Title: CSC 2260 Operating Systems and Networks


1
CSC 2260Operating Systems and Networks
  • Chapter 6
  • Fall 2008
  • Dr. Chuck Lillie

2
(No Transcript)
3
Making the Windows GUI Work for You
Chapter
6
  • Who Invented the Desktop?
  • Navigating the Windows GUI
  • Configuring Customizing the Windows Desktop
  • Managing Files in Windows
  • Launching Programs in Windows
  • Selecting a Strategy for Leaving the Desktop
  • Troubleshooting Common Desktop Problems

4
Learning Objectives
  • Explain the nature and history of the Windows GUI
  • Navigate the Windows GUI
  • Configure and customize the Windows desktop
  • Manage files in Windows
  • Launch applications in Windows
  • Select a method for leaving the desktop
  • Troubleshoot common Windows desktop problems

5
Who Invented the Desktop?
  • 1968 Douglas Engelbarts demonstration
  • 1970s Xerox PARC influences others
  • Result desktop metaphor

6
Navigating the Windows GUI
  • Getting to the Desktop via Logon
  • User Accounts
  • Each account is a record in an accounts database
  • Local database or server-based
  • Windows 9x does not have local accounts database
  • Workgroups and Domains
  • Workgroups
  • Logical grouping for sharing resources
  • Unique name on the network
  • No central accounts database only local

7
Navigating the Windows GUI
  • Getting to the Desktop via Logon (continued)
  • Workgroups and Domains (continued)
  • Domains
  • Logical grouping for sharing resources
  • Unique name on the network
  • Central accounts database
  • The use of CTRL-ALT-DELETE before logon
  • Most versions of Windows can require
    Ctrl-Alt-Delete to open logon dialog box
  • Security measure to clear memory

8
Navigating the Windows GUI
  • Getting to the Desktop via Logon (continued)
  • Working with Logon Dialog Boxes
  • Logging onto a stand-alone or workgroup computer
  • Windows XP Welcome to Windows dialog box
  • Windows NT Logon Information dialog box
  • Windows 98 Welcome or Enter Network Password
  • Windows 2000 Log On to Windows dialog box

9
Navigating the Windows GUI
  • Getting to the Desktop via Logon (continued)
  • Working with Logon Dialog Boxes (continued)
  • Logging onto a Microsoft Windows Domain
  • User logs on to access domain resources
  • A computer can be a member of a domain and be
    centrally managed as a resource of a domain
  • The computer from which a user logs on must be a
    domain member
  • Windows 9x exception user logon without
    computer membership
  • Windows XP Home cannot be a member of a domain,
    and a user cannot log onto a domain from XP Home

10
Navigating the Windows GUI
  • Getting to the Desktop via Logon (continued)
  • Working with Logon Dialog Boxes (continued)
  • Buttons in the Logon Dialog Boxes
  • OK
  • Cancel
  • Help
  • Shut Down
  • Options

11
Navigating the Windows GUI
  • Step-by-Step 6.01
  • Logging Onto Windows
  • Page 258

12
Navigating the Windows GUI
  • A Tour of the Desktop
  • Getting Started
  • Special dialog boxes in Windows NT, 98, and 2000
  • Cartoon-style message balloon in Windows XP
  • First Look
  • Default desktop includes mouse pointer, taskbar,
    Start menu button, and one or more icons

13
Navigating the Windows GUI
  • A Tour of the Desktop (continued)
  • Desktop Icons
  • Default icons vary among versions of Windows
  • My Computer, Internet Explorer, Recycle Bin.
    Network Neighborhood, My Network Places, My
    Briefcase, My Documents, MSN Internet Account,
    Online Services, Connect to the Internet

14
Navigating the Windows GUI
  • A Tour of the Desktop (continued)
  • Taskbar
  • Default position across bottom of screen
  • Start button
  • Quick Launch toolbar
  • Buttons for running programs
  • Notification area (AKA system tray or systray)
  • Reposition and resize
  • Windows XP default locked
  • Taskbar Properties

15
Navigating the Windows GUI
  • A Tour of the Desktop (continued)
  • Start Menu
  • Programs/All Programs
  • Documents/My Recent Documents
  • Personal Folders

16
Navigating the Windows GUI
  • Step-by-Step 6.02
  • Using the Start Menu
  • Page 271

17
Configuring and Customizing the Windows Desktop
  • Classic Desktop vs. Active Desktop
  • Active Desktop web content on desktop
  • Classic desktop double-click to open objects
  • Enable/Disable in Display applet
  • Web tab
  • Desktop tab in Windows XP
  • Single-click a separate option in Windows XP

