Lucene Boot Camp

1
Lucene Boot Camp

• Grant Ingersoll
• Lucid Imagination
• Nov. 12, 2007
• Atlanta, Georgia

2
Intro

• My Background
• Your Background
• Brief History of Lucene
• Goals for Tutorial
• Understand Lucene core capabilities
• Real examples, real code, real data
• Ask Questions!!!!!

3
Schedule

• 10-1010 Introducing Lucene and Search
• 1010-12 Indexing, Analysis, Searching,
  Performance
• 12-1205 Break
• 12-1 More on Indexing, Analysis, Searching,
  Performance
• 1-230 Lunch
• 230-240 Recap, Questions, Content
• 240-440 Class Example
• 4-420 Break
• 420-5 Class Example
• 5-520 Lucene Contributions (time permitting)
• 520-525 Open Discussion (time permitting)
• 525-530 Resources/Wrap Up

4
Lucene is

• NOT a crawler
• See Nutch
• NOT an application
• See PoweredBy on the Wiki
• NOT a library for doing Google PageRank or other
  link analysis algorithms
• See Nutch
• A library for enabling text based search

5
A Few Words about Solr

• HTTP-based Search Server
• XML Configuration
• XML, JSON, Ruby, PHP, Java support
• Caching, Replication
• Many, many nice features that Lucene users need
• http//lucene.apache.org/solr

6
Search Basics

• Goal Identify documents that are similar to
  input query
• Lucene uses a modified Vector Space Model (VSM)
• Boolean VSM
• TF-IDF
• The words in the document and the query each
  define a Vector in an n-dimensional space
• Sim(q1, d1) cos T
• In Lucene, boolean approach restricts what
  documents to score

dj ltw1,j,w2,j,,wn,jgt q ltw1,q,w2,q,wn,qgt w
weight assigned to term
7
Indexing

• Process of preparing and adding text to Lucene
• Optimized for searching
• Key Point Lucene only indexes Strings
• What does this mean?
• Lucene doesnt care about XML, Word, PDF, etc.
• There are many good open source extractors
  available
• Its our job to convert whatever file format we
  have into something Lucene can use

8
Indexing Classes

• Analyzer
• Creates tokens using a Tokenizer and filters them
  through zero or more TokenFilters
• IndexWriter
• Responsible for converting text into internal
  Lucene format

9
Indexing Classes

• Directory
• Where the Index is stored
• RAMDirectory, FSDirectory, others
• Document
• A collection of Fields
• Can be boosted
• Field
• Free text, keywords, dates, etc.
• Defines attributes for storing, indexing
• Can be boosted
• Field Constructors and parameters
• Open up Fieldable and Field in IDE

10
How to Index

• Create IndexWriter
• For each input
• Create a Document
• Add Fields to the Document
• Add the Document to the IndexWriter
• Close the IndexWriter
• Optimize (optional)

11
Task 1.a

• From the Boot Camp Files, use the
  basic.ReutersIndexer skeleton to start
• Index the small Reuters Collection using the
  IndexWriter, a Directory and StandardAnalyzer
• Boost every 10 documents by 3
• Questions to Answer
• What Fields should I define?
• What attributes should each Field have?
• What Fields should OMIT_NORMS?
• Pick a field to boost and give a reason why you
  think it should be boosted

12
Use the Luke
13
Searching

• Key Classes
• Searcher
• Provides methods for searching
• Take a moment to look at the Searcher class
  declaration
• IndexSearcher, MultiSearcher, ParallelMultiSearche
  r
• IndexReader
• Loads a snapshot of the index into memory for
  searching
• Hits
• Storage/caching of results from searching
• QueryParser
• JavaCC grammar for creating Lucene Queries
• http//lucene.apache.org/java/docs/queryparsersynt
  ax.html
• Query
• Logical representation of programs information
  need

14
Query Parsing

• Basic syntax
• titlehockey (bodystanley AND bodycup)
• OR/AND must be uppercase
• Default operator is OR (can be changed)
• Supports fairly advanced syntax, see the website
• http//lucene.apache.org/java/docs/queryparsersynt
  ax.html
• Doesnt always play nice, so beware
• Many applications construct queries
  programmatically or restrict syntax

15
Task 1.b

• Using the ReutersIndexerTest.java skeleton in the
  boot camp files
• Search your newly created index using queries you
  develop
• Delete a Document by the doc id
• Hints
• Use a IndexSearcher
• Create a Query using the QueryParser
• Display the results from the Hits
• Questions
• What is the default field for the QueryParser?
• What Analyzer to use?

