Virtualization Tech

1
Virtualization Tech

• Guangdeng Liao
• UCR

2
Outline

• What is Virtualization
• Why need virtualization
• Virtualization today
• Xen Overview
• Xen Network IO
• State of the art
• Research Roadmap?

3
Virtualization

• Virtualization is a framework or methodology of
  dividing the resources of a computer into
  multiple execution environments,
• Done by applying one or more concepts or
  technologies such as
• hardware and software partitioning,
• time-sharing,
• partial or complete machine simulation,
• emulation,
• quality of service,
• and many others.
• Virtualization is an abstraction layer that
  decouples the physical hardware from the
  operating system to deliver greater IT resource
  utilization and flexibility.
  www.vmware.com

4
Virtualization
5
Why Virtualization in the Enterprise

• Consolidate under-utilized servers to reduce
  CapEx and OpEx

X

• Avoid downtime with VM Relocation

• Dynamically re-balance workload to guarantee
  application SLAs

X

• Enforce security policy

6
Why virtualization for U

• Test patches or modification to OS or server
  configurations
• Used to run non trustworthy applications
• Running Windows, Linux, Mac in one machine
• Accelerated application deployment
• Using pre-configured virtual machines

7
Virtualization today

• Single OS image Virtuozzo, Vservers, Zones
• Group user processes into resource containers
• Hard to get strong isolation
• Full virtualization VMware, VirtuaPC, QEMU
• Run multiple unmodified guest OSes
• Hard to efficiently virtualize x86
• Para-virtualization UML, Xen
• Run multiple guest OSes ported to special arch
• Arch Xen/x86 is very close to normal x86

8
Xen Overview

• Xen is a virtual machine monitor for x86 that
  supports execution of multiple guest operating
  systems with unprecedented levels of performance
  and resource isolation. It is a
  para-virtualization technology.
• Only guest kernel needs to be ported
• All user-level apps and libraries run unmodified
• Linux 2.4/2.6, NetBSD, FreeBSD, Plan9
• Execution performance is close to native
• Based on Intel-VT, Xen supported full
  virtualization.

9
Xen 2.0 Architecture
10
Xen 3.0 Architecture
VM3
VM0
VM1
VM2
Device Manager Control s/w
Unmodified User Software
Unmodified User Software
Unmodified User Software
GuestOS (XenLinux)
GuestOS (XenLinux)
GuestOS (XenLinux)
Unmodified GuestOS (WinXP))
AGP ACPI PCI
Back-End
SMP
Native Device Drivers
Front-End Device Drivers
Front-End Device Drivers
Front-End Device Drivers
VT-x
x86_32 x86_64 IA64
Event Channel
Virtual MMU
Virtual CPU
Control IF
Safe HW IF
Xen Virtual Machine Monitor
Hardware (SMP, MMU, physical memory, Ethernet,
SCSI/IDE)
11
Xen Network IO

• Xen Network IO architecture

12
Network IO

• How to Send packet?
• Network protocol stack in guest OS
• Virtual Network interface ( Front-end driver)
• IO channel to Backend Driver
• Page flipping technology without data copy
• Deliver packet to Bridge and Real NIC driver
• Initialize DMA
• DMA data transfer
• Completion notification through interrupt

13
Network IO

• How to Receive Packet?
• Interrupt to VMM through NIC
• DMA data transfer
• Driver and bridge manages packets information
• VMM signal the specified guest OS
• Backend to Front-end through IO channel
• Go up to Guest OS network stack

14
Networking micro-benchmark

• One streaming TCP connection per NIC (up to 4)

• Driver receive throughput 75 of Linux throughput
• Guest throughput 1/3rd to 1/5th of Linux
  throughput

15
Receive Xen Driver overhead

• Profiling shows slower instruction execution with
  Xen Driver than w/Linux (both use 100 CPU)
• Data TLB miss count 13 times higher
• Instruction TLB miss count 17 times higher
• Xen 11 more instructions per byte transferred
  (Xen virtual interrupts, driver hypercall)

16
Receive Xen Guest overhead

• Xen Guest configuration executes two times as
  many instructions as Xen Driver configuration
• Driver domain (38) overhead of bridging
• Xen (27) overhead of page remapping

17
Transmit Xen Guest overhead

• Xen Guest executes 6 times as many instructions
  as Xen driver configuration
• Factor of 2 as in Receive case
• Guest instructions increase 2.7 times
• Virtual NIC (vif2) in guest does not support
  TCP offload capabilities of NIC

18
Why downgrade?

• Lower bandwidth Higher Latency
• VMM involvement brings more system overhead(
  Domain switch, Inter-Domain communication cost,
  system management etc)
• Virtual NIC does not support some offload
  capabilities of Real NIC etc

19
Virtualization IO State of the Art

• Architecture side
• Concurrent direct access to NIC from Guest OS
  (Rice University)
• Needs NICs support with multi-context
• Still needs the involvement of VMM
• Bypass VMM just like bypass OS tech, How?
• IOMMU support from Hardware, which offers
  translation and protection function in hardware.
  Both AMD and Intel will support it soon.
• Does not support multi-domain direct access to IO
  device?

20
Virtualization IO State of the Art

• System side
• Optimize IO channel
• Optimize Receive path
• Optimize transmit path
• Virtual Memory optimization

21
Are they enough?

• What can we do?
• Performance evaluation of XEN, XEN with Intel-VT
  and the coming Intel IOMMU technology.
• Domain 0 and VMM on-loading on multi-core?
• Optimize Cache
• Optimize Instruction Set
• Integrated NIC to CPU?
• Floorplan How to place NIC on multi-core die?
  Performance Power Concern
• Like TOE, not only bypass VMM but also OS?
• NIC supports concurrent direct access from guest
  OS?
• Use polling instead of interrupt?

22
QA

• Thanks

23
Reference

• Optimization Network virtualization in Xen
• Virtualization and Virtual machines Tom Gianos
• Xen and the art of virtualization Ian Pratt
• Diagnosing Performance Overhead in the Xen
  Virtual Machine Environment Aravind Menon
• Integrated Network Interfaces for High-Bandwidth
  TCP/IP Nathan L. Binkert
• Design and Evaluation of Network Interfaces for
  SAN
