MAMMOGRAPHY

1
MAMMOGRAPHY

• QUALITY ASSURANCE
• Quality Assurance/Quality Control

2
MQSA

• FEDERAL LEGISLATION
• OCT. 1, 1994
• EQUIPMENT DESIGN OPERATION STANDARDS
  (DEDICATED UNITS)
• INTENSIVE QUALITY CONTROL PROGRAM

3
QUALITY CONTROL

• Quality control is an equipment and processing
  evaluation program in diagnostic imaging centers.
• QC involves testing, record keeping and
  evaluation of imaging equipment and processing
• QC Team includes Radiographer, Physicists and
  Radiologist
• QA involves people scheduling, reports, waiting
  time and follow up exams

4
MAMMO QC

• SEE PG 589 CARLTONS PHYSICS BOOK

5
Elements of QC

• TASKS
• Darkroom Clean
• Processor QC sensitometry/densitometry and
  DEVELOPER temp
• Screen Cleaning
• VISUAL CHECK
• Phantom Images
• Repeat Analysis (should be less than 2 repeat
  rate - diagnostic rad 5)

• FREQUENCY
• Daily
• Weekly
• Monthly/Quarterly

6
MAMMO QC

• DARKROOM FOG
• SCREEN/FILM CONTACT
• COMPRESSION

• SEMIANNUALLY
• NOT MORE THAN 25 PSI

7
(No Transcript)
8
Clean crossovers daily
9
Dedicated processor
10
QUALITY CONTROL TOOLS

• PHANTOM
• DIGITAL THERMOMETER
• SCREEN CLEANER
• LINT FREE CLOTHS
• FIXER RETENTION TESTING KIT
• CHARTS

11
DAILY QC
12
(No Transcript)
13
PHANTOM IMAGES

• Daily - to assure film density, contrast,
  uniformity and image quality are optimum Using
  the SAME cassette and technical factors each
  time.
• 4/5 masses 3/4specks and 4/6 fibers should be
  seen

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
REPEAT ANALYSIS

• Mammography should be less than 2
• Number of repeated film
• Repeat Rate --------------------------- X 100
• Total of films
• Diagnostic Radiology less than 5
• Students less than 10

18
MORE QC TESTS
19
PURPOSE OF QC

• ASSURES OPTIMUM PATIENT CARE by avoiding
  unnecessary repeat exposures due to artifacts,
  processing problems and equipment failure

20
(No Transcript)
21
EQUIPMENT CONSIDERATIONS

• FILM SCREEN
• VS
• DIGITAL

22
EQUIPMENT DIFFERENCES

• TARGET MATERIAL
• MOLYBDENUM
• MO/RHODIUM
• SMALLER FOCAL SPOTS
• SHORTER SID

• KVP RANGES
• 24 30
• MAS
• PHOTOCELLS

23
(No Transcript)
24
(No Transcript)
25
DIGITAL MAMMO

• DIGITAL has a resolution of approximately
• 5 line/pairs per millimeter but also has
  MORE CONTRAST
• CONVENTIONAL FILM/SCREEN resolution of
  approximately
• 12 line/pairs per millimeter

26
DIGITAL MAMMOGRAPHY
27
(No Transcript)
28
DEDICATED MAMMOGRAPIC EQUIPMENT

• KVP RANGE 23 30 kvp
• TARGETS Molybdenum /
  Rhodium (vs. Tungsten)
• FOCAL SPOTS (0.1 0.6)
• SID 60 70 cm (vs. 100cm)
• Compression Paddle
• Heel Effect (fat/cat)
• GRIDS 41 or 51 (vs 8 to161)

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
MAMMOGRAPHICIMAGES

• The BREAST has a low subject contrast little
  differences in density soft tissue radiography

35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
