Inferring Locks for Atomic Sections

1
Inferring Locks for Atomic Sections
Sigmund Cherem
Trishul Chilimbi
Sumit Gulwani
Cornell University (summer intern at Microsoft
Research)
Microsoft Research
Microsoft Research
2
What Is This Talk About?

• Multi-cores widely available
• Developing concurrent software is not trivial
• Many challenges parallelization, synch.,
  isolation
• Manual locking is error prone, non compositional
• Recent proposal atomic sections
• Raising the level of abstraction, is
  compositional
• Optimistic (transactions) implementations
• Herlihy, Moss ISCA93 Hammond et al. ISCA04
  Shavit, Touitou PDC95 Dice et al. DISC06
  Fraser, Harris TOPLAS07
• Limitations non-reversible ops, overhead
• This talk compiler support for atomic sections
  via pessimistic concurrency

3
Static Lock Inference Framework

• Compiler support for atomic sections based on
  pessimistic concurrency
• Prevent conflicts using locks, no deadlocks
• Goal reduce contention while avoiding deadlocks

Lock Inference Compiler
Concurrent program with atomic sections (runs on
STM)
Same program with locks for implementing atomic
sections

• Specifies where, but not how

• Lightweight runtime support (locking library)

• Automatically supports non-reversible ops.

4
Moving List Elements
move (list to, list from) atomic elem
x to-gthead elem y from-gthead
from-gthead null while (x-gtnext !
null) x x-gtnext x-gtnext y

to
from
head
head
x
y
5
Moving List Elements
move (list to, list from) atomic elem
x to-gthead elem y from-gthead
from-gthead null while (x-gtnext !
null) x x-gtnext x-gtnext y

to
from
head
x
y
6
Attempt 1 Global Lock
move (list to, list from) elem x
to-gthead elem y from-gthead
from-gthead null while (x-gtnext !
null) x x-gtnext x-gtnext y

to
from
acquire( GLOBAL )
head
x
y
Global lock protects entire memory
Problem with Attempt 1 No parallelism with any
other atomic sections
release( GLOBAL )
7
Attempt 2 Fine-Grain Locks
move (list to, list from) elem x
to-gthead elem y from-gthead
from-gthead null while (x-gtnext !
null) x x-gtnext x-gtnext y
releaseAll()
to
from
acquire( (to-gthead) )
head
acquire( (from-gthead) )
x
y

acquire( (x-gtnext) )
acquire( (x-gtnext) )
8
Attempt 2 Fine-Grain Locks
move (list to, list from) elem x
to-gthead elem y from-gthead
from-gthead null while (x-gtnext !
null) x x-gtnext x-gtnext
y releaseAll()
to
from
acquire( (to-gthead) )
head
acquire( (from-gthead) )
x
y
Problem with Attempt 2 may lead to deadlock
acquire( (x-gtnext) )
acq((a-gthead) ) // deadlock here acq((b-gthead
) )
acquire( (x-gtnext) )
acq((b-gthead) ) acq((a-gthead) )
9
Attempt 3 Fine-Grain Locks at Entry
move (list to, list from) while
(x-gtnext ! null) x x-gtnext
x-gtnext y releaseAll()
to
from
acquireAll( )
acquire( (to-gthead) )
elem x to-gthead
head
acquire( (from-gthead) )
elem y from-gthead
from-gthead null
x
y

acquire( (x-gtnext) )
Challenge 1 Protect locations ahead of time (at
entry of atomic), i.e., find which addresses will
be used inside atomic
acquire( (x-gtnext) )
10
Protect when Entering Atomic Block

• Find corresponding expressions
• Acquire a lock for each shared location
  accessed within the atomic section, expressed in
  terms of expressions valid at the entry of the
  atomic block

atomic list x y5 list d x
d-gthead NULL
acquire( (y5-gthead) )
acquire( (x-gthead) )
acquire( (d-gthead) )
Contribution 1 Identifying appropriate
fine-grain locks at entry (via inter-procedural
backward data-flow analysis)
11
Attempt 3 Fine-Grain at Entry
move (list to, list from) acquireAll(
) elem x to-gthead
elem y from-gthead from-gthead null
while (x-gtnext ! null) x
x-gtnext x-gtnext y releaseAll()
to
from
(to-gthead)
(from-gthead)
head
(to-gthead-gtnext)
head
Problem with Attempt 3 Cant protect unbounded
number of locations
12
Attempt 4 Multi-Grain Locks at Entry
move (list to, list from) acquireAll(
) elem x to-gthead
elem y from-gthead from-gthead null
while (x-gtnext ! null) x
x-gtnext x-gtnext y releaseAll()
to
from
head
head
Challenge 2 Mixing locks of multiple
granularities while avoiding deadlocks
13
Defining Multi-Grain Locks

