Multiscreen Display System Video/Data Wall
2
Digital Display Wall

• Perfect one-stop solution provider
• Video Cubes, Processor and Control software
• Pre-sales consultation System Design
• Installation and commissioning
• After-Sales maintenance and support

3
Product Lines
Video Cube VisionPro C2 (XGA) VisionPro T2(Slim
version XGA) VisionPro CH2 (SGXA) Processors
Series Digicom Windows-Based, Unix- Based,
XLAN (launch in Late 2009) Ark 1000 (launch in
Late 2009) Software VWAS Management software
VLINKExpress
4
Market strengths

• Ranking number 2 (DTC) in the control room
  applications

Findings by 2006 DTC (UK) Market Research
5
Market strengths

• Worlds largest demonstration facilities
• Continuous enhancement in the technologies by
  RD team with 300 Engineers
• Distribution networks with technical support
  service covering 40 countries
• Production strength with monthly capacity 550
  Cubes
• ISO 9001, ISO14001

6
Product Strengths in the Market

• Proprietary advanced screen Technologies - BUCS
• Cost Effective Powerful Built-in Processor
• Powerful brand new processor Ark 1000 (late
  2009)
• Perfect IP-based Processor Digicom XLAN (late
  2009)
• Single or Dual Lamps with Hot standby
• Redundancy Power Hard-Drive
• Master and Slave Architecture
• Sophisticated Control software VWAS

7
Proprietary advanced screen Technologies

• Black Ultra Contrast Screen (BUCS)
• VTRONs unique patented product
• High screen quality
• Screen with High Contrast, more compact with
  sharper image
• Multi-element screen with coated glass
• Perfectly flat, rigid and resistant to collision,
  scratches, dirt, dust, and temperature changes
• Exceptionally high gain gt2.3
• Viewing angle 170 Horizontal, 110 vertical
• Seamless splicing provides polished finish

8
Cost Effective Built-in Processor

• Standard with all series of Video cubes
• Basic Two display windows (RGB and Video) per
  cube
• Scalable for C2 and T2 for up to 10 Video inputs
  and/or 3 RGB inputs
• Maximum of 10 windows per cube with optional
  input boards
• Window overlay
• Real time processing for RGB and video signals
• Screen layout can be controlled by software
• Video and RGB signals can be freely located and
  resized on a cubes or across screens

9
Cost Effective Built-in Processor (Cont)

• Does not limit display windows and speed to
  internal data bus like the traditional single
  processor
• Multiple windows from inputs can be displayed
  simultaneously
• Provides windows overlay and real time processing
• Improve performance with load sharing with
  Digicom
• Supplies dedicated ports for RGB and Video inputs

10
Cost Effective Built-in Processor (Cont)
ltDiagram of the built in processorgt
11
Perfect IP-based Processor Digicom XLAN

• Full Digital with distributed processing
• High capability e.g. 3X2 system can display 120
  IP video signals
• Accommodate IP Video input from Internet
• No Limit for IP Video Inputs
• High Speed Internal transmission with bandwidth gt
  100GB
• High scalability
• Simple installation and configuration

12
Master Slave Solution

• Ideal for video wall with more than 20 cubes
• Better share loading and higher performance
• E.g. 2 seconds to refresh the VW with more than
  80 cubes.

13
Other advanced Features

• Single or Dual Lamps with Hot standby
• Standard dual lamp system
• Hot standard with No physical movement of the
  standby lamp
• 0 second for the replacement lamp to be in
  position
• Redundancy Power Hard-Drive
• For the processor to maintain shorter downtime
• No Stitches are required between screens
• T2 series Front Access Servicing with screen
  Gap lt0.5mm

14
Software VWAS

• Provides user friendly graphical interface
• between operators and video wall system
• Layout and display mode management
• Input source management
• Multiple operator control
• Multi-layer security control
• Multi-processor and multi-display wall control
• Interface with Visionpro cubes
• Third party devices control
• (AMX, Crestron, matrix switchers..)

15
VLINKExpressTM

• A high speed solution capable of wirelessly
  displaying desktop content via network (LAN) on
  the video wall
• Self-developed transmission protocol that is 10x
  faster than the conventional protocol package
• Ideal for PowerPoint presentations, live video
  playbacks, high resolution content, GIS, and
  SCADA applications

