CML Seminar with Macro Team

1
CML Seminar with Macro Team

• A review of CML products
• Presented by David Falp
• Area Sales Manager

2
Scope of presentation

• CML - An Introduction
• Define CMLs position/products today
• Two Way Radio
• Wireline Telecoms
• Wireless Data
• Including-
• Product applications
• Review current market needs
• CML A Summary

3
CML Consumer Microsystems plc

• Headquarters - CML Microcircuits (UK) Ltd
• A fabless chip manufacturer/group
• 30 years telecoms market experience
• Experience in most IC processes, CMOS, BiCMOS,
  Bipolar, GaaS
• Offer ASIC service

• Two design centres in the UK
• Sales offices in US and Singapore
• Sales, marketing technical support for
  worldwide customer base
• 250 employees worldwide
• Over 60 distributors

4
Two-Way Radio

• CML Where our products are used
• CMX88n series Baseband processors
• CMX838 FRS Family Radio processor
• CMX649 CVSD Voice Codec

5
Two-Way radioWhere CML fits
6
CMX88n series Baseband processors

• A family of products for
• FRS/PMR446 low cost radio
• Professional trunked radio
• Maritime VHF radio
• Secure radio design

7
CMX881, CMX882 and CMX883 Features

• Voice Processing-
• Pre/de-emphasis
• Voiceband sub-audio filtering
• Input modulation gain control
• In-band sub-audio signalling-
• CTCSS
• DCS
• SELCALL In-band Signalling
• Data capability-
• FFSK/MSK Encode/Decode (1200/2400 bps for
  MPT1327)
• DTMF

8
CMX881 High integration PMR

• Follows our design strategy for high integration
• Designed for mid to high end professional radio
  design
• Mops up many functional blocks onto single chip
• MPT1327 trunked applications
• Simple control through serial C-bus
• Low power

9
CMX882/883 for FRS Market

• CMX883 for FRS
• Audio processing
• CTCSS (extended) and DCS
• Basic in-band signalling

• CMX882 for FRS data
• GPS data decode capability
• MSK/FFSK modem for additional future markets
  (text messaging?)

Current Future markets
10
CMX882 CMX883 Leisure Radio ICs

• Aimed at FRS/PMR446/Leisure market
• Low cost, high integration
• Addition of modem for GPS, text messaging over
  FRS
• Small footprint
• Easy implementation with serial bus
• Suitable for marine VHF

11
CMX882 FRS GPS System Diagram
12
CMX88n family summary

• Multiple radio applications through FRS to
  professional radio
• High integrations allows for
• Simplified design
• Low cost
• Low component count
• Small footprint

13
CMX838 PMR446 Audio processor on-board
Synthesiser
14
CMX838Overview

• A highly integrated signal processor for FRS,
  PMR446 and GMRS radio designs.
• Audio, Sub-audio and RF Synthesizer all on-chip
• C bus serial control
• 2.7-5.5V supply, low power consumption
• TSSOP package

15
CMX838 Overview

• Significant advances on a single chip
• Advanced CTCSS tone processor Integrated
  synthesizer
• Supports FRS, PMR446 and GMRS characteristics
• Integrated digital gains for trim and level
  controls
• Baseband clock developed from synthesizer
  reference
• Integrated audio tone generator
• External signal processing port for standard
  options

16
CMX838 Design Advantages

• High level of integration
• Lower external part count
• Lower BOM cost
• Smaller board space
• Lower power consumption
• 12mA _at_ 3.0V during TX operation
• Commonly encountered requirements have been
  pre-programmed
• Standard TIA-603 tones pre-programmed (CTCSS)
• FRS/GMRS/PMR446 channels pre-programmed
• Flexible operating modes pre-programming allow
  for faster software development

17
Summary

• For the customer The CMX838
• can streamline your FRS/PMR design project
• can reduce your external part count
• can lower your radio power consumption
• can allow for new and innovative features in your
  products
• All this functionality available in a TSSOP
  package!

