THE AVIATION WEATHER PROGRAM AT THE AVIATION WEATHER CENTER

1
AVIATION WEATHER CENTER NATIONAL CENTERS FOR
ENVIRONMENTAL PREDICTION
THE AVIATION WEATHER PROGRAM AT THE AVIATION
WEATHER CENTER GULF OF MEXICO WORKING GROUP
MEETING FEBRUARY 1, 2000 HOUSTON, TX
N C E P
WHERE AMERICAS CLIMATE AND WEATHER SERVICES BEGIN
2
OPERATIONS BRANCH Vision Transition to future
enroute forecasting activities and
products. Current formats may be sustained until
customers modernize
Current Forecaster Role

• Alphanumeric messages - turbulence, icing,
  convection, ceiling/visibility SIGMETs,
  Convective SIGMETs, AIRMETs, Area Forecasts
• Graphic depiction of SIGWX - fronts, jets,
  convection, freezing levels, etc
• Global High Level SIGWX forecasts, Low Level
  SIGWX forecasts

Future Forecaster Role

• Near Term
• Graphic Products
• Enhanced Global SIGWX

• Long Term
• Gridded Products
• Gridded TAF Guidance

Major Efforts

• Training of 36 forecasters in advanced systems,
  forecast generation techniques and new science
• Transition to Team Forecast Process

3
(No Transcript)
4
3 Forecasters issue Area Forecasts, AIRMETS,
SIGMETS
5
MWO KKCI
MWO KKCI
FACA Responsibility Outlined in Red
MWO KKCI
MWO KKCI
MWO KKCI
Figure 1 MWO Areas of Responsibility for AWC
listed as KKCI, FACA Area Outlined in Red
6
MWO KKCI
MWO KKCI
Figure 2 MWO Area of Responsibility for AWC
7
OFAGX
Figure 3 OFAGX Responsibility for AWC
8
MIA FA
DFW FA
FACA
OFAGX
Figure 5 A comparison of the Domestic Area
Forecast Areas, the OFAGX and the FACA
9
TODAYS FORECASTER PROCESS

• Individual Ownership Of A Product
• Single Alphanumeric Bulletins
• Minimum Of Coordination And Interaction With
  Other Forecasters During Analytical Phase Of
  Production
• Leads To Inefficiencies In Process
• Same Analytical Tasks Accomplished
• Redundant Composition And Distribution
• Individual Nature Of Products
• Potential For Large Differences In Description Of
  Attributes From Product To Product
• Differences Lead To Misinterpretation

10
TODAYS FORECASTER PROCESS continued

• INDIVIDUAL NATURE OF FORECAST PROCESS DOES NOT
  FIT INTO THIS ERA OF SHRINKING RESOURCES AND
  INCREASING DEMANDS FOR HIGHER ACCURACY AND
  RESOLUTION

11
GOAL AT THE AWC

• Generate Products Collaboratively And
• Eliminate Inefficiencies In Production
• Eliminate Inconsistencies In Products

12
ICAO AREAS TO BE DONE BY UNITED STATES
1998
1999
ADDITIONALLY, TWO PS OVER THE NORTH POLE, ONE PS
OVER THE SOUTH POLE
13
Figure 6 ICAO Mercator charts prepared four
times a day by the AWC Global Graphics Unit
14
Figure 7 ICAO Polar Stereographic Areas prepared
by the Global Graphic Unit
15
Figure 8 ICAO Area J prepared by the Global
Graphics Unit
16
EXAMPLE OF HIGH LEVEL SIGNIFICANT WX CHART
17
EXAMPLE OF A LOW LEVEL SIGNIFICANT WX CHART
18
3 Forecasters issue Area Forecasts, AIRMETS,
SIGMETS
19
AIRMET SIERRA UPDT 3 FOR IFR AND MTN OBSCN VALID
UNTIL 072100 . AIRMET IFR...TX FROM ADM TO TXK TO
PSX TO BRO TO 80W BRO TO LRD TO SJT TO ADM OCNL
CIGS/VIS BLW OVC010/3SM IN CLDS..PCPN AND BR.
CONDS CONTG BYD 21Z THRU 03Z. .
20

