Using the Sony Mavica Digital Camera

1
Using the Sony Mavica Digital Camera
2
Identifying Parts on the Front of the Camera
1

• Shutter Button
• Zoom Lever
• Tripod receptacle
• 4. Lens and Cover

2
4
3
3
Parts of the Front of the Camera, Continued

• Built-in Microphone
• Accessory Jack
• DC IN Jack

6
7
5
4
Identifying the Parts of the Back of the Camera

• Photo Cell for LCD Screen
• LCD Screen
• Volume Buttons
• LCD Backlight Switch

1
3,4
2
5
Back of Camera, Continued

• 5. Play/Still/Movie Selector
• 6. Power on/Off Lamp
• 7. Power Switch
• 8. Flash Button

7
6
5
8
6
Back of Camera, Continued

• Focus Button
• Program Button
• Display Button
• Floppy Disk Slot

12
9
10
11
7
Back of Camera, Continued

• 13. Memory Stick Slot
• 14. MS/FD (Memory Stick/Floppy Disk) selector
• 15. Access Lamp
• 16. Disk Eject Lever

15
16
14
13
8
Back of Camera, Continued

• Battery Cover
• USB Cover/Jack
• Menu Control Button

17
18
19
9
Getting Started

• Slide the power on.
• Insert the floppy disk until it clicks.
• To eject the disk, slide the Eject lock to the
  left, slide down the Disk Eject lever.

10
Recording Still Images

• Set the Play/Still/Movie selector to Still
• Using the MS/FD selector, select FD for Floppy
  Disk
• Point the camera toward an object and frame it in
  the LCD screen.
• Press and hold the shutter halfway down. Listen
  for the beep, look for the green flashing dot to
  stop flashing and become solid green.
• Press the shutter down fully. Recording will
  appear on the LCD screen.

11
Using the Zoom Feature

• If you want your subject to appear closer, press
  the T side of the Zoom for telephoto.
• If you want the subject to appear farther away,
  press the W for wide-angle.
• If you cant get a sharp focus on a close
  subject, slide the zoom lever to the W side, and
  move closer to the subject until the focus is
  sharp.

12
Playing Back Recorded Images on the Digital Camera

• Set the Play/Still/Movie selector to Play.
• Press the round Control button up to display the
  menu bar at the bottom of the LCD screen.
• Use the left or right arrow on the Control button
  to select Index on the menu bar.
• Press the up arrow on the Control button to
  select the forward and back arrow on the menu
  bar. Press the back arrow to see previous images
  on the disk.

13
Viewing All Images at Once on the 3.5 Floppy Disk

• Set the Play/Still/Movie selector to Play.
• Use the Control button to move to the word Index.
• Select Index on the LCD screen. All recorded
  images will be displayed at once.
• Individual pictures can be selected by using the
  Control buttons left and right arrows. Press
  the center of the Control button to make the
  image look larger.

14
Inserting a Digital Picture into a Microsoft
Application

• Place the disk with pictures into the computers
  floppy disk drive.
• Open the application that will receive the
  digital picture.
• From the applications menu bar, pull down the
  INSERT menu, and click on PICTURE. Then chose
  FROM FILE.

15
Inserting a Digital Picture, Continued

• In the drop-down LOOK IN menu, select 3 ½ (A)
  drive.
• From the picture files, single-click to get a
  preview. Double-click (or click the INSERT
  button) to insert your selection.

16
Inserting a Digital Picture, Continued

• Once in your document, the picture may be sized
  or moved in any way youd like
• To move the picture, place the pointer over the
  picture so that you see four arrows. Click,
  hold, and drag.
• To resize, click on the picture, place the
  pointer on any corner of the picture until you
  see two diagonal arrows. Click, hold, and drag
  to make it bigger or smaller

17
Formatting a Disk in the Camera

• On the Menu bar, click File
• Arrow up to Disk Tool
• Arrow right and up to Format
• Select Format by pressing the center of the menu
  button
• Arrow up to OK and press center of menu button

18
Troubleshooting

• Any problems? You can always use the
• applications help function to guide you
• through any tough situations.
