Software Reliability Methods and Experience Dave Dwyer USA

1
Software Reliability Methods and Experience
Dave Dwyer USA EIS david.j.
dwyer_at_ baesystems.com

2
Overview and outline

• Definitions
• Similarities and differences hardware and
  software reliability
• Foundations of Musas models reviewed
• Trachtenberg (Trachtenberg, Martin. The Linear
  Software Reliability Model and Uniform Testing,
  IEEE Transactions on Reliability, 1985, pp 8-16)
• Downs (Downs, Thomas. An Approach to the
  Modeling of Software Testing with Some
  Applications, IEEE Transactions on Software
  Engineering, Vol. SE-11, No. 4, April 1985, pp
  375-386)
• Instantaneous Failure Rate, a.k.a. failure
  intensity
• Hardware - Duane, Codier
• Software - analogous derivation
• Testing results
• SW reliability calculator

3
SW reliability defined

• Software reliability defined
• The probability of failure-free operation for a
  specified time in a specified environment for a
  specified purpose (Software Engineering, 5th
  edition, I. Somerville, Addison-Wesley, 1995)
• The probability of failure-free operation of a
  computer program for a specified time in a
  specified environment (Software Reliability,
  Musa, Iannino, Okumoto, McGraw-Hill, 1987)
• We will use MTBF or its reciprocal, ?

4
HW vs. SW reliability

• The hardware reliability discipline provided an
  impetus to provide for safety margins in the
  stresses, both mechanical and electrical
• But margins of safety dont mean much in software
  because it doesnt wear out
• Software has x failures per million unique
  executions if y executions/hour, then xy
  failures/million hours
• Once a process has been successfully executed,
  that identical process is not going to fail in
  the future

5
Martin Trachtenberg (1985)

• Simulation testing showed that
• Testing the functions of the software system in a
  random or round-robin order and fixing the
  failures gives linearly decaying system error
  rates
• Testing and fixing each function exhaustively one
  at a time gives flat system-error rates
• Testing and fixing different functions at widely
  different frequencies gives exponentially
  decaying system error rates operational profile
  testing, and
• Testing strategies that result in linear decaying
  error rates tend to require the fewest tests to
  detect a given number of errors
• Testing to the operational profile gives the
  lowest time to reach an operational MTBF

6
Downs Pure approach reflected the nature of
software (1985)

• The execution of a sequence of M paths
• The actual number of paths affected by a fault is
  treated as a random variable c
• Not all paths are equally likely to be executed
• ?j (N j)?, where
• N the total number of faults,
• j the number of corrected faults,
• ? -r log(1 c/M),
• r the number of paths executed/unit time

7
Downs execution path parameters

• Start

8
Our data analysis approach

• Cumulative 8-hour test shifts are recorded
• Failures plotted
• All
• First instance
• The last data point will be put at the end of the
  test time
• Only integration and system test data

9
Failure rate is proportional to failure number,
Downs ?j ? (N j)r(c/M)
10
Failure rate plots against failure number for a
range of non-uniform testing profiles, M1, M2
paths and N1, N2 initial faults in those paths
11
Instantaneous failure intensity derivation
Duanes for hardware
Instantaneous ? for HW
Instantaneous ? for SW
Same Approach
Similar Result
12
Background test example

• Console operation and operating profile
• Necessity of distinguishing failure priorities
• Priority 1 Prevents mission essential
  capability
• Priority 2 Adversely affects mission essential
  capability with no alternative workaround
• Priority 3 Adversely affects mission essential
  capability with alternative workaround
• Work shifts varied over test duration 1-3/day
• Calculation of failure intensity

13
Corrective action for Priority 2 failures
suspended while Priority 1 failures corrected
14
Codier, Duane 1964 RAMS HW reliability growth

• Ref. Appendix B, Notes on Plotting (Codier,
  Ernest O., Reliability Growth in Real Life,
  Proceedings, 1968 Annual Symposium on
  Reliability, New York, IEEE, January 1968, pp
  458-469)
• 1. The latter points, having more information
  content, must be given more weight than earlier
  points (Trachtenberg, too)
• 2. The normal curve-fitting procedures of drawing
  the line through the center of gravity of all
  the points should not be used
• 3. Start the line on the last data point and seek
  the region of highest density of points to the
  left right for Musa plots of it

15
How I draw a growth line through the points on a
reliability growth plot?

• Is there one point that is most important?
• Yes, the last point represents the cumulative
  MTBF to date it has the most degrees of freedom
• Should the trend line go through that point?
• Yes, it has the best measure of cumulative MTBF
• Would an Excel trend line go through that point?
• No, its just a least squares fit with all points
  weighing the same
• What is the least important point?
• The first it has the least degrees of freedom

16
Questions Drawing a line through the points
(cont.)

• If the line goes through the last point, what
  else should it go through?
• The center of density of the other points (ref.
  back to Duane, Codier)
• What is the center of density?
• The center of density is where the center of mass
  would be if The latter points are given more
  weight than earlier points

17
Example - Priority 1 data plotted
18
Point estimates vs. instantaneous
19
The formula for calculation of ?i correlates with
interval estimates of failure intensity
20
Most recent data plot
21
A calculator has been developed for BAE Systems
SW reliability practice 8349714
22
Priority 1 data graph
23
Questions?

• Anybody want a grad course in SW Reliability? I
  need 5 more students
• Rivier College can do that through
  teleconference(e-mail david.j.dwyer_at_baesystems.c
  om)
• You will solve a real problem _at_ no charge to your
  department (except tuition)
