By: Audella Eid

1
Constructed Wetlands for Wastewater treatment
By Audella Eid Advisor Dr. R. Zurayk
2
What are constructed wetlands ?

• CW are complex, integrated systems in which
  water, plants, microorganisms, and the
  environment all interact to improve water
  quality.
• CW have been used in Europe since the 1960s.

3
Usage of CW

• Municipal wastewater treatment
• Acid mine drainage
• Agricultural point and non-point discharges
• Storm water treatment

4
Important Characteristics of CW

• Inexpensive
• Low-maintenance
• Easy operation
• High removal efficiencies under various temp, pH,
  hydraulic and biological loading rates.

5
Types of CW

• Free-water surface (FWS) wetland

• Subsurface Flow (SF) wetland

6
Free-water surface (FWS)

• Are earthen basins or channels filled with
  shallow water and emergent vegetation.
• Wastewater is exposed to the atmosphere.
• Recommended for lower strength wastewater,
  stormwater treatment or where nitrogen removal is
  required.

7
Subsurface Flow wetland (SF)

• Is composed of a cement cell filled with a
  porous media such as rock or gravel.
• Wastewater percolated through a porous medium
  that supports the root system of the vegetation.
• Water flows below the porous surface and is not
  exposed to the environment.

8
SF ( contd)

• Recommended for residential homes, schools and
  other areas where the exposed wastewater
  treatment site may not be suitable.
• Decrease chance of exposure, odor and insect
  vectors.

9
(No Transcript)
10
Treatment of wastewater

• CW treat wastewater using the following
  processes
• Filtration
• Sedimentation
• Physical or chemical immobilization
• Chemical and biological decomposition
• Absorption and assimilation of excess nutrient
  by plants

11

• In each of the two systems march plants aid in
• the treatment of water by improving conditions
  for the microorganisms living in the cells.
• and by acting as a filter to absorb some trace
  metals.

12
How do they operate?

• Plants and microorganisms play a key function in
  the cleaning of the wastewater.
• Plant roots transpire oxygen and thus aerate the
  water.

13
How do they operate?(contd1 )

• Large populations of aerobic and anaerobic
  bacteria grow within the rhizosphere (which is
  the small area surrounding the root zone).
• These microbes are the primary source of
  treatment, breaking down the complex dissolved
  organic and nutrient pollutants into simpler
  forms that the plants use as food.

14
How do they operate?(contd2)

• Aerobic conditions in the root zones of the
  plants also facilitates growth of large
  microorganisms (protozoa) that are essential to
  the removal of bacteria, such as fecal coliforms.
• The most common plant used for subsurface flow is
  the common reed (Phragmites australis).

15
The Gharzouz experience
16
The Gharzouz Reed Bed

• The choice of using a constructed wetland for
  wastewater treatment was based on
• environmental feasibility
• social acceptance
• economic feasibility
• previous removal efficiencies

17
Environmental feasibility

• The place is relatively isolated with a lot of
  land around it and a large area for the wetland
  construction.
• The possibility of using the effluent in
  irrigating of the olive and other trees that is
  present in the area.

18
(No Transcript)
19
Social acceptance

• The community is a relatively very small
  ranging from 15 to 50 people at different times.
• They accepted the implication of this technique

20
Economic feasibility

• The budget available for wastewater treatment is
  not very high.
• The difference in costs between construction of
  a wetland and using a mechanical method.

21
Previous removal efficiency

• Previous studies that showed high reduction
  rates of BOD , SS and nitrates.
• The previous pilot tests that were done on this
  system (in AUB and other places in Lebanon) and
  proved to be efficient in reducing BOD and other
  measures.

22
Characteristics of the gravel bed
t VPorosity of the gravel bed (assumed to be
35)/Q BOD loading rate Co(avg)Q /A
23
(No Transcript)
24
MONITORING
25
Methodology

• 15 samples of wastewater were collected from
  June 1999 till March 2000.
• Analysis was carried out using standard method
  for COD, BOD, TSS, TDS, Nitrates, Ammonia,
  Phosphates, Sulfates, conductivity, pH, Fecal
  coliforms, Total Coliforms

26
(No Transcript)
27
RESULTS AND DISCUSSION
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Comparison of the percent removal rates between
previous studies and the current one
37
Comparison between typical performance data and
Gharzouz data
38
LIMITATIONS AND CONCERNS
39
Limitations

• Large land area requirements.
• Lack of a consensus on design specifications.
• Long term effectiveness is not known. Wetland
  aging may contribute to a decrease in contaminant
  removal rates over time.

40
Limitations (Contd)

• When metals are key contaminant, CW do not
  destroy them but only restrict their mobility.
• Performance may be more variable and less
  predictable than other treatment methods.

41
COSTS
42
COSTS
43
CONCLUSION
The Gharzouz experience indicates that CW may be
an appropriate, low-cost alternative for small
rural communities!