18
Configuring and Customizing the Windows Desktop
  • Decorating the Desktop Background, Color
    Schemes, and Settings
  • Background/Desktop page of Display applet
  • Background
  • Wallpaper
  • Colors
  • Screen saver
  • Themes

19
Configuring and Customizing the Windows Desktop
  • Customizing the Taskbar
  • Quick Launch toolbar
  • An area on the taskbar designed to launch
    programs that are used frequently

20
Configuring and Customizing the Windows Desktop
  • Step-by-Step 6.03
  • Customizing the Desktop
  • Page 274

21
Managing Files in Windows
  • File and Folder Basics
  • A file is information organized as a unit
  • A folder is a special file that holds a list of
    files and other folders
  • An application may save to a default folder
  • User may choose to save in other folder

22
Managing Files in Windows
  • File and Folder Basics (continued)
  • File/folder management actions
  • Opening
  • Closing
  • Copying
  • Moving
  • Deleting

23
Managing Files in Windows
  • What Files Should You Manage?
  • Users only manage data files
  • Understand folder structure
  • Document and Settings
  • Windows
  • Program Files
  • Fonts
  • System and System32
  • Temp

24
Managing Files in Windows
  • What Files Should You Manage? (continued)
  • Hands Off System Files!
  • Root of drive C
  • WINNT or WINDOWS folder
  • Hidden by default in Windows 2000 and XP
  • Make system files visible in Tools Folder
    Options

25
Managing Files in Windows
  • What Files Should You Manage? (continued)
  • Managing Data Files
  • Data File types
  • Text files
  • Word processing document files
  • Graphic files
  • Database files
  • Spreadsheet files

26
Managing Files in Windows
  • Organizing Files Using Folders
  • GUI Techniques
  • Drag-and-Drop Rules in Explorer/My Computer
  • Dragging while pressing right mouse button
    options
  • Dragging while pressing CTRL move
  • Dragging to another drive copy
  • Dragging to another drive while pressing SHIFT
    move
  • Dragging a program file creates a shortcut to
    program

27
Managing Files in Windows
  • Step-by-Step 6.04
  • Managing Files and Folders
  • Page 280

28
Managing Files in Windows
  • Non-GUI TechniquesThe Command Prompt
  • Open command prompt and run commands
  • Launch any program that runs in Windows
  • Work at command prompt within Windows

29
Managing Files in Windows
  • Non-GUI TechniquesThe Command Prompt (continued)
  • The Command Prompt in Windows 9x
  • DOS Virtual Machine
  • Uses DOS Command shell (COMMAND.COM)
  • Start Programs MS-DOS Prompt

30
Managing Files in Windows
  • Non-GUI TechniquesThe Command Prompt (continued)
  • The Command Prompt in Windows NT, Windows 2000,
    and Windows XP
  • Menu item Command Prompt
  • Launches CMD.EXE
  • 32-bit character-mode command prompt
  • Do no Harm!
  • Never do file management at the command prompt
  • Never run third-party disk utilities at the
    command prompt

31
Managing Files in Windows
  • Non-GUI TechniquesThe Command Prompt (continued)
  • The Command Prompt in Windows NT, Windows 2000,
    and Windows XP (continued)
  • 8.3 File Names vs. Long File Names
  • Windows creates both a long file name and an 8.3
    alias
  • Best-supported in GUI
  • Using the 8.3 file name from the command prompt
    brings risk of losing the long file name

32
Managing Files in Windows
  • Non-GUI TechniquesThe Command Prompt (continued)
  • The Command Prompt in Windows NT, Windows 2000,
    and Windows XP (continued)
  • The Dangers of FDISK and Other DOS Utilities
  • FDISK will not run in Windows NT, Windows 2000,
    Windows XP, or Windows Server 2003
  • FDISK is the only partitioning program in Windows
    9x
  • FDISK run after booting with a startup disk will
    run unrestricted

33
Managing Files in Windows
  • Step-by-Step 6.05
  • Working at the Command Prompt in Windows
  • Page 285

34
Managing Files in Windows
  • Maintenance of Disks and Files
  • Perform basic maintenance regularly
  • Remove excess files that accumulate over time
  • Reorganize how files are saved on disk
  • Back up valuable data and system files

35
Managing Files in Windows
  • Maintenance of Disks and Files (continued)
  • Remove excess files with Disk Cleanup
  • Not available in Windows NT
  • Start All Programs Accessories System Tools
  • Start Run cleanmgr

36
Managing Files in Windows
  • Maintenance of Disks and Files (continued)
  • Defragmenting a Disk
  • Disk Defragmenting utility (not in Windows NT)
  • Start All Programs Accessories System Tools
    Disk Defragmenter
  • Start Run dfrg.msc

37
Managing Files in Windows
  • Maintenance of Disks and Files (continued)
  • Backing up data
  • Data is more valuable than hardware and software
  • Therefore, backup is critical
  • Most Windows versions include backup program
  • Third party programs offer more features