18
CMX649 Voice Codec

• Full duplex voice CODEC
• 64 kbps CVSD
• m-law/A-law PCM modes
• 13 bit linear PCM
• Very low power
• Programmable gain amplifiers for analog I/O
• Analog output for earphone/speaker
• Data rates from 16 to 128 Kbps
• Programmable audio bandpass up to 14KHz
• 20 Pin TSSOP package

19
CMX649 Block Diagram
20
CMX649 Target Applications

• Digital cordless headsets (non - BlueTooth )
• BlueTooth transceiver
• Digital voice systems that need
• m-law/A-law PCM
• CVSD

21
Summary

• ADM voice CODEC
• Low power consumption (2mA _at_ 2.7V)
• Price/performance for consumer applications
• Samples April, production summer of 2002
• Applications
• Wireless headsets
• BlueTooth chips that do not integrate CODEC
• Other digital voice applications

22
Wireline Telecoms

• CML Modems
• Current market established CML products
• DE8681 V.22bis modem design tool
• CMX866 V.22bis AT Command set
• CMX878 V.22bis DAA Components
• CMX850 V.22bis modem 80C51 Micro controller
• CML ISDN products
• CMX635 Subscriber processor

23
Overview

• CML has an established reputation for low power,
  high performance modems.
• We need to maintain market position against
  strong competition
• Design-in opportunities demand more in terms of
  support
• Competitive products offer higher integration
  complete solutions, and reference circuits

24
Modem Signalling Speed Evolution
Modem technology
DTMF FSK DPSK QAM
TCM V.23 V.22
V.22bis V.32bis
SMS Meter Reading LCR
Payphones Set Top Box Data-loggers
Alarms EPOS
Application
25
Established products

• V.22bis CMX868
• V.22 CMX867
• V.23 CMX624 CMX860

• We are now offering V.22bis
• AT Command set
• Line interface embedded components
• Reference designs
• CMLs edge is power consumption BUT many
  applications are mains powered!

26
DE8681 Socket Modem Design tool

• Uses CMX868 V.22bis modem
• Approvable design to CTR21
• Small footprint, pin compatible with Conexant
  socket modem
• AT Command firmware
• Plug n play design
• Transformer based line interface
• 2.7V to 5.5V operation

27
DE8681 CMX868 typical application

• New design for telemetry, module measures tank
  status sends data via PSTN
• Modem can also handle system status, fault
  conditions, firmware downloads, etc
• Customer design is based around DE8681

28
DE8681 Summary

• Drop-in design
• CTR21 approvable
• Low power
• Flash PIC design allows customer firmware
  upgrades
• CLI Firmware to be made available
• Inexpensive BOM cost

29
CMX866 V.22bis modem AT

• All standard CMX868 features plus Embedded AT
  Command Set.
• Advantages-
• Reduces load on host processor.
• Simplifies operating software.
• Device controlled via RS232 serial port at 9600
  bps.

30
CMX866 Features, as per CMX868

• Integral AT Command Set with 'Fast Connect'
• V.23 and Bell 202 'Fast Turnaround
• AND
• V.22bis, V.22 and Bell 212A QAM/DPSK
• V.23, Bell 202, V.21 and Bell 103 FSK
• Support for Type 1 Caller Line Indentification
• DTMF/Programmable Tones Tx and Rx
• 28-Pin SSOP and SOIC Packages
• Low-Power 2.7 Volt Operation
• 'Zero-Power' and Powersave Standby Modes

31
CMX878 modem DAA

• Provides DAA (digital access arrangement) Support
  and Control
• Allows a Line Powered Interface to Telephone Line
• Generates regulated power to run uC and other
  external devices

32
CMX878 - Preliminary Application Circuit
33
CMX878

• Advantages
• Low cost external components for line power
  operation
• Simplified Design with less external components
• Line power available through CMX878
• Reduced Time to Market, applications information
  reference circuits to come
• Reduced Costs