16
Task 1 Results

• Locks
• Lucene maintains locks on files to prevent index
  corruption
• Located in same directory as index
• Scores from Hits are normalized
• Scores across queries are NOT comparable
• Lucene 2.3 has some transactional semantics for
  indexing, but is not a DB

17
Deletion and Updates

• Deletions can be a bit confusing
• Both IndexReader and IndexWriter have delete
  methods
• Updates are always a delete and an add
• Updates are always a delete and an add
• Yes, that is a repeat!
• Nature of data structures used in search

18
Analysis

• Analysis is the process of creating Tokens to be
  indexed
• Analysis is usually done to improve results
  overall, but it comes with a price
• Lucene comes with many different Analyzers,
  Tokenizers and TokenFilters, each with their own
  goals
• See contrib/analyzers
• StandardAnalyzer is included with the core JAR
  and does a good job for most English and
  Latin-based tasks
• Often times you want the same content analyzed in
  different ways
• Consider a catch-all Field in addition to other
  Fields

19
Commonly Used Analyzers

• StandardAnalyzer
• WhitespaceAnalyzer
• PerFieldAnalyzerWrapper
• SimpleAnalyzer

20
Indexing in a Nutshell

• For each Document
• For each Field to be tokenized
• Create the tokens using the specified Tokenizer
• Tokens consist of a String, position, type and
  offset information
• Pass the tokens through the chained TokenFilters
  where they can be changed or removed
• Add the end result to the inverted index
• Position information can be altered
• Useful when removing words or to prevent phrases
  from matching

21
Inverted Index
aardvark
Little Red Riding Hood
0
hood
0
1
little
0
2
Robin Hood
1
red
0
riding
0
robin
1
Little Women
2
women
2
zoo
22
Tokenization

• Split words into Tokens to be processed
• Tokenization is fairly straightforward for most
  languages that use a space for word segmentation
• More difficult for some East Asian languages
• See the CJK Analyzer

23
Modifying Tokens

• TokenFilters are used to alter the token stream
  to be indexed
• Common tasks
• Remove stopwords
• Lower case
• Stem/Normalize -gt Wi-Fi -gt Wi Fi
• Add Synonyms
• StandardAnalyzer does things that you may not want

24
Custom Analyzers

• Solution write your own Analyzer
• Better solution write a configurable Analyzer so
  you only need one Analyzer that you can easily
  change for your projects
• See Solr
• Tokenizers and TokenFilters must be newly
  constructed for each input

25
Special Cases

• Dates and numbers need special treatment to be
  searchable
• o.a.l.document.DateTools
• org.apache.solr.util.NumberUtils
• Altering Position Information
• Increase Position Gap between sentences to
  prevent phrases from crossing sentence boundaries
• Index synonyms at the same position so query can
  match regardless of synonym used

26
5 minute Break
27
Indexing Performance

• Behind the Scenes
• Lucene indexes Documents into memory
• At certain trigger points, memory (segments) are
  flushed to the Directory
• Segments are periodically merged
• Lucene 2.3 has significant performance
  improvements

28
IndexWriter Performance Factors

• maxBufferedDocs
• Minimum of docs before merge occurs and a new
  segment is created
• Usually, Larger faster, but more RAM
• mergeFactor
• How often segments are merged
• Smaller less RAM, better for incremental
  updates
• Larger faster, better for batch indexing
• maxFieldLength
• Limit the number of terms in a Document

29
Lucene 2.3 IndexWriter Changes

• setRAMBufferSizeMB
• New model for automagically controlling indexing
  factors based on the amount of memory in use
• Obsoletes setMaxBufferedDocs and setMergeFactor
• Takes storage and term vectors out of the merge
  process
• Turn off auto-commit if there are stored fields
  and term vectors
• Provides significant performance increase

