Virtual Memory

1
Virtual Memory

• Matt Evett
• Dept. Computer Science
• Eastern Michigan University

2
Virtual Memory Topics

• Demand Paging
• Performance of Demand Paging
• Page Replacement
• Page-Replacement Algorithms
• Allocation of Frames
• Thrashing
• Other Considerations
• Demand Segmenation

3
Background

• Virtual memory separation of user logical
  memory from physical memory.
• Only part of the program needs to be in memory
  for execution.
• Logical address space can therefore be much
  larger than physical address space.
• Need to allow pages to be swapped in and out.
• Virtual memory can be implemented via
• Demand paging
• Demand segmentation

4
Demand Paging

• Bring a page into memory only when it is needed.
• Similar to simple paging, but uses a lazy
  swapper to bring in pages only as needed
• Less I/O and memory than simple paging
• Faster response (dont have to swap entire proc.)
• Fewer pages/proc ? More users
• Page request reference to it
• invalid reference ? abort
• not-in-memory ? bring to memory

5
Valid-Invalid Bit

• With each page table entry a validinvalid bit is
  associated(1 ? in-memory, 0 ? not-in-memory)
• recall from simple paging scheme.
• Initially the bit is set to 0 on all entries.
• Ex. snapshot of a page table
• During address translation, if validinvalid bit
  in page table entry is 0 ? page fault.

6
Swapper Page Fault

• Invalid reference ? OS trap, page fault
• OS looks at another table to differentiate...
• If truly invalid (illegal address) ? abort
• Else, refd page is in swap space
• Get empty frame (may need swap out)
• Swap page into frame
• Could handle another proc while waiting.
• Reset tables, validation bit 1.
• Restart instruction

7
Potential Problems During Swap

• Restarting a partially executed instruction
• Block operations span blocks of memory, perhaps
  across page boundaries. How to deal with a
  partial move at page fault?
• MOV (A2), -(A3) auto increment/decrement can
  be partial at time of page fault (A2 and A3 are
  address registers)

8
What happens if there is no free frame?

• Page replacement find a page in memory
  (resident), but not really in use, swap it out.
• But which page?
• There are many algorithms
• performance want an algorithm which will
  minimize number of page faults.
• Same page may be brought into memory several
  times.

9
Performance of Demand Paging

• Page Fault Rate 0 ? p ? 1.0
• if p 0 no page faults
• if p 1, every reference is a fault
• m is the modification rate probability that
  frame has been modified since swapped in.
• Effective Access Time (EAT)
• EAT (1 p) tmemory access
• p (tpage_fault_overhead m tswap_page_out
• tswap_page_in trestart overhead)

10
Demand Paging Example

• Memory access time 1 microsecond
• 50 of the time the page that is being replaced
  has been modified and therefore needs to be
  swapped out.
• Swap Page Time 10 msec 10,000 ?sec
• EAT (1 p) 1 p (15000) 1 14999p ?sec
• So if p .001, EAT 15.999 ?sec, a 16-fold
  decrease in access time! For decrease to be lt
  10, p must be lt .1/14999 .00000667 1 fault /
  149,990 references

11
Page Replacement

• Use modify (dirty) bit to reduce overhead of page
  transfers only modified pages are written back
  to disk. Bit is hardware manipd.
• Page replacement completes separation between
  logical memory and physical memory large
  virtual memory can be provided on a smaller
  physical memory.

12
Over-allocation

• Because demand paging allows processes to have
  just a few of their pages resident, the system
  can support more simultaneous jobs.
• As degree of over-allocation increases, so does
  CPU utilization, but also the page-fault ratio.

13
Page-Replacement Algorithms

• Want lowest page-fault rate.
• Evaluate algorithm by running it on a particular
  string of memory references (reference string)
  and computing the number of page faults on that
  string.
• In the following examples, the reference string
  is
• 1, 2, 3, 4, 1, 2, 5, 1, 2, 3, 4, 5.

