Grid Middleware, Grid Canada

1
Grid Middleware, Grid Canada

• darcy.quesnel_at_canarie.ca

2
Globus Toolkit 4
3
Background

• Open source project
• Under development since 1996
• Hosted by
• DOE Argonne National Laboratory
• USC Information Sciences Institute

• Now overseen by the Globus Alliance
• Argonne, ISI
• EPCC, University of Edinburgh
• NCSA
• KTH, Sweden
• Univa Corporation
• Funded by
• NSF
• IBM
• DOE
• NASA
• DARPA
• European Commission
• UK Research Councils
• Microsoft

4
Background

• Commercial partners in the Globus Consortium
• HP
• IBM
• Intel
• Sun
• Nortel
• Univa

• Enterprise Grid Alliance
• Data Synapse
• EMC2
• Fujitsu
• HP
• Intel
• NEC
• NetApp
• Oracle
• Sun

5
Background

• Various versions of Globus in use by a number of
  large science projects
• Sloan Digital Sky Survey
• National Virtual Observatory
• Collaboratory for Multi-Scale Chemical Science
• Network for Earthquake Engineering Simulation
• Earth System Grid
• Access Grid
• Science Environment for Ecological Knowledge
• Laboratory for the Ocean Observatory Knowledge
  Integration Grid
• Particle Physics Data Grid
• NAREGI
• Enabling Grids for e-Science (EGEE)
• Open Science Grid
• TeraGrid
• UK e-Science

6
Components
7
GT4 Security
Users
VO
8
GT4 Security
9
Data Management

• Discover, transfer, and access large data sets
• Stage large data sets to/from nodes and provide
  access to diverse data sources, file systems,
  parallel file systems, and hierarchical storage,
  GridFTP
• Replicate data for performance and reliability,
  RFT
• Locate data of interest, RLS
• Provide access to databases, OGSA-DAI

10
Execution Management

• Provision, deploy, and manage services
• Common WS interface to schedulers
• Unix, Condor, LSF, PBS, SGE,
• More generally interface for process execution
  management
• Lay down execution environment
• Stage data
• Monitor and manage lifecycle
• Kill it and clean up
• A basis for application-driven provisioning
• This is where WSRF and WS-N come in

11
Information Services

• Discover and monitor dynamic services
• Every service should be monitorable and
  discoverable using common mechanisms
• WSRF/WSN provides those mechanisms
• A common aggregator framework for collecting
  information from services, thus
• MDS-Index XPath queries, with caching
• MDS-Trigger perform action on condition
• MDS-Archiver XPath on historical data
• Deep integration with Globus containers
  services every GT4 service is discoverable
• GRAM, RFT, GridFTP, CAS,

12
GT4 In Action
13
Implementations

• Multiple implementations of the web services
  parts (WSRF, WSN)
• GT4-Java, Java
• GT4-C, C
• pyGridWare, Python
• WSRFLite, Perl
• WSRF.Net, C

14
Ecosystem

• MPICH-G2, MPI in the wide-area
• Nimrod-G, parameter studies
• Ninf-G, remote procedure calls
• Condor-G, reliable job submission
• Grid Resource Management System, metascheduler
• Open Grid Computing Environment, portal

15
Grid Canada
16
Grid Canada Drivers
LHC
17
Canadian Grid Groups

• Grid Research Centre at U Calgary
• Rob Simmonds, Brian Unger, c
• Grid Group at U Windsor
• Bob Kent, A.K. Aggarwal, c
• Atlas Canada
• Randy Sobie, U Victoria, Bryan Carron, U Alberta,
  Michel Vetterli, TRIUMF, c
• CRIM
• Pierre Duchoumel, c

• International Grid Testbed
• Bryan Carron, U Alberta, Wade Hong, Carleton U,
  c
• NRC Internal HPC Programme / Multi-Scale
  Modelling Project
• Roger Impey, c
• SPARRO at U Regina
• Edward Brash, c
• UQAM
• Omar Cherkaoui, c

18
Grid Canada

• Informational and consultative functions, a forum
  for interested parties
• www.gridcanada.ca
• giis.gridcanada.ca
• Information service, resources attached to the
  Grid Canada testbed and a production grid effort,
  Grid-X1
• www.gridcanada.ca/ca/
• Grid Canada Certificate Authority
• myproxy.gridcanada.ca
• Were looking at VO management

19
Grid CanadaCertificate Authority

• Issues certificates to users and resources
  involved in grid-related research in Canada
• Atlas Canada, NRC Grid, WestGrid, and anyone else
  who wants to talk to us (!)
• Certificates are used in the context of PKI as
  implemented by grid middleware such as Globus
• CA operations are (securely) housed at NRC with
  Ratilal Haria handling day-to-day certificate
  signing
• Process is documented in our CP/CPS
• http//www.gridcanada.ca/ca/
• Many legal issues side-stepped or not
  stipulated

20
GC CAIssued Certificates

• Around fifteen hundred issued certificates
• Mainly Westgrid users (!)
• Not all are active
• User and host certificates
• Some are revoked
• Many are expired
• Certificates expire after a year but can be
  renewed
• Weve been issuing certificates since April 2002

21
GC CAExternal Relations

• Trust between CAs about the processes which we
  follow
• Certificates from one CA are allowed to
  authenticate with those of another
• GC CA has trust relationships with all the CAs
  associated with the EU Grid PMA
• http//www.eugridpma.org/
• In response to the need for Canadian researchers
  to access international resources such as LCG
• GC CA is listed in the TERENA TACAR, a reliable
  repository

22
GC CA External Relations

• The Americas Grid Policy Management Authority
  (TAGPMA)
• Grid Canada, DOEGrids, FermiLab, c
• Main drivers are large projects such as OSG and
  Teragrid
• Canadian researchers will be able to access
  TeraGrid resources soon with GC certificates

23
GC CA External Relations

• Global Grid Forum, Certificate Authority
  Operations Working Group
• Documents, both finished and in the pipeline
• Deal with PMA issues as well as a publishing
  point
• www.ggf.org

24
GC CAExternal Relations

• International Grid Trust Federation
• Formed at the last GGF in Boston
• Regroups EUGridPMA, APGridPMA, and TAGPMA
• Allows for international trust to be established
• This represents 10s of thousands of users, and
  10s of thousands of resources

25
Questions?

• Contact me
• darcy.quesnel_at_canarie.ca