• A fine-grain lock protects a single location
• A coarse-grain lock protects a set of locations
• Any traditional heap abstraction can be used to
  define coarse-grain locks
• E.g. types, points-to sets, shape abstractions
• Our compiler framework is parameterized
• Clients can specify the kind locks they want to
  use

14
Mixing Locks of Multiple Granularities
Memory locations

• Borrow Databases locking protocol based on
  intention locks Gray 76

Global lock
Coarse-grain locks
Fine-grain locks
Contribution 2 We allow mixing locks of
multiple granularities and avoid deadlocks
15
Soundness Results

• Sound locking structure provided
• Protected by child is alsoprotected by parent
• Map of expressions to locks
• Bounded (for termination)
• Soundness Theorem
• Compiler chooses set of locks protecting all
  memory accesses within atomic block

(-gtnext)
(to-gthead-gtnext)
(to-gthead-gtnext-gtnext)
Contribution 3 Framework is sound (for any
sound lock structure instantiation)
16
Experimental Evaluation

• Lock structure instance 3-level locks effects
• Experiments
• Concurrent data-structures rb-tree, hashtable
• Concurrent get (read-only), put, and remove
  operations
• 1.86Gz Intel Xeon dual-quad core machine

Global lock
rw
Points-to set locks Steensgards 96
ro
rw

Expression locks (limited in size)
ro
17
Scalability Results
70 60 50 40 30 20 10 0
Execution time (sec)
1 2 3 4 5 6
7 8
Number of threads
18
TH (rb-tree hash w/rehash) 80 gets
70 60 50 40 30 20 10 0
Global lock (exclusive) doesnt scale
Execution time (sec)
Scalability comparable to STM
Compiler didnt use fine-grain locks
1 2 3 4 5 6
7 8
Number of threads
19
TH (rb-tree hash w/rehash) 80 puts
High contention from re-hashing degrades STM
performance
70 60 50 40 30 20 10 0
Execution time (sec)
2 coarse-grain (exclusive) locks are better than
a single global lock
1 2 3 4 5 6
7 8
Number of threads
20
simple-hashtable 80 gets
45 40 35 30 25 20 15 10 5 0
Compiler didnt use fine-grain locks for gets
Execution time (sec)
STM allows put and get concurrently
1 2 3 4 5 6
7 8
Number of threads
21
simple-hashtable 80 puts
45 40 35 30 25 20 15 10 5 0
Compiler uses fine-grain locks for puts
Execution time (sec)
1 2 3 4 5 6
7 8
Number of threads
22
Differences with Recent Work

• No programmer annotations (other than atomic)
• Autolocker McCloskey et al POPL06 requires
  programmer annotations to choose appropriate
  granularity
• Moving fine-grain lock acquisitions to entry of
  atomic
• Acquiring fine-grain locks right before first use
  Hindman, Grossman MSPC06 is not fully
  pessimistic
• may generate deadlocks and need rollbacks
• Multi-grain locks without deadlocks
• Several pessimistic approaches use coarse-grained
  locks only Hicks et al 06 Halpert et al. 07
  Emmi et al.07

23
Conclusions and Future Work

• Lock inference framework for atomic sections
• Multi-grain locks to reduce contention and avoid
  deadlocks
• Soundness accesses are protected, atomicity
  preserved
• Validation resulting performance depends on
  application
• Locks preferable for non-reversible ops. or
  high-contention
• Future directions
• Better locking hierarchy instantiations (e.g.
  ownership)
• Optimizations (e.g. delay lock acquisitions)
• Hybrid systems (e.g. compiler support to optimize
  STMs)