30
Index Threading

• IndexWriter and IndexReader are thread-safe and
  can be shared between threads without external
  synchronization
• One open IndexWriter per Directory
• Parallel Indexing
• Index to separate Directory instances
• Merge using IndexWriter.addIndexes
• Could also distribute and collect

31
Benchmarking Indexing

• contrib/benchmark
• Try out different algorithms between Lucene 2.2
  and trunk (2.3)
• contrib/benchmark/conf
• indexing.alg
• indexing-multithreaded.alg
• Info
• Mac Pro 2 x 2GHz Dual-Core Xeon
• 4 GB RAM
• ant run-task -Dtask.alg./conf/indexing.alg
  -Dtask.mem1024M

32
Benchmarking Results
Your results will depend on analysis, etc.
33
Searching

• Earlier we touched on basics of search using the
  QueryParser
• Now look at
• Searcher/IndexReader Lifecycle
• Query classes
• More details on the QueryParser
• Filters
• Sorting

34
Lifecycle

• Recall that the IndexReader loads a snapshot of
  index into memory
• This means updates made since loading the index
  will not be seen
• Business rules are needed to define how often to
  reload the index, if at all
• IndexReader.isCurrent() can help
• Loading an index is an expensive operation
• Do not open a Searcher/IndexReader for every
  search

35
Query Classes

• TermQuery is basis for all non-span queries
• BooleanQuery combines multiple Query instances as
  clauses
• should
• required
• PhraseQuery finds terms occurring near each
  other, position-wise
• slop is the edit distance between two terms
• Take 2-3 minutes to explore Query implementations

36
Spans

• Spans provide information about where matches
  took place
• Not supported by the QueryParser
• Can be used in BooleanQuery clauses
• Take 2-3 minutes to explore SpanQuery classes
• SpanNearQuery useful for doing phrase matching

37
QueryParser

• MultiFieldQueryParser
• Boolean operators cause confusion
• Better to think in terms of required ( operator)
  and not allowed (- operator)
• Check JIRA for QueryParser issues
• http//www.gossamer-threads.com/lists/lucene/java-
  user/40945
• Most applications either modify QP, create their
  own, or restrict to a subset of the syntax
• Your users may not need all the flexibility of
  the QP

38
Sorting

• Lucene default sort is by score
• Searcher has several methods that take in a Sort
  object
• Sorting should be addressed during indexing
• Sorting is done on Fields containing a single
  term that can be used for comparison
• The SortField defines the different sort types
  available
• AUTO, STRING, INT, FLOAT, CUSTOM, SCORE, DOC

39
Sorting II

• Look at Searcher, Sort and SortField
• Custom sorting is done with a SortComparatorSource

• Sorting can be very expensive
• Terms are cached in the FieldCache
• SortFilterTest.java example

40
Filters

• Filters restrict the search space to a subset of
  Documents
• Use Cases
• Search within a Search
• Restrict by date
• Rating
• Security
• Author

41
Filter Classes

• QueryWrapperFilter (QueryFilter)
• Restrict to subset of Documents that match a
  Query
• RangeFilter
• Restrict to Documents that fall within a range
• Better alternative to RangeQuery
• CachingWrapperFilter
• Wrap another Filter and provide caching
• SortFilterTest.java example

42
Expert Results

• Searcher has several expert methods
• Hits is not always what you need due to
• Caching
• Normalized Scores
• Reexecutes Query repeatedly as results are
  accessed
• HitCollector allows low-level access to all
  Documents as they are scored
• TopDocs represents top n docs that match
• TopDocsTest in examples

43
Searchers

• MultiSearcher
• Search over multiple Searchables, including
  remote
• MultiReader
• Not a Searcher, but can be used with
  IndexSearcher to achieve same results for local
  indexes
• ParallelMultiSearcher
• Like MultiSearcher, but threaded
• RemoteSearchable
• RMI based remote searching
• Look at MultiSearcherTest in example code

44
Search Performance

• Search speed is based on a number of factors
• Query Type(s)
• Query Size
• Analysis
• Occurrences of Query Terms
• Optimize
• Index Size
• Index type (RAMDirectory, other)
• Usual Suspects
• CPU
• Memory
• I/O
• Business Needs