38
Launching Programs in Windows
  • Start Menu
  • Program Shortcut
  • Start Run
  • Launch by Association

39
Launching Programs in Windows
  • Step-by-Step 6.06
  • Launch Programs in Windows
  • Page 291

40
Launching Programs in Windows
  • Command Prompt
  • Launching Windows Programs from the Command
    Prompt
  • Running DOS Applications in Windows

41
Launching Programs in Windows
  • Step-by-Step 6.07
  • Running MS-DOS Editor in Windows
  • Page 294

42
Selecting a Strategy for Leaving the Desktop
  • Logging Off and Shutting Down
  • Log off
  • Log off and Shut Down

43
Selecting a Strategy for Leaving the Desktop
  • System Standby
  • Sleep state
  • Consumes minimal power
  • On resume, all programs and data open
  • Settings in Power Options applet
  • Not really turned off
  • Requires power (AC or battery)

44
Selecting a Strategy for Leaving the Desktop
  • Hibernate
  • Contents of memory saved to disk
  • Computer powered off no power required
  • On resume, all programs and data open
  • Settings in Power Options in Control Panel

45
Selecting a Strategy for Leaving the Desktop
  • Start Menu
  • Start Shut Down
  • Shut Down Windows dialog box
  • May include Log off, Shut Down, Restart,
    Hibernate (not in NT), and Standby (not in NT)
  • Start Log off (Windows XP)
  • Start Turn Off Computer (Windows XP)

46
Selecting a Strategy for Leaving the Desktop
  • Ctrl-Alt-Delete
  • Opens Security dialog box
  • Select Log off or Shut down

47
Troubleshooting Common Windows Desktop Problems
  • Disappearing Dialog Box
  • Dialog box closes before completion
  • Pressing Enter closes
  • Do not press Enter until completed

48
Troubleshooting Common Windows Desktop Problems
  • Inability to Find Something
  • Forget where you saved a file?
  • Use the Windows Find or Search utility
  • Flexible searches on almost anything you can
    remember about a file

49
Troubleshooting Common Windows Desktop Problems
  • Windows Fails to Start
  • Data floppy disk left in drive
  • Last Known Good
  • Advanced Options Menu

50
Troubleshooting Common Windows Desktop Problems
  • Windows Stalls
  • No response from Windows or apps
  • Cannot close any apps
  • In Windows 9x press Ctrl-Alt-Delete
  • In newer versions press Ctrl-Shift-Esc
  • If Explorer not responding, restart
  • Any other single app can be removed

51
Troubleshooting Common Windows Desktop Problems
  • An Application Fails to Start
  • Possible lack of memory
  • Close other applications and retry

52
Chapter Summary
  • Who Invented the Desktop?
  • The origins go back several decades
  • Many innovative people contributed to the
    desktop metaphor Douglas Engelbart
    demon-strated the use of a mouse in 1968.
  • The mouse and keyboard are your primary input
    devices.

53
Chapter Summary
  • Who Invented the Desktop?
  • The Palo Alto Research Center (PARC) was a major
    contributor to the desktop metaphor.
  • The Apple Macintosh was the first successful
    consumer product using a GUI and a mouse.
  • The desktop metaphor endures today in Windows,
    Macintosh OS, and in various GUI interfaces for
    UNIX and Linux.

54
Chapter Summary
  • Navigating the Windows GUI
  • In most organizations, you must log on and be
    authenticated before you can access the desktop.
  • A user account is a record in an accounts
    database that may exist locally (except for
    Windows 9x) or on a network server.
  • Logging onto a computer requires a user name and
    password that match those in a user account.

55
Chapter Summary
  • Navigating the Windows GUI
  • A workgroup is a grouping of computers on a
    network for the sake of sharing printers and
    folders.
  • A Microsoft Windows domain has a centralized
    security accounts database, maintained on one or
    more special servers called domain controllers.
    This database contains accounts for users,
    groups, and computers in the domain and can be
    used to authenticate a user for access to any
    domain resource.

56
Chapter Summary
  • Navigating the Windows GUI
  • For a more secure logon, ctrl-alt-delete is
    required to bring up the logon dialog box in
    all but Windows 9x.
  • By default, Windows XP, Windows 2000
    Professional, and Windows NT Workstation allow
    users to select Shutdown even though no one is
    logged on. Not allowed on servers.

57
Chapter Summary
  • Navigating the Windows GUI
  • Windows Help has improved with each version of
    Windows. Use it!
  • Windows now has a variety of graphical objects
    the cursor, icons, shortcuts, dialog boxes,
    windows, folders, buttons, toolbars, menus, and
    the taskbar.
  • The Start button gives you access to menus from
    which you can launch programs.

