Diagnosing NetworkWide Traffic Anomalies

1
Diagnosing Network-Wide Traffic Anomalies

• Anukool Lakhina, Mark Crovella, Christophe Diot

2
Anomaly Diagnosis

• Is my network experiencing unusual conditions?
• e.g., DoS attacks, outages, misconfigurations
• DetectionIs there an unusual event?
• IdentificationWhat is the best explanation?
• QuantificationHow serious is the problem?

A general framework for AnomalyDiagnosis
3
Problem Statement

• A volume anomaly is a sudden change in an
  Origin-Destination flow (i.e., point to point
  traffic)
• Given link traffic measurements, diagnose the
  volume anomalies

4
An Illustration

• Detect the time of the anomaly
• Identify the source destination
• Quantify the size of the anomaly

5
Data Collected
Abilene
Sprint-Europe
6
Typical Link Data
Abilene
Sprint-Europe
Finding common patterns (e.g. volume anomalies)
from such high-dimensional, noisy data is very
difficult
7
Low Intrinsic Dimensionality of Link Traffic

• Studied via Principal
• Component Analysis
• Key result
• Normal traffic is well approximated as occupying
  a low dimensional subspace
• Reasons
• Links share OD flows
• Set of OD flows also low
• dimensional

8
The Subspace Method

• An approach to separate normal from anomalous
  traffic
• Normal Subspace, space spanned by the first
  k principal components
• Anomalous Subspace, space spanned by the
  remaining principal components
• Then, decompose traffic on all links by
  projecting onto and to obtain

Residual trafficvector
Traffic vector of all links at a particular
point in time
Normal trafficvector
9
A Geometric Illustration
In general, anomalous traffic results in a large
value of
Traffic on Link 2
Traffic on Link 1
10
Detection

• Capture size of vector using squared prediction
  error
• Assuming Gaussian data, we can find boundswhich
  SPE should only exceed 1- of the time
• Result due to Jackson and Mudholkar, 1979

Traffic on Link 2
Traffic on Link 1
11
Detection Illustration
Value of
over time(SPE)
SPE at anomaly time points clearly stand out
12
Identification

• An anomaly causes a displacement of the link
  traffic vector away from
• The direction of the displacement gives
  information about the nature of the anomaly
• Intuition find the hypothesis that best
  describes the detected anomaly

13
Hypothesis-Based Identification

• Denote set of all anomalies by
• Each adds link traffic specified by

• In the presence of
• is found by minimizing the distance to
  in the direction of the anomaly

Normal Subspace,
14
Selecting the Best Hypothesis

• 1. For each hypothesized anomaly
• compute
• 2. Select anomaly as

The best hypothesis (OD flow) accounts for
maximum residual traffic
15
Quantification

• Given hypothesized anomaly ,
• Estimated per-link anomaly traffic is
• And the size of the anomaly is

16
Validation Identifying True Volume Anomalies

• Measure OD flows for Sprint-Europe and Abilene
  networks
• To identify true volume anomalies,
• Look for significant deviations in each OD flow
• Use two different approaches EWMA filtering,
  and Fourier frequency-domain filtering
• Note time point, OD flow, and amount of deviation
• These are our true volume anomalies
  (approximately)

17
Results on True Volume Anomalies Sprint
40 Largest deviations in OD flows via Fourier
True Anomaly Size
Anomaly (rank order)
Quantification
Identification
Detection
18
Summary True Volume Anomalies

• Summary
• High Detection Rate
• Low False Alarm Rate
• Accurate Identification
• Accurate Quantification

19
Summary Synthetic Volume Anomalies

• Summary
• Detection rates about 90
• Identification better on Sprint than Abilene
• Quantification good in both networks

20
Power of the Subspace Method

• Subspace Method exploits correlation among links
  to define normal traffic behavior
• Effective diagnosis of volume anomalies requires
  a whole-network approach
• Previous work has concentrated on measurements
  from individual links

21
Conclusions

• Diagnosing Volume Anomalies
• Proposed a general diagnosis framework
• Subspace method yields high detection rates, low
  false alarm rate
• Accurate hypothesis-based identification and
  quantification
• Subspace method also useful in other contexts
• Poster in the Network Troubleshooting Workshop
• Paper in the IMC 04