45
Query Types

• Be careful with WildcardQuery as it rewrites to a
  BooleanQuery containing all the terms that match
  the wildcards
• Avoid starting a WildcardQuery with wildcard
• Use ConstantScoreRangeQuery instead of RangeQuery
• Be careful with range queries and dates
• User mailing list and Wiki have useful tips for
  optimizing date handling

46
Query Size

• Stopword removal
• Search an all field instead of many fields with
  the same terms
• Disambiguation
• May be useful when doing synonym expansion
• Difficult to automate and may be slower
• Some applications may allow the user to
  disambiguate
• Relevance Feedback/More Like This
• Use most important words
• Important can be defined in a number of ways

47
Usual Suspects

• CPU
• Profile your application
• Memory
• Examine your heap size, garbage collection
  approach
• I/O
• Cache your Searcher
• Define business logic for refreshing based on
  indexing needs
• Warm your Searcher before going live -- See Solr
• Business Needs
• Do you really need to support Wildcards?
• What about date range queries down to the
  millisecond?

48
Explanations

• explain(Query, int) method is useful for
  understanding why a Document scored the way it
  did
• ExplainsTest in sample code
• Open Luke and try some queries and then use the
  explain button

49
FieldSelector

• Prior to version 2.1, Lucene always loaded all
  Fields in a Document
• FieldSelector API addition allows Lucene to skip
  large Fields
• Options Load, Lazy Load, No Load, Load and
  Break, Load for Merge, Size, Size and Break
• Makes storage of original content more viable
  without large cost of loading it when not used
• FieldSelectorTest in example code

50
Scoring and Similarity

• Lucene has sophisticated scoring mechanism
  designed to meet most needs
• Has hooks for modifying scores
• Scoring is handled by the Query, Weight and
  Scorer class

51
Affecting Relevance

• FunctionQuery from Solr (variation in Lucene)
• Override Similarity
• Implement own Query and related classes
• Payloads
• HitCollector
• Take 5 to examine these

52
Lunch
1-230
53
Recap

• Indexing
• Searching
• Performance
• Odds and Ends
• Explains
• FieldSelector
• Relevance

54
Next Up

• Dealing with Content
• File Formats
• Extraction
• Large Task
• Miscellaneous
• Wrapping Up

55
File Formats

• Several open source libraries, projects for
  extracting content to use in Lucene
• PDF PDFBox
• http//www.pdfbox.org/
• Word POI, Open Office, TextMining
• http//www.textmining.org/textmining.zip
• XML SAX or Pull parser
• HTML Neko, Jtidy
• http//people.apache.org/andyc/neko/doc/html/
• http//jtidy.sourceforge.net/
• Tika
• http//incubator.apache.org/tika/
• Aperture
• http//aperture.sourceforge.net

56
Aperture Basics

• Crawlers
• Data Connectors
• Extraction Wrappers
• POI, PDFBox, HTML, XML, etc.
• http//aperture.wiki.sourceforge.net/Extractors
  will give you info on what comes back from
  Aperture
• LuceneApertureCallbackHandler in example code

57
Large Task

• Using the skeleton files in the
  com.lucenebootcamp.training.full package
• Get some content
• Web, file system
• Different file formats
• Index it
• Plan out your fields, boosts, field properties
• Support updates and deletes
• Optional
• How fast can you make it go? Divide and conquer?
  Multithreaded?

58
Large Task

• Search Content
• Allow for arbitrary user queries across multiple
  Fields via command line or simple web interface
• How fast can you make it?
• Support
• Sort
• Filter
• Explains
• How much slower is to retrieve an explanation?

59
Large Task

• Document Retrieval
• Display/write out the one or more documents
• Support FieldSelector

60
Large Task

• Optional Tasks
• Hit Highlighting using contrib/Highlighter
• Multithreaded indexing and Search
• Explore other Field construction options
• Binary fields, term vectors
• Use Lucene trunk version and try out some of the
  changes in indexing
• Try out Solr or Nutch at http//lucene.apache.org/

• Whats do they offer that Lucene Java doesnt
  that you might need?

61
Large Task Metadata

• Pair up if you want
• Ask questions
• 2 hours
• Use Luke to check your index!
• Explore other parts of Lucene that you are
  interested in
• Be prepared to discuss/share with the class

62
Large Task Post-Mortem

• Volunteers to share?