34
CMX850 V.22bis modem 80C51 Micro

• ENHANCED 80C51 MICROCONTROLLER
• V.22bis INTEGRAL MODEM
• 8KBYTES OF INTERNAL RAM
• DUAL CLOCK SYSTEM
• ADVANCED POWER MANAGEMENT

35
Functional Diagram
36
CMX850 modem micro features

• V.22bis with fallback modes
• Line Phone differential drivers and receivers
• Programmable Tone codecs
• DTMF
• Call Progress Answertone detection
• Tx Rx levels software adjustable
• Line Reversal or Ring wake up even in sleep mode
• On chip hybrid for simple line interfacing

• 8Kbytes of internal RAM
• 64K external address range extendable to many
  Mbytes
• Real Time Clock with Alarm
• Keyboard encoder
• 13 Interrupt sources, 5 internal, 8 external
• Watchdog Timer
• Advanced oscillator and power saving controls
• Dual channel, 10-bit A to D converter with
  threshold comparators and internal bandgap
  reference

37
CMX Modems - Summary

• Complete reference design solutions
• Basic line interface
• Line powered line interface
• Lowest power solutions, smallest size
• Lowest cost
• Development road map
• Simplicity of design with CMX866/878/850 aimed at
• Set top boxes
• EPOS
• General telemetry
• SMS terminals

38
CML ISDN products

• ISDN to POTS Signalling Interface
• HDLC Controllers
• Compliance with CCITT I.430
• Clock Generator
• IOM-2 Port
• 2 Independent Analogue Differential Inputs
• 2 Independent Analogue Differential Outputs
• On-chip Speakerphone Functions
• Automatic Setting of Micro Interface

39
CMX635 - Functional Diagram
40
CML ISDN - Example Feature Phone Application
S-bus
41
Wireless data

• Modulation schemes
• CMX469A FFSK modem
• CMX589A GMSK Modem
• CMX909B GMSK Packet Data Modem

42
Types of Modulation

• MSK (Minimum Shift Keying)
• Low data rates (1200-4800bps)
• Typically used in two-way radios (LMR)
• GMSK (Gaussian pre-filtered MSK)
• High data rates (4kbps-200kbps)
• More spectrally efficient than MSK
• Typically used in PDA/laptop wireless modems
• CDPD and Mobitex networks use GMSK

43
CMX469A FFSK/MSK Modem

• Selectable data rates
• 1200/2400/4800bps operation
• Selectable crystal frequencies
• Full duplex operation
• Carrier Detect and Clock Recovery included
• Typically used in audio channels of radios
• Low power operation (2.0mA typ _at_ 3.0V)
• Small size (20-pin TSSOP package), low pin count

44
CMX589A GMSK Modem

• General purpose IC with WIDE range of
  applications
• Currently used in CDPD modems, medical telemetry,
  SCADA, etc.
• Fast design-in time, low risk
• Ultra low power consumption
• Small TSSOP size fits into a PC card!
• High data rates for both narrow band and spread
  spectrum application

45
CML High Speed Modems

• CMX909B GMSK Packet Data Modem
• High speed transfer of data over narrow-band
  wireless links
• FEC, CRC and burst error protection ensures
  robust data transmission
• Easy integration with RF chipsets

46
CMX909B (GMSK) Modem

• Rx and Tx Modes from 4kb/s to 38.4kb/s
• Full Data Packet Framing
• Full Mobitex Compatability incl. R14N
  short-block frames
• Checksum Generation and Checking
• Parallel uC interface

47
CMX909B GMSK Modem
48
Wireless data summary

• CML offers an excellent entry into low -high
  speed wireless modem markets
• High performance products with low power
  requirement
• Easy to design-in and use
• Available now and in production

49
CML A summary

• Customer support from concept to production
• Long history extensive market knowledge
• Quality product supplier
• Designing now for our market

50
Thank you for your attention!