58
Chapter Summary
  • Navigating the Windows GUI
  • The Documents shortcut icon contains shortcuts
    to recently opened data files. In Windows XP
    this folder is named My Recent Documents, but is
    not enabled by default.

59
Chapter Summary
  • Navigating the Windows GUI
  • Personal folders are a subset of special folders
    that Windows creates to hold files and folders
    for each user. Included are files containing
    desktop configuration and preference information,
    each users own data files. Shortcuts to some
    personal folders are on the Start menu.
  • Personal Folders include Start Menu, My
    Documents, Favorites, Desktop, and many others.

60
Chapter Summary
  • Configuring and Customizing the Desktop
  • If Active Desktop is enabled, choose between the
    classic Windows desktop and Web view. In classic
    Windows desktop, double-click to open an object
    in Web view, objects on the desktop behave like
    links in a web page that can be open-ed with a
    single click.
  • Shortcuts added to the Quick Launch area of the
    taskbar are launched with a single click.

61
Chapter Summary
  • Configuring and Customizing the Desktop
  • Control Panel contains many applets that allow
    you to configure your hardware and software.
  • Right-click on the desktop, choose Properties to
    open the Display Properties box, a Control Panel
    applet that allows you to customize many aspects
    of the desktop.

62
Chapter Summary
  • Manage Files in Windows
  • A file is information organized as a unit, and
    the author of a file determines how much
    information is stored in a file.
  • Files allow you to put information into
    manageable chunks.
  • A special type of file acts as a container for
    files, called a folder in Windows, but
    previously called a directory in MS-DOS. You can
    create folders in a hierarchy, enhancing the
    organization of your files.

63
Chapter Summary
  • Manage Files in Windows
  • File management in the Windows GUI is easier and
    safer than in DOS because you dont have to
    memorize commands that use cryptic syntax you
    dont have to feel like you are taking a typing
    test every time you want to create, copy, move,
    or delete a file or folder and because you can
    see exactly what files and folders you have
    selected for a file management operation.

64
Chapter Summary
  • Manage Files in Windows
  • Two important file types are program files and
    data files. Program files (also called binary
    files) contain programming code, and data files
    contain the data you create and work with in
    your applica-tion programs.
  • It is best not to attempt to manage program
    files, especially those the operating system
    requires, called system files. Leave them in the
    folders in which the operating system or
    installation pro-grams place them.

65
Chapter Summary
  • Manage Files in Windows
  • Manage data files.
  • A short list of data file types includes
  • Text filesmost often have the TXT extension
  • Word processing document filesDOC extension
  • Graphic filesBMP, DIB, GIF, JPG, TIF, etc.
  • Database filesAccess uses the MDB extension
  • Spreadsheet filesExcel uses the XLS extension

66
Chapter Summary
  • Manage Files in Windows
  • The Find/Search option has been improved with
    each version of Windows. In Windows NT, you can
    search for files, folders, and com-puters, but
    in Windows XP, you can search for almost
    anything in the world that is searchable over
    the Internet.
  • Users can manage files and folders in My Computer
    and Windows Explorer and from the command prompt.
    The last is not recommended.

67
Chapter Summary
  • Launching Programs in Windows
  • Users can launch programs by using the Start
    menu.
  • Another method for launching programs is with
    the use of shortcuts on the desktop or other
    locations.

68
Chapter Summary
  • Launching Programs in Windows
  • Using the file extensions of data files, Windows
    associates the files with applications that can
    create and read that file type. When you click
    on a file that has an extension for which
    Windows has an association, Windows will start
    the associated program and load the file as data
    for the program.

69
Chapter Summary
  • Launching Programs in Windows
  • Another method for launching a program is to use
    Start Run. Then enter a command name in the
    box to launch a program.
  • Launch a program from the command prompt. If the
    program is a GUI program, it will be launch-ed
    in a window.

70
Chapter Summary
  • Leave the Desktop by Logging Off and Shutting
    Down
  • Your end-of-day procedure depends on the rules
    for using the computer.
  • In some organizations, users are required to log
    off but to leave the computer running.
  • In other organizations, users are required to log
    off and shut down the computer.
  • Never just switch off your desktop computer with
    the on/off switch. You should always do so from
    within Windows.

71
Chapter Summary
  • Troubleshoot Common Windows Desktop Problems
  • Pressing ENTER when you intended to select a new
    field may cause a dialog box to disappear.
  • Use the Find or Search function to find lost
    files.
  • Leaving a floppy disk in the drive is a frequent
    cause of startup failure.
  • If Windows stops responding, you may have no
    other choice but to restart your computer.
Write a Comment
User Comments (0)
About PowerShow.com
