Title: System Calls


1
System Calls Libraries
  • Vivek Pai
  • Lecture 4, COS318
  • Sep 24, 2002

2
Gedankundmathematics
  • Recall the pointer verification case for fread( )
  • Can you speed up the checking process?
  • Whats the best you could achieve? O(n)? O(logn)?
    O(1)?
  • What happens if you have gt32 bits?
  • Aside atoms in universe 1080, or 2256
  • Does this provide any other benefits?

3
Mechanics
  • Project 1
  • Has everyone started?
  • Barring major problems, due Tuesday 1159pm
  • Upcoming projects
  • No more groups of 3
  • Who wants partners?
  • Readings updated
  • Project 2 documentation in place

4
Protection Issues
  • I/O protection
  • Prevent users from performing illegal I/Os
  • Memory protection
  • Prevent users from modifying kernel code and data
    structures
  • CPU protection
  • Prevent a user from using the CPU for too long

5
Protection Is Not Safety/Security
  • Protection is a prerequisite
  • Safety can be separation of concerns
  • Security related to overall design
  • Examples?
  • Bad pointer access causing seg fault
  • Sniffing cleartext passwords on the wire

6
Support in Modern ProcessorsUser ? Kernel
An interrupt or exception (INT)
  • User mode
  • Regular instructions
  • Access user-mode memory
  • Kernel (privileged) mode
  • Regular instructions
  • Access user-mode memory

A special instruction (IRET)
7
Why a Privileged Mode?
  • Special Instructions
  • Mapping, TLB, etc
  • Device registers
  • I/O channels, etc.
  • Mode Bits
  • Processor features
  • Device access

8
x86 Protection Rings
Privileged instructions Can be executed only When
current privileged Level (CPR) is 0
Level 3
Level 2
Level 1
Operating system kernel
Level 0
Operating system services
Applications
9
Other Design Approaches
  • Capabilities
  • Fine-grained access control
  • Crypto-like tokens
  • Microkernels
  • OS services in user space
  • Small core hypervisor

10
Monolithic
User program
User program
  • All kernel routines are together
  • A system call interface
  • Examples
  • Linux
  • Most Unix OS
  • NT

return
call
entry
Kernel many many things
11
Monolithic Pros and Cons
  • Pros
  • Relatively few crossings
  • Shared kernel address space
  • Performance
  • Cons
  • Flexibility
  • Stability
  • Experimentation

12
Layered Structure
  • Hiding information at each layer
  • Develop a layer at a time
  • Examples
  • THE (6 layers)
  • MS-DOS (4 layers)

Level N
. . .
Level 2
Level 1
Hardware
13
Layering Pros and Cons
  • Pros
  • Separation of concerns
  • Simplicity / elegance
  • Cons
  • Boundary crossings
  • Performance?

14
Microkernel
User program
Services
  • Micro-kernel is micro
  • Services are implemented as regular process
  • Micro-kernel get services on behalf of users by
    messaging with the service processes
  • Examples Taos, Mach, L4

return
call
entry
m-kernel
15
Microkernel Pros and Cons
  • Pros
  • Easier to develop services
  • Fault isolation
  • Customization
  • Smaller kernel gt easier to optimize
  • Cons
  • Lots of boundary crossings
  • Really poor performance

16
Virtual Machine
  • Virtual machine monitor
  • provide multiple virtual real hardware
  • run different OS codes
  • Example
  • IBM VM/370
  • virtual 8086 mode
  • Java
  • VMWare

user
user
OS1
OSn
. . .
VM1
VMn
Small kernel
Bare hardware
17
Hardware Support
  • What is the minimal support?
  • Can a virtual machine be protected without such
    support?
  • Hint what is a Turing machine?

18
System Call Mechanism
  • User code can be arbitrary
  • User code cannot modify kernel memory
  • Makes a system call with parameters
  • The call mechanism switches code to kernel mode
  • Execute system call
  • Return with results

User program
User program
return
call
entry
Kernel in protected memory
19
Interrupt and Exceptions
  • Interrupt Sources
  • Hardware (by external devices)
  • Software INT n
  • Exceptions
  • Program error faults, traps, and aborts
  • Software generated INT 3
  • Machine-check exceptions
  • See Intel document chapter 5, volume 3 for details

20
Interrupt and Exceptions (1)
Vector Mnemonic Description Type
0 DE Divide error (by zero) Fault
1 DB Debug Fault/trap
2 NMI interrupt Interrupt
3 BP Breakpoint Trap
4 OF Overflow Trap
5 BR BOUND range exceeded Trap
6 UD Invalid opcode Fault
7 NM Device not available Fault
8 DF Double fault Abort
9 Coprocessor segment overrun Fault
10 TS Invalid TSS
21
Interrupt and Exceptions (2)
Vector Mnemonic Description Type
11 NP Segment not present Fault
12 SS Stack-segment fault Fault
13 GP General protection Fault
14 PF Page fault Fault
15 Reserved Fault
16 MF Floating-point error (math fault) Fault
17 AC Alignment check Fault
18 MC Machine check Abort
19-31 Reserved
32-255 User defined Interrupt
22
System Calls
  • Interface between a process and the operating
    system kernel
  • Categories
  • Process management
  • Memory management
  • File management
  • Device management
  • Communication

23
OS Kernel Trap Handler
HW Device Interrupt
Sys_call_table
System service dispatcher
System Service Call
HW exceptions SW exceptions
Virtual address exceptions
HW implementation of the boundary
24
Passing Parameters
  • Affects and depends on
  • Architecture
  • Compiler
  • OS
  • Different choices for different purposes

25
Passing Parameters - Registers
  • Place parameters in registers
  • of registers
  • of usable registers
  • of parameters in system call
  • Spill/fill code in compiler
  • Really fast

26
Passing Parameters - Vector
  • Register holds vector address
  • Single register
  • Vector in users memory
  • Nothing horrible, just not common

27
Passing Parameters - Stack
  • Place parameters on stack
  • Similar to vector approach
  • Stack already exists
  • Gets copied anyway

Top
frame
frame
28
Library Stubs for System Calls
  • Use read( fd, buf, size) as an example
  • int read( int fd, char buf, int size)
  • move fd, buf, size to R1, R2, R3
  • move READ to R0
  • int 0x80
  • move result to Rresult

User stack
User memory
Registers
Kernel stack
Registers
Linux 80 NT 2E
Kernel memory
29
System Call Entry Point
  • Assume passing parameters in registers
  • EntryPoint
  • switch to kernel stack
  • save context
  • check R0
  • call the real code pointed by R0
  • restore context
  • switch to user stack
  • iret (change to user mode and return)

User stack
User memory
Registers
Kernel stack
Registers
Kernel memory
30
Design Performance Issues
  • Can user code lie?
  • One result register large results?
  • Parameters in user memory
  • Multiprocessors

31
General Design Aesthetics
  • Simplicity, obviousness
  • Generality same call handles many cases
  • Composition / decomposition
  • But
  • Expressiveness
  • Performance

32
Separation Of Concerns
  • Memory management
  • Kernel allocates pages hw protection
  • Programs use malloc( ) fine grained
  • Kernel doesnt care about small allocs
  • Allocates pages to library
  • Library handles malloc/free

33
Library Benefits
  • Call overhead
  • Chains of alloc/free dont go to kernel
  • Flexibility easy to change policy
  • Fragmentation
  • Coalescing, free list management
  • Easier to program

34
Feedback To The Program
  • System calls, libraries are program to OS
  • What about other direction?
  • Various exceptional conditions
  • General information, like screen resize
  • When would this occur?
  • Answer signals