• Forecasters Historically Had Been Able To
  Coordinate Descriptions Of Weather Phenomena
  Along Predetermined Geographical Boundaries
• New Work Could Not Add Significant Production
  Time With Resolution Of Inconsistencies And
  Assimilation Of Work Produced By The
  Hydrometeorological Prediction Center
• Issuance Of Final Products For Facsimile
  Transmission Had To Be Transparent To User

21
THREE FORECASTERS AND THE HPC INVOLVED IN
FORECAST PRODUCTION
1
2
3
4
5
22
LOW LEVEL CHART AS SHIPPED TO USER
23

• Weather Production Inefficiencies And
  Inconsistencies In Products Used For Air
  Traffic Management Decisions Often Compound
  Operational Problems
• Thunderstorms Represent The Single Most
  Disruptive Weather Phenomenon In The
  Operations Of The National Airspace System
• Forecasts Of Thunderstorms Produced Must Have
  A High Degree Of Consistency Among Producers To
  Limit The Degree Of Uncertainty Among Users As
  To Key Decision Factors

24

• FAA Asked AWC To Become The Focus For A
  Collaborative Convective Forecast Product To
  Be Used In Strategic Routing And Scheduling
  Decisions
• Up To 25 Government And Airline Forecasts
  Could Be Used To Produce A Cohesive Product
• Telephone Or Video Conference Ruled Out As
  Unacceptable Since
• Typically Chaotic
• Difficult To Document
• Imperfect Understanding Where Highly
  Technical Subjects Are Considered

25
Collaborative Convective Forecast Product
26
(No Transcript)
27

• Final Report Reflects Success Of
  Collaboration Even Though There Was No Marked
  Improvement In Accuracy Of The Forecasts
• FAA Indicates The Perceptions Of Success Had
  More To Do With Consistency Of Products With
  All Players Buying Into Final Solution

28
LOW LEVEL SIGNIFICANT WX CHART PRODUCED BY AAWU
HIGH LEVEL SIGNIFICANT WX CHART PRODUCED BY AWC
29

• Increased Productivity At The AWC
• Much Wider Application As Capabilities Are
  Enhanced
• Internet Technology Is Very Viable For
  Collaborative And Consensus Based Weather
  Information Products
• AWC Expects To Revolutionize Its Production
  Capability Over The Next Few Years
• Sufficient Investment Is A Necessity For
  Further Development Of Technology And Its
  Applications

30
AWC Home Page Soon to be merged with ADDS
31
Meteorological Impact Statement (MIS) 31 Jan 2000
- 131031 UTC Houston ARTCC (KZHU) ZHU MIS 01
VALID 311305-312115 ...FOR ATC PLANNING
PURPOSES ONLY... ZHU AND ADJ CSTL WTRS
OCNL LGT-MDT TURBC ABV FL200 BYD 21Z DUE TO
JTSTR. OCNL LGT-MDT RIME/MXD ICGIC 150-FL300 BYD
21Z. ZHU E LRD-SJI LN/ADJ CSTL WTRS ISOLD-WDLY
SCT SHRA BYD 21Z. VRBL-LTL MOVMT TX PTN/MOVG EWD
30-40KTS LA-AL PTN. TOPS 100-FL200. MORE NMRS
ALG EXTRM CST AND OVR CSTL WTRS. ZHU
GLFMEX ISOLD-WDLY SCT TS/SHRA PSBL BYD 21Z. MAX
TOPS FL350-450. MOVG EWD 30-40KTS. DW
Meteorological Impact Statement
32
Product Distribution 1. IFFDP
33
Communications AWC.to.CUSTOMER
AWC
END USER
DELIVERY
Production
Fax Back
24 HOUR HELP Desk
Product
877 Toll Free Service
34
Product Distribution 2. INTERNET
IMPROVING AND MERGING
35
Cooperative roles of operations and research
Products
Research

• FSL
• NCAR
• Universities
• Lincoln Labs
• FAA Tech Center

• Clients
• FAA Ops.
• Air Transportation
• Regional
• Business
• General Aviation

User Feedback
36
FAA Testbed Year 2000 Activities

• Installation of New Data Ingest and Product
  Development System with Redundancy.
• Establish Experimental Phase for IIFA, VVSTORM,
  and other programs.
• Work from Experimental towards Guidance Phase
  with IIDA, NCWF, ITFA, and MWAVE.
• New Displays and Grib Files available on the
  Internet.

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