63
Term Information

• TermEnum gives access to terms and how many
  Documents they occur in
• IndexReader.terms()
• IndexReader.termPositions()
• TermDocs gives access to the frequency of a term
  in a Document
• IndexReader.termDocs()
• Term Vectors give access to term frequency
  information in a given Document
• IndexReader.getTermFreqVector
• TermsTest in sample code

64
Lucene Contributions

• Many people have generously contributed code to
  help solve common problems
• These are in contrib directory of the source
• Popular
• Analyzers
• Highlighter
• Queries and MoreLikeThis
• Snowball Stemmers
• Spellchecker

65
Open Discussion

• Multilingual Best Practices
• UNICODE
• One Index versus many
• Advanced Analysis
• Distributed Lucene
• Crawling
• Hadoop
• Nutch
• Solr

66
Resources

• http//lucene.apache.org/
• http//en.wikipedia.org/wiki/Vector_space_model
• Modern Information Retrieval by Baeza-Yates and
  Ribeiro-Neto
• Lucene In Action by Hatcher and Gospodnetic
• Wiki
• Mailing Lists
• java-user_at_lucene.apache.org
• Discussions on how to use Lucene
• java-dev_at_lucene.apache.org
• Discussions on how to develop Lucene
• Issue Tracking
• https//issues.apache.org/jira/secure/Dashboard.js
  pa
• We always welcome patches
• Ask on the mailing list before reporting a bug

67
Resources

• trainer_at_lucenebootcamp.com

68
Finally

• Please take the time to fill out a survey to help
  me improve this training
• Located in base directory of source
• Email it to me at trainer_at_lucenebootcamp.com
• There are several Lucene related talks on Friday

69
Extras
70
Task 2

• Take 10-15 minutes, pair up, and write an
  Analyzer and Unit Test
• Examine results in Luke
• Run some searches
• Ideas
• Combine existing Tokenizers and TokenFilters
• Normalize abbreviations
• Filter out all words beginning with the letter A
• Identify/Mark sentences
• Questions
• What would help improve search results?

71
Task 2 Results

• Share what you did and why
• Improving Results (in most cases)
• Stemming
• Ignore Case
• Stopword Removal
• Synonyms
• Pay attention to business needs

72
Grab Bag

• Accessing Term Information
• TermEnum
• TermDocs
• Term Vectors
• FieldSelector
• Scoring and Similarity
• File Formats

73
Task 6

• Count and print all the unique terms in the index
  and their frequencies
• Notes
• Half of the class write it using TermEnum and
  TermDocs
• Other Half write it using Term Vectors
• Time your Task
• Only count the title and body content

74
Task 6 Results

• Term Vector approach is faster on smaller
  collections
• TermEnum approach is faster on larger collections

75
Task 4

• Re-index your collection
• Add in a rating field that randomly assigns a
  number between 0 and 9
• Write searches to sort by
• Date
• Title
• Rating, Date, Doc Id
• A Custom Sort
• Questions
• How to sort the title?
• How to sort multiple Fields?

76
Task 4 Results

• Add stitle to use for sorting the title

77
Task 5

• Create and search using Filters to
• Restrict to all docs written on Feb. 26, 1987
• Restrict to all docs with the word computer in
  title
• Also
• Create a Filter where the length of the body
  title is greater than X

78
Task 5 Results

• Solr has more advanced Filter mechanisms that may
  be worth using
• Cache filters

79
Task 7

• Pair up if you like and take 30-40 minutes to
• Pick two file formats to work on
• Identify content in that format
• Can you index contents on your hard drive?
• Project Gutenberg, Creative Commons, Wikipedia
• Combine w/ Reuters collection
• Extract the content and index it using the
  appropriate library
• Store the content as a Field
• Search the content
• Load Documents with and without FieldSelector and
  measure performance

80
Task 7 (cont.)

• Include score and explanation in results
• Dump results to XML or HTML
• Be prepared to share with class what you did
• What libraries did you use?
• What content did you use?
• What is your Document structure?
• What issues did you have?

81
20 Minute Break
82
Task 7 Results

• Explain what your group did
• Build a Content Handler Framework
• Or help out with Tika

83
Task 8

• Building on Task 7
• Incorporate one or more contrib packages into
  your solution
