Visual Perception

1
Visual Perception
2
Perceptual process

• Environmental stimulus
• anything in our environment that we can perceive
• Attended stimulus
• focus of attention

3
Visual perception

• Perception can be defined as a conscious sensory
  experience
• light is emitted or reflected from an object
• image is formed on the receptors of the retina of
  the eye
• stimulus on the receptors are transformed into
  electrical signals
• electrical signals produced by the neurones are
  processed by the brain and converted to the
  experience of seeing
• high level processes (recognition, action,)

4
Visual system

• Eyes

5
Eyes

• cornea approx. 2/3 of eyes focussing power
• lens can change shape
• eye can focus on object at various distances
  (accommodation)
• focus at one depth at a time
• limited depth of field
• pupil
• diameter varies from 3mm to 7mm
• change in retinal illuminance

6
Eyes

• Fovea
• less than 1 of retinal size
• Most densely populated with photoreceptors
• Image fixated on the retina
• Saccades
• quick, simultaneous movements of both eyes
• Blind Spot (optical nerve exit)

7
Blindspot
R L
8
Receptors

• Rods
• 120 million
• Mainly in periphery
• Monochromatic, low light
• Cones
• 6 million
• Concentrated in fovea
• Colour, bright light
• 3 types
• peak at different wave lengths

9
Colour vision

• humans can perceive wavelengths between 400 to
  700 nanometer
• Just noticeable difference
• 1 nm in green - yellow wavelengths(human
  colour perception is most sensitive here)
• 10 nm and more in the red and blue

 Source Hunt, 2004 (via http//www.handprint.co
m/HP/WCL/color1.html)Note "c" means "complement
of" wavelength for extraspectral hues
(mixtures of "red" and "violet" light).
10
Colour vision
Colour blindness 6-8 European4-6
Asian 2-4 African
11
Visual System

• 126 mil. receptors converge to 1 mil. ganglion
  cells
• 120 rods, 6 cones
• Connect to nervoussystem
• Visual cortex
• Cells respond to different aspects of stimuli
  (feature detectors)
• e.g. orientation, motion, edge

12
Visual perception

• the world or the image is not 'given', but
  constructed.
• we are not like passive cameras
• we interpret the world actively
• Knowledge / Experience
• Affects processing, perception, recognition
• Top down

13
(No Transcript)
14
(No Transcript)
15
Environmental factors
16
Environmental factors

• Experience, education, culture, values, etc.
  influence perception
• Carpentered world
• Experiement (Segall, Campbell and Herskovitz
  (1966) - Zulu people are less affected by this
  illusion

Müller-Lyer Illusion
17
Environmental factors

• people who lived in very open rural environments
  tended to be more subject to the
  horizontal-vertical illusion than others
• visual perception is in part at least learned

18
Environmental factors
the two-pronged trident
impossible object by L S and R Penrose
19
Environmental factors

• Gender differences
• Coren, Porac and Ward (1978)
• brush vs. comb
• target vs. dinner plate
• head vs. cup

20
Gestalt psychology

• Model of Perceptual Organization
• perceiving individual sensory stimuli as a
  meaningful whole
• whole is different from the sum of its parts
• Overarching principle pragnänz
• the simplest and most stable interpretations are
  favoured
• Gestalt principles / laws
• proximity, similarity, good continuation,
  closure, symmetry, common fate

21
Proximity

• Elements in spatial or temporal proximity appear
  to be grouped together

22
Similarity

• Tendency to group similar elements (form, colour,
  size, brightness)

23
Good continuation

• The mind continues visual, auditory, and kinetic
  patterns

24
Closure

• Interpretations which produce 'closed' rather
  than 'open' figures are favoured

25
Symmetry

• Symmetrical areas tend to be seen as figures
  against asymmetrical backgrounds

26
Common fate

• Elements moving in the same direction appear to
  be grouped

27
Attention

• Inattentional blindness
• video
• Attentional Blink
• inability to detect a new target for a short time
  after the first target is presented (200-500
  ms)http//psych.hanover.edu/JavaTest/Cognition/Co
  gnition/AttentionalBlink.html
• Change blindness
• inability to detect unattended changes
• example

28
Visual search
One stimulus dimension (colour)
Parallel searchpre attentive
29
Visual search

• Other pre-attentive stimuli
• shape, depth, motion (direction), orientation,
  curvature, size,

30
Visual search
Conjunction searchcolour shape
serial search
31
Visual search

• Nakayama Silverman
• stereoscopic depth different in conjunction
  searches
• depth colour depth motion different to
  colour motion
• reaction times constant over set sizes
• segregation of visual array into planes
• parallel searches in one plane without
  interference from distracters in other plane

32
Multi Layer Display
33
Conditions - single
shape
colour
depth
34
Conditions - conjunction
colour-shape
colour-depth
colour-depth (tf)
shape-depth
shape-depth (tf)
colour - shape-depth
35
Task
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
Results
41
Stroop Effect
?????
?????
?????
?????
?????
Green
Brown
Purple
Red
Blue
42
Stroop Effect

• interference
• mind automatically determines semantic meaning -
  then must override this first impression with the
  identification of the coulor
• http//cognitivefun.net/test/2

43
Colour

• Colour effect (colour psychology)
• varies in different cultures
• passion, strength, energy, fire, love, sex,
• peace, unity, harmony, calmness, trust,
• life, nature, bad spirits, spring, fertility,
  youth,...
• joy, happiness, earth, optimism, intelligence,
• modernity, power, sophistication, formality,
• boldness, depth, natural organisms, nature,
  richness,
• http//en.wikipedia.org/wiki/Color_symbolism

44
Colour

• Warm vs. cold colours
• seems related to the observed contrast in
  landscape light

45
Same colour illusion

• Local contrast B is lighter than its neighbours
• Visual system tends to ignore gradual changes
• Chromatic adaptation (colour constancy with
  different types of light)

46
Object consistency

• perception of objects is more constant than our
  retinal images

47
Depth perception

• Binocular depth cues
• Stereopsis or retinal disparity
• Accommodation
• Convergence
• Monocular depth cues
• Motion parallax
• Depth from motion
• Colour vision
• Perspective
• Relative size
• Occlusion
• Texture gradient

48
Depth perception
49
Afterimage
receptors adapt from the over stimulation and
lose sensitivity (colours are muted)
50
Afterimage
Afterimages of complementary colours create
apparent movement in our peripheral vision as
our eyes shift across the page
51
Movement
Phi phenomenon
Beta movement