14
First-In-First-Out (FIFO) Algorithm

• Reference string 1, 2, 3, 4, 1, 2, 5, 1, 2, 3,
  4, 5
• 3 frames (3 pages can be in memory at a time per
  process) vs. 4
• FIFO Replacement Beladys Anomaly
• more frames does not necessarily ? fewer page
  faults

9 page faults
10 page faults
15
Optimal Algorithm

• Replace page that will not be used for longest
  period of time.
• 4 frames example
• 1, 2, 3, 4, 1, 2, 5, 1, 2, 3, 4, 5How could
  you know this? Crystal ball?
• Its a benchmark used for measuring how well an
  algorithm performs.
• Analogous to shortest-job-first CPU scheduling

1
4
2
6 page faults
3
4
5
16
Least Recently Used (LRU) Algorithm

• Reference string 1, 2, 3, 4, 1, 2, 5, 1, 2, 3,
  4, 5
• Counter implementation
• Every page entry has a counter every time page
  is referenced through this entry, copy the clock
  into the counter.
• When a page needs to be changed, look at the
  counters to determine which are to change.

17
LRU Algorithm (Cont.)

• Stack implementation keep a stack of page
  numbers in a double link form
• Page referenced
• move it to the top
• requires 6 pointers to be changed
• No search for replacement

18
LRU Approximation Algorithms

• Reference bit
• With each page associate a bit, initially 0
• When page is referenced bit set to 1.
• Replace the one which is 0 (if one exists). We
  do not know the order among the 0s, however.
• Worst case is that all pages have same reference
  bit.
• Need a way to occasionally set bits back to 0?

19
LRU Approximations (cont.)

• The Second Chance Algorithm
• Need reference bit.
• Clock replacement provides ordering scheme
  among entries with same reference bit value.
• If page to be replaced (in clock order) has
  reference bit 0, replace it. Else, (bit1),
• set reference bit to 0.
• leave page in memory.
• continue to next page (in clock order), subject
  to same rules.

20
Counting Algorithms

• Keep a counter of the number of references that
  have been made to each page.
• LFU Algorithm replaces page with smallest count.
• MFU Algorithm based on the argument that the
  page with the smallest count was probably just
  brought in and has yet to be used.
• Suffers from cost of sorting page table.
  Priority queue is reasonable solution.
• Whats a priority queue?.

21
Preemptive swap-outs

• Provide a cached bit for each page.
• If CPU and I/O are idle, copy resident pages to
  swap-space, setting the cached bit.
• When a page replacement is needed, if a cached
  page is selected, there is no need to swap it
  out. Instead simply overwrite it with swapped-in
  page.

22
Allocation of Frames

• Each process needs minimum of frames.
• Example IBM 370 a max. of 6 pages to handle
  SS MOVE instruction
• instruction is 6 bytes, might span 2 pages.
• from address could straddle two pages.
• to address could straddle two pages.
• Two major types of allocation schemes
• fixed allocation
• priority allocation

23
Fixed Allocation

• Equal allocation e.g., if 100 frames and 5
  processes, give each 20 pages.
• Proportional allocation Allocate according to
  the size of process.

24
Priority Allocation

• Use a proportional allocation scheme using
  priorities rather than size.
• If process Pi generates a page fault,
• select for replacement one of its frames, or...
• select for replacement a frame from a process
  with lower priority number.

25
Global vs. Local Allocation

• Global replacement process selects a
  replacement frame from the set of all frames one
  process can take a frame from another.
• Process execution time is dependent on global
  environment. Less multitasking ? fewer pg faults
• Local replacement each process selects from
  only its own set of allocated frames.
• Run-time is more stable across environments.
• But, idle pages in processes are kept from other,
  busier processes. Generally global is used.

26
Thrashing

• If a process does not have enough frames, the
  page-fault rate is very high. This leads to
• 1. low CPU utilization.
• 2. OS thinks that it needs to increase the degree
  of multiprogramming (to increase CPU util.)
• 3. another process added to the system,
  decreasing number of frames per process!
• Thrashing ? a process spends most of its cycles
  swapping pages in and out.

