
• Snapshoting and Checkpointing
• Out-of-core programming
• Optimizing KelpIO Programs
• Further Research

16
KeLPIO Overview

• Provides KeLP-like primitives for communicating
  array data between GridXs and external arrays
• Designed for
• Application I/O
• Snapshoting
• Checkpointing
• Out-of-core execution
• Independent of the underlying I/O library
• Does not duplicate I/O library functions other
  than read and write
• Target I/O libraries are interfaced to KeLPIO by
  a concrete implementation of the FileInterface
  abstract class

17
External Arrays

• FileArrayX
• Is the KelpIO interface to an external array
• Is strongly typed in
• Number of dimensions
• Element type
• Uses FileInterface object to perform I/O
• Similar to XArrayX
• FileArrayX manages a collection of blocks
• DecompositionX represents which processors can
  (should) directly access regions of the array

18
I/O Plans and Movers

• Based on same inspector-executor paradigm as KeLP
• Classes IOPlanX and IOMoverX move data between
  GridX within an XArrayX and RegionX within a
  FileArrayX
• Direction of movement (from XArrayX to FileArrayX
  or vice-versa) determines input or output
• IOPlanX and IOMoverX are either all input or all
  output
• Source and destination must have the same
  processor assignment

19
KelpIO Example (Part 1/2)

• Void saveData (int N, DoubleArray2 X,
• char filename, int offset)
• PassionFile pf (MODE_WRITEONLY, filename)
• Region2 r (1, 1, N, N)
• Processors2 P
• Decomposition2 T(r)
• T.distribute(BLOCK1,BLOCK1,P)
• FileArray2ltdoublegt fa (T, pf, offset)

20
KelpIO Example (Part 2/2)

• IOPlan2 iop
• for (indexIterator1 ii(X) ii ii)
• int i ii(0)
• Region2 inside grow(X(i).region(), -1)
• for (indexIterator1 jj(T) jj jj)
• int j jj(0)
• iop.CopyOnIntersection(X,i,fa,j,inside)
• IOMover2ltGrid2ltdoublegt, doublegt iom(X,fa,iop)
• iom.execute()

21
Snapshoting

• Use same strategy as application I/O
• Create IOPlanX once, then execute IOMoverX
  repeatedly
• Need to change external array position between
  snapshots
• Use FileArrayXSetOffset for numerical positions
• Directly access and change FileView otherwise

22
Checkpointing

• If overlap doesn't need saving, use same strategy
  as application I/O
• If overlap must be saved
• Replicated elements generally have different
  values
• Cannot use one-to-one correspondence between
  internal and external grid positions
• Solution translate GridXs to eliminate overlap

23
Embeddings

• EmbeddingX shifts GridX to new positions
• Original GridXs continue to store data
• Can use EmbeddingX to transform away overlap
  regions
• Utility function RemoveOverlap does this for
  regular decompositions
• Multi-dimensional rectangular bin-packing problem
  in general (NP-hard)
• Application must provide mechanism
• Future provide general-purpose (but not optimal)
  function

24
Out-of-core Programming

• Manual conversion from in-core to out-of-core
• Can require substantial effort to introduce
  staging areas, rearrange computation
• Results in divergence of in-core and out-of-core
  codes, duplicated effort
• KeLPIO enables semi-automatic conversion, with
  minimal source code changes
• Easy to conditionally compile for either in-core
  or out-of-core
• Basic unit of OOC decomposition is the GridX
• Overpartition array and assign multiple GridXs
  per processor
• Only a subset of GridXs assigned to each
  processor are in core concurrently

25
Managing Out-of-core GridXs

• OOCXArrayX is a new GridX management class
  similar to XArrayX
• Accessing a specific GridX from an OOCXArrayX
  forces that GridX into memory
• Least recently accessed GridX is swapped out

26
Using OOCXArrayX

• Application creates OOCXArrayX much like an
  XArrayX
• Must create multiple GridXs per processor
• Application enables OOCXArrayX
• Determines non-overlapping EmbeddingX
• Creates swap array (FileArrayX)
• Sets number of GridXs to cache
• Application uses OOCXArrayX much like an XArrayX
• Programmer must ensure only cached GridXs are
  accessed
• Possible, as cache behavior predictable from
  source
• Performance implications should also be
  considered
• Must use OOCMoverX for communicating