16
Typical System design 1. 2 x 4 System with
Processor without Direct Input to Cubes
17
Typical System design 1. 2 x 4 System with ONLY
Direct Input to Cubes (using built-in processor,
without LAN Connection)
18
Typical System design 1. 2 x 4 System with BOTH
Processor wit Direct Input to Cubes
19
Global References
20
Global References
Location Bangalore, India User Akamai
Technologies Ltd (Nasdaq AKAM) Industry
Information Technology Application Network
Monitoring Operation System 2X3 C2 Series 50
XGA, Dual Lamps
21
Global References
Location ShenZhen, China User Shenzhen Metro
Corporation Industry Mass Transportation Applicat
ion Railway System Operation, CCTV,
Security System Config 3X27 C2 Series 67 XGA
22
Global References
Location Guangdong China User Guangdong Telecom
Industry Telecommunication Application Network
Monitoring and operation System Config 5X13 C
Series 67 XGA
23
Global References
Location Gunpo City of Seoul, Korea User Gunpo
City Management Office Industry
Government Application Presentation
Conference System Config 2X4 C2 series 60 XGA
24
Global References
Location Guangzhou, China User Guangzhou Metro
Corporation Industry Mass Transportation Applicat
ion Railway System Operations, CCTV,
Security System Config 3X18 C2 series 50 XGA
25
Global References
Location Angola, Africa User Angola Government
Department Industry Government Application
Presentation and Conferencing System 2X3 C2
Series 67 XGA
26
Global References
Location Seoul, Korea User Expressway
Management Corp. Industry Transportation Applicat
ion CCTV, Highway system operation System
Config 2X6 C Series 50 XGA
27
Global References
Location Bangalore, India User IBM (NYSE
IBM) Industry Information Technology Application
Presentation Conference System Config 2X3 C
series 50 XGA
28
Global References
Location Hong Kong, China User Princess Margret
Hospital Industry Hospital Application
Presentation Conference 2X3 T Series 50 XGA
29
Global References
Location Israel User HOT (Israel) Industry
Cable TV Station Application Control Center,
Channel Monitoring System Config 2X3 C2 series
67 XGA System
30
Global References
Location Abu Dhabi, UAE User Khalidiyah
Shopping Mall Industry Shopping Mall
Application Air Composition Monitoring System
Config 2X3 C2 series 50 XGA
31
Global References
Location Korea User Gangneung City Hall
Industry Government Application Presentation
Conference 2X4 C2 Series 50 XGA System
32
Global References
Location Seoul, Korea User Seoul Data
center Industry Government Application Network
Operations, and Data Monitoring System Config
2X5 C2 50 XGA
33
Global References
Location Seoul, Korea User Expressway
Management Corp. Industry Transportation Applicat
ion CCTV, Highway system operation System
Config 2X6 CH Series 50 SXGA
34
Global References
Location Seoul, Korea User Korean Airport
Authority Industry Transportation Application
Air transport monitoring System Config 2X6 C
Series 67 XGA
35
Global References

• Location Seoul, Korea
• User KT (Korea Telecom)
• Industry telecommunication
• Application CCTV, Network operation Monitoring

• - 2X2 CH Series 84 SXGA Dual Lamps
• 2X8 CH Series 80 SXGA Dual Lamps
• 2X2 CH series 84 SXGA Dual Lamps

36
Global References
Location Sharjah, UAE User Sharjah Electricity
Water Authority Industry Power Energy,
Government Application SCADA Management System
Config 3X3 C2 XGA Dual Lamps
37
Global References
Location Norway User Aker Oilfield
Services Industry Power Energy Application
Presentation conferencing System Config 2X4 T2
series 50 XGA
38
Global References
Location Hong Kong, China User Immigration
Department Industry Government Application
CCTV, Call Center System Config 2X10 C series XGA
39
Global References
Location Norway User Fotophono Industry
Commercial Application Video Conferencing
System Config 2X4 C2 series XGA
40
Global References
Location Jakarta, Indonesia User PT Smart
Industry Commercial Application
Presentation System Config 2X8 C series XGA
41
Global References
Location Russia Federation User Water Control
Center Industry Government Application Drainage
Water Control System Config 2X3 C2 Series XGA
42
Global References
Location Azerbaijan User City Traffic Control
Center Industry Government (Internal Affairs
) Application Traffic Control System Config
2X4 C2 Series XGA
43
Global References
Location Korea User Sachon City Hall Industry
Government Application Presentation and
Conference System Config 1X2 C2 Series 80 XGA
44
Global References
Location Saudi Arabia User Orbit Beam
Industry Government Application Presentation,
Demo System System Config 2X2 C2 Series 50 XGA
45
Global References
Location Seoul, Korea User Seoul City Council
Data Center Industry Government Application
Presentation, Data processing System Config 2X5
C Series 50 XGA
46
Global References
Location Tumen City, Siberia, Russia User Water
Control Center Industry Government Application
Water Control System Config 2X5 T2 Series 50 XGA
47
Global References
Location Oslo, Norway User Fotophono
Industry Commercial Application Demonstration,
Presentation and conferencing System Config 2X4
C2 Series 50 XGA
48
Global References
Location Switzerland User Zurich Insurance
Industry Financial Application Presentation
Conferencing System Config 3X6 C Series 52 XGA
49
Global References
Location Hong Kong, China User PCCW Industry
Telecommunication Application Telephone Network
Monitoring System Config 2X5 C Series 50 XGA
50
Global References
Location Jakarta, Indonesia User PT
Telkom Industry Telecommunication Application
Network Monitoring System Config 2X4 C2 Series
50 XGA
51
- The end -