27
Thrashing Diagram

• Why does paging work?Locality model (See figure
  10.15)
• locality set of pages used together
• Process migrates from one locality to another.
• Localities may overlap.
• Why thrashing?? size of locality gt total memory
  size (one proc thrashing vs. all)

28
Working-Set Model

• Working set is an approximation of locality.
• ? ? working-set window ? a fixed number of page
  references (e.g. 10,000 instructions)
• WSSi (working set of Process Pi) total number
  of pages referenced in the most recent ? (varies
  in time)
• if ? too small will not encompass entire
  locality.
• if ? too large will encompass several localities.
• if ? ? ? will encompass entire program.

29
Working-Set Model (cont.)

• Thesis allocate enough frames to a process to
  accommodate its current locality.
• m is total frames
• D ? WSSi ? total demand for frames
• if D gt m ? Thrashing
• Policy if theres thrashing, then suspend one of
  the processes.
• Process will be completed later.

30
Tracking the Working Set

• Approx. with interval timer a reference bit
• Example ? 10,000
• Timer interrupts after every 5000 time units.
• Keep 2 in-memory bits for each page.
• Whenever a timer interrupts, copy and set the
  values of all reference bits to 0.
• If one of the bits in memory 1 ? page in
  working set.
• How is this not accurate?
• Improvement 10 bits and interrupt every 1000
  time units.

31
Page-Fault Frequency Scheme

• Establish acceptable page-fault rate.
• If actual rate too low, process loses frame.
• If actual rate too high, process gains frame.
• Again, may need to suspend a process.

32
Other Considerations

• Prepaging (vs. demand paging)
• With pure demand paging, many page faults as
  processes begin, or are reactivated.
• Prepaging strives to bring all pages of a process
  into memory at same time.
• A win because disk latency is gt gt throughput.
  Combining faults combines latencies.

33
Other Considerations (2)

• Page size selection - how to select page size?
• fragmentation -- big pages more internal
  fragmentation
• table size -- small pages better memory
  utilization, but larger page tables
• I/O overhead
• latency is, say, 8msec20msec seek time,
  throughput 1KB/.4msec. Moving from 512B pages
  to 1K ? small run-time increase
• locality -- small pages better resolution
  better representation of localities

34
Programmers Knowledge of Paging

• Program structure
• int A1024, 1024
• Each row of A is stored in one page
• One frame allocd to process
• Program 1 for j 1 to 1024 do for i 1 to
  1024 do Ai,j 01024 x 1024 page faults
• Program 2 for i 1 to 1024 do for j 1 to
  1024 do Ai,j 01024 page faults

35
I/O Interlock

• Sometimes need to lock page into memory when
  using VM.
• Ex process requests input into a local buffer.
  If process is then swapped out, buffer will be
  inaccessible when input starts.
• Ex low-priority process faults. After page is
  swapped-in, it re-enters ready Q. A higher
  priority job may then want to replace this
  page....
• I/O interlock is a policy decision there are
  many different methods.

36
Real-Time Systems and VM

• Real-time systems usually cant afford run-time
  cost of VM.
• Solaris OS allows some processes (i.e., the
  real-time ones) to be highest priority, and to
  I/O interlock their pages.
• Have to be careful that not too many pages are
  locked.

37
Demand Segmentation

• Used when hardware is insufficient to support
  demand paging (e.g. 80286, etc.)
• OS/2 allocates memory in segments, which it keeps
  track of through segment descriptors
• Segment descriptor contains a valid bit to
  indicate whether the segment is currently in
  memory.
• If segment is in main memory, access continues,
• If not in memory, segment fault.

38
Demand Segmentation (cont.)

• Much more overhead than demand paging
• Segment size is variables
• External fragmentation compaction
• After compaction, may need segment replacement
• Segments can be big, so replacement may be slow