27
Communication Involving OOCXArrayXs

• Standard KeLP movers inadequate for out-of-core
  data
• Transient GridXs always require buffering
• Swapping of GridXs should be minimized
• When a specific GridX is swapped in, do as many
  communications involving it as possible
• OOCMoverX designed for moving data involving
  OOCXArrayXs

28
Conditionally Compiled OOC

• Use typedefs for all potentially OOC XArrayXs and
  MoverXs
• To compile in-core application
• Define typedefs using KeLP XArrayX and MoverX
• typedef XArray2ltGrid2ltdoublegt gt DoubleArray2
• To compile out-of-core application
• Define typedefs using KelpIO OOCXArrayX and
  OOCMoverX classes
• typedef OOCXArray2ltGrid2ltdoublegt gt DoubleArray2
• Overpartition the array (create multiple GridXs
  per processor)
• Compile in code to establish OOC backing store
  and enable OOC cache

29
Agenda

• Introduction
• Quick KeLP Review
• Brief Overview of KelpIO
• Optimizing KelpIO Programs
• File Layout Optimization
• File Access Optimization
• Out-of-core Optimization
• Further Research

30
File Layout Optimization

• Specific file layouts often not required
• Checkpoint files
• Out-of-core swap files
• Use EmbeddingX to remap GridXs into
  high-performance shape
• Library function Pencilize can remap general
  shape into a pencil along one dimension

31
File Access Optimization

• Interleave I/O and computation
• Create multiple IOPlanXs and IOMoverXs
• Interleave/combine similar I/Os
• Merge snapshots and checkpoints
• Use asynchronous I/O (not implemented)
• Prefetch out-of-core GridXs

32
Out-of-core Optimization

• Optimization of swap file layout
• Optimization of GridX size
• Algorithmic optimization
• Example loop fusion
• Explicit control of GridX cache
• Examples renewing, aging, flushing, clearing
• Optimization of KeLPIO primitives used
• Adjust cache size to use available memory

33
Optimizing OOC Primitives

• Accessing a GridX is potentially very expensive
• May need to read from disk (and write-back old
  GridX)
• Use utility access methods provided for non-data
  GridX methods
• These do not affect GridX cache
• const accesses don't make GridXs dirty
• Clean GridXs don't need to be written back to
  disk
• Repeatedly accessing a GridX is expensive
• Unnecessarily checks and updates LRU data each
  access
• Move GridX accesses out of computation loops

34
Optimized Out-of-Core Example

• Void fillGhost(DoubleArray2 X)
• MotionPlan2 M
• For (indexIterator1 ii(X) ii ii)
• int i ii(0)
• Region2 inside grow(X.region(i), -1)
• for (indexIterator1 jj(X) jj jj)
• int j jj(0)
• if (i ! j)
• M.CopyOnIntersection(X,i,X,j,inside)
• DoubleArray2Mover DM(X,X,M)
• DM.execute()

35
Adjusting OOC Cache Size

• Set the OOC Cache size to use available memory
• However, always ensure it's large enough to
  guarantee that only cached GridXs are used
• OOC Cache size can be adjusted dynamically
• Periodically monitor available physical memory
  and adjust cache size appropriately
• Allows a single executable to configure itself
  for high performance on any node in a Grid
  environment.
• Makes use of memory when it's available
• Avoids thrashing when it isn't

36
Runtime Overhead of OOCXArrayX

• OOCXArrayX with all GridXs cached has similar
  performance to XArrayX for reasonable numbers of
  GridXs per processor

37
Recent and Future Status

• Recent Developments
• Released KeLPIO version 1.4.0 compatible with
  KeLP 1.4
• Coming Soon
• Fortran interface to core KeLP and KeLPIO library
  functions
• No application C required
• New GridX management class for multiple time step
  computations.
• Allows more computation between communication
  steps.
• Essentially the same computation/communication
  ratio.
• To download software, search for KeLPIO on Google.

38
Acknowledgements

• KelpIO is supported in part by the National
  Partnership for Advanced Computational
  Infrastructure (NPACI).
