Microsoft Healthcare Solutions

1
Microsoft Healthcare Solutions

• Veli BIÇER

2
Agenda

• Components of the Healthcare Ecosystem
• The challenges
• Integration
• SharePoint Services
• BizTalk Server 2004
• BizTalk Accelerator for HIPAA
• BizTalk Accelerator for HL7

3
Components of the Healthcare Ecosystem

• Provider organizations and physicians
  delivering healthcare
• Pharmaceutical and medical device companies
  creating drugs and medical devices
• Government and private-sector employers paying
  for most healthcare
• Health insurers managing financial and
  administrative transactions
• Consumers receiving, and helping pay for,
  health services

4
The challenges

• The problem with the current healthcare ecosystem
  is Integration.
• Open standards such as XML, SOAP, UDDI, WSDL, and
  healthcare-specific standards such as HIPAA, HL7
  are key to handle integration problem.
• The administration costs in US is about 90
  billion per year, which may be reduced to 5
  billion according to Microsoft.

5
Integration

• Presentation Tier Using portals and applications
  which can work on mobile devices such as Tablet
  PC as well as desktop computers.
• Middle Tier Enterprise Application Integration.
• Data Layer Communication with legacy systems as
  well as DBMSs.

6
Integration
Logical Architecture
7
Integration
Physical Architecture
8
InfoPath

• Streamlines the process of gathering, using and
  sharing information through electronic business
  forms.
• Design forms based on a schema, database, or a
  web service and publish the manifest to a portal,
  FTP, or shared folder.
• Share the XML messages with the reference to a
  published URL.
• Further Information http//msdn.microsoft.com/off
  ice/understanding/infopath/default.aspx

9
InfoPath
10
SharePoint Services

• A portal server which can be customized according
  to the need.
• Includes security and integration capabilities.
• Acts as a library of the clinical forms in a
  healthcare system.
• Patients and healthcare professionals can access
  information through the portal.

11
SharePoint Services
12
BizTalk Server 2004

• Serves as a business process orchestration hub.
• Work with adapters and accelerators for
  communication. E.g. EDI, Legacy Systems, HTTP,
  FTP, SOAP, SQL Server and HL7 Minimal Lower Layer
  Protocol (MLLP).
• Export BPEL files.
• Mapping tool to map XML documents.

13
BizTalk Server 2004

• .NET Integration
• Pipelines to parse, serialize, decode, encode,
  (dis)assemble and validate incoming and outgoing
  messages, respectively.
• BizTalk Web Services by binding logical ports to
  Web Service definitions.

14
BizTalk Server 2004
Schema Editor
15
BizTalk Server 2004

• BizTalk Server Mapper enables XSLT-based mapping.

16
BizTalk Server 2004
Pipeline
17
BizTalk Server 2004
Orchestration Designer
18
BizTalk Server 2004
19
BizTalk Accelerator for HIPAA

• enables healthcare organizations to implement
  solutions that process the X12N EDI transactions
  adopted under HIPAA.
• Includes schemas for X12N transaction sets
  provided by WPC.
• A HIPAA-specific parser to process and validate
  HIPAA-compliant EDI messages.

20
BizTalk Accelerator for HIPAA
Batch documents are processed with MSMQ
21
BizTalk Accelerator for HIPAA
22
BizTalk Accelerator for HL7

• A comprehensive HL7 messaging solution for
  healthcare to leverage Enterprise Application
  Integration (EAI).
• Enables BizTalk Server 2004 to communicate with
  Clinical Information Systems which are
  HL7-conformant applications.
• Just an HL7 implementation.

23
BizTalk Accelerator for HL7
HL7 Models
24
BizTalk Accelerator for HL7

• Trigger events and application roles.
• Provides XML schema definitions for HL7 v2.x
  trigger events.
• HL7 defines two acknowledgement modes Original
  and enhanced both of which are supported by BT
  Acc. for HL7.

25
BizTalk Accelerator for HL7

• HL7 Message Types
• Provides the XML schema definitions for HL7 v2.x
  Message Types.
• Provides the disassembler and assembler to parse
  and serialize the HL7 messages using BizTalk
  pipelines.
• Implements HL7 validation rules for messages as
  Business Rules.

26
BizTalk Accelerator for HL7
27
BizTalk Accelerator for HL7

• A HL7 v2.3 Message

28
BizTalk Accelerator for HL7
29
BizTalk Accelerator for HL7

• HL7 batch protocols provides the messages in
  following segments
• FHSBHS . BTSFTS
• Process HL7 batch message protocols, create batch
  from individual messages, or split a batch.

30
BizTalk Accelerator for HL7

• Provides a configurable adapter for HL7 Minimal
  Lower Layer Protocol (MLLP) on TCP/IP to connect
  to the HL7-conformant application directly.

31
BizTalk Accelerator for HL7
32
BizTalk Accelerator for HL7
HL7 Accelerator Overview
33
Resources

• Microsoft Healthcare http//www.microsoft.com/heal
  thcare
• Microsoft BizTalk Server http//www.microsoft.com/
  biztalk
• Health Level Seven http//www.hl7.org
• HIPAA http//aspe.hhs.gov/admnsimp/index.shtml

34
Thanks for your attention
