Frequent Patterns I

• EECS435
• Fall 2005

2
Outline

• Introduction
• What is frequent pattern mining?
• What is association rule mining?
• Methods for association rule mining
• Extensions of frequent patterns

3
Introduction

• Topics
• Association Rule
• Sequential Patterns
• Graph Mining
• Clustering and Outlier Detection
• Classification and Prediction
• Regression
• Pattern Interestingness
• Dimensionality Reduction

4
Introduction

• Applications
• Bioinformatics
• Web mining
• Text mining
• Visualization
• Financial data analysis
• Intrusion detection

5
Introduction

• Data mining and KDD (SIGKDD CDROM)
• Conferences ACM-SIGKDD, IEEE-ICDM, SIAM-DM,
  PKDD, PAKDD, etc.
• Journal Data Mining and Knowledge Discovery, KDD
  Explorations
• Database systems (SIGMOD CD ROM)
• Conferences ACM-SIGMOD, ACM-PODS, VLDB,
  IEEE-ICDE, EDBT, ICDT, DASFAA
• Journals ACM-TODS, IEEE-TKDE, JIIS, J. ACM, etc.
• AI Machine Learning
• Conferences Machine learning (ICML), AAAI,
  IJCAI, COLT (Learning Theory), etc.
• Journals Machine Learning, Artificial
  Intelligence, etc.

6
Introduction

• Statistics
• Conferences Joint Stat. Meeting, etc.
• Journals Annals of statistics, etc.
• Bioinformatics
• Conferences ISMB, RECOMB, PSB, CSB, BIBE, etc.
• Journals J. of Computational Biology,
  Bioinformatics, etc.
• Visualization
• Conference proceedings CHI, ACM-SIGGraph, etc.
• Journals IEEE Trans. visualization and computer
  graphics, etc.

7
What Is Frequent Pattern Mining?

• Frequent patterns patterns (set of items,
  sequence, etc.) that occur frequently in a
  database AIS93
• Frequent pattern mining finding regularities in
  data
• What products were often purchased together?
• Beer and diapers?!
• What are the subsequent purchases after buying a
  car?
• Can we automatically profile customers?

8
Basics

• Itemset a set of items
• E.g., acma, c, m
• Support of itemsets
• Sup(acm)3
• Given min_sup3, acm is a frequent pattern
• Frequent pattern mining find all frequent
  patterns in a database

Transaction database TDB
9
Association Rules Mining A Road Map

• Boolean vs. quantitative associations
• age(x, 30..39) income(x, 42..48K) ? buys(x,
  car) 1, 75
• Single dimension vs. multiple dimensional
  associations
• Single level vs. multiple-level analysis
• What brands of beers are associated with what
  brands of diapers?

10
Extensions Applications

• Correlation, causality analysis mining
  interesting rules
• Maxpatterns and frequent closed itemsets
• Sequential patterns
• Periodic patterns
• Structural Patterns

11
Frequent Pattern Mining Methods

• Apriori and its variations/improvements
• Mining frequent-patterns without candidate
  generation
• Mining max-patterns and closed itemsets
• Mining multi-dimensional, multi-level frequent
  patterns with flexible support constraints
• Interestingness correlation and causality

12
Apriori Candidate Generation-and-test

• Any subset of a frequent itemset must be also
  frequent an anti-monotone property
• A transaction containing beer, diaper, nuts
  also contains beer, diaper
• beer, diaper, nuts is frequent ? beer, diaper
  must also be frequent
• No superset of any infrequent itemset should be
  generated or tested
• Many item combinations can be pruned

13
Apriori-based Mining

• Generate length (k1) candidate itemsets from
  length k frequent itemsets, and
• Test the candidates against DB

14
Apriori Algorithm

• A level-wise, candidate-generation-and-test
  approach (Agrawal Srikant 1994)

Data base D
1-candidates
Freq 1-itemsets
2-candidates
Scan D
Min_sup2
Counting
Freq 2-itemsets
3-candidates
Scan D
Scan D
Freq 3-itemsets
15
The Apriori Algorithm

• Ck Candidate itemset of size k
• Lk frequent itemset of size k
• L1 frequent 1-itemsets
• for (k 1 Lk !? k) do
• Ck1 candidates generated from Lk
• for each transaction t in database do increment
  the count of all candidates in Ck1 that are
  contained in t
• Lk1 candidates in Ck1 with min_support
• return ?k Lk

16
Important Details of Apriori

• How to generate candidates?
• Step 1 self-joining Lk
• Step 2 pruning
• How to count supports of candidates?

17
How to Generate Candidates?

• Suppose the items in Lk-1 are listed in an order
• Step 1 self-join Lk-1
• INSERT INTO Ck
• SELECT p.item1, p.item2, , p.itemk-1, q.itemk-1
• FROM Lk-1 p, Lk-1 q
• WHERE p.item1q.item1, , p.itemk-2q.itemk-2,
  p.itemk-1 lt q.itemk-1
• Step 2 pruning
• For each itemset c in Ck do
• For each (k-1)-subsets s of c do if (s is not in
  Lk-1) then delete c from Ck

18
Example of Candidate-generation

• L3abc, abd, acd, ace, bcd
• Self-joining L3L3
• abcd from abc and abd
• acde from acd and ace
• Pruning
• acde is removed because ade is not in L3
• C4abcd

19
How to Count Supports of Candidates?

• Why counting supports of candidates is a problem?
• The total number of candidates can be very huge
• One transaction may contain many candidates
• Method
• Candidate itemsets are stored in a hash-tree
• Leaf node of hash-tree contains a list of
  itemsets and counts
• Interior node contains a hash table
• Subset function finds all candidates contained
  in a transaction

20
Challenges of Frequent Pattern Mining

• Challenges
• Multiple scans of transaction database
• Huge number of candidates
• Tedious work of support counting for candidates
• Improving Apriori general ideas
• Reduce number of transaction database scans
• Shrink number of candidates
• Facilitate support counting of candidates

21
DIC Reduce Number of Scans
ABCD

• Once both A and D are determined frequent, the
  counting of AD can begin
• Once all length-2 subsets of BCD are determined
  frequent, the counting of BCD can begin

ABC
ABD
ACD
BCD
AB
AC
BC
AD
BD
CD
Transactions
B
C
D
A
Apriori

Itemset lattice
2-items
S. Brin R. Motwani, J. Ullman, and S. Tsur, 1997.
3-items
DIC
22
DHP Reduce the Number of Candidates

• A hashing bucket count ltmin_sup ? every candidate
  in the buck is infrequent
• Candidates a, b, c, d, e
• Hash entries ab, ad, ae bd, be, de
• Large 1-itemset a, b, d, e
• The sum of counts of ab, ad, ae lt min_sup ? ab
  should not be a candidate 2-itemset
• J. Park, M. Chen, and P. Yu, 1995

23
Partition Scan Database Only Twice (Distributed
Computing)

• Partition the database into n partitions
• Itemset X is frequent ? X frequent in at least
  one partition
• Scan 1 partition database and find local
  frequent patterns
• Scan 2 consolidate global frequent patterns
• A. Savasere, E. Omiecinski, and S. Navathe, 1995

24
Sampling for Frequent Patterns

• Select a sample of original database, mine
  frequent patterns within sample using Apriori
• Scan database once to verify frequent itemsets
  found in sample, only borders of closure of
  frequent patterns are checked
• Example check abcd instead of ab, ac, , etc.
• Scan database again to find missed frequent
  patterns
• H. Toivonen, 1996
