Chapter XI Reduced Instruction Set Computing (RISC)

1
Chapter XIReduced Instruction Set
Computing(RISC)

• CS 147
• Li-Chuan Fang

2
Introduction

• The world of microprocessors and CPUs can be
  divided into two parts
• complex instruction set computers (CISC
  processors)
• reduced instruction set computers (RISC
  processors)
• CISC processors have larger instruction sets that
  often include some particularly complex
  instructions. These instructions usually
  correspond to specific statements in high-level
  languages.
• RISC processors exclude these instructions,
  opting for a smaller instruction set with simpler
  instructions.

3
Overview

• the rationale for RISC processors
• RISC instruction sets
• instruction pipelines and register windows

4
RISC Rationale

• The first microprocessors ever developed were
  very simple processors with very simple
  instruction sets.
• Current CISC microprocessor instruction sets may
  include over 300 instructions.
• In general, the greater the number of
  instructions in an instruction set, the
  propagation delay is within the CPU.

5
RISCs Features

• Fixed - Length Instructions
• Limited Loading and Storing Instructions Access
  Memory
• Fewer Addressing Modes
• Instruction Pipeline
• Large Number of Registers

6
RISCs Features cont.

• Hardwired Control Unit
• Delayed Loads and Branches
• Speculative Execution of Instructions
• Optimizing Compiler
• Separate Instruction and Data Streams

7
Fixed - Length Instructions

• In RISC processors, every instruction has
• the same size. For instance, an immediate
• mode instruction might include an 8-bit
• operand. Other instructions might use these
• 8 bits for opcodes of address information.

8
Limited Loading and Storing Instruction Access
Memory

• All processors can load data from and store data
  to memory.
• RISC processors limit interaction with memory to
  loading and storing data. If a value from memory
  is to be ANDed with the accumulator, the CPU
  first loads the value into a register and then
  performs the AND operation.

9
Fewer Addressing Modes

• RISC processors typically allow only a few
  addressing modes that can be processed quickly,
  such as register indirect and relative modes.

10
Instruction Pipeline

• A pipeline is like an assembly line in which
  many products are being worked on simultaneously,
  each at a different station.
• In RISC processors, one instruction is executed
  while the following instruction is being fetched.
  By overlapping these operations, the CPU
  executes one instruction per clock cycle, even
  though each instruction requires three cycles to
  be fetched, decoded, and executed.

11
Large Number of Registers

• Having a large number of registers allows the
  CPU to store many operands internally.
• When the operands are needed, the CPU fetches
  them from the registers, rather than from memory.
  This reduces the access time significantly. The
  registers can also be used to pass parameters to
  subroutines in an efficient manner this is
  accomplished using register windowing.

12
Hardwired Control Unit

• Combinatorial logical generally has a lower
  propagation delay than a lookup ROM. For this
  reason, a hardwired control unit can run at a
  higher clock frequency than its corresponding
  microcoded control unit.
• For RISC processors, the benefit of a higher
  clock rate outweighs the advantages offered by
  microcoded control units, such as ease of
  modification.

13
Delayed loads and Branches

• RISC processors use delayed loads and delayed
  branches to avoid waiting time.
• The RISC instruction pipeline can encounter
  hazards during branch instructions or consecutive
  instructions that use a common operand.

14
Speculative Execution of Instructions

• In speculative execution, the CPU executes the
  instruction but does not store its result. If
  the instruction is to be executed, the result is
  stored. If not, the result is discarded.

15
Optimizing Compiler

• An optimizing compiler can arrange instructions
  to facilitate delayed loads and branches, as well
  as to optimally assign operands to registers.
  Fewer instructions make it much simpler to design
  an optimizing compiler for a RISC processor than
  for a CISC processor.

16
Separate Instruction and Data Streams

• The instruction pipeline may need to access
  instructions and operands from memory
  simultaneously. Separating the instruction and
  data streams helps to avoid memory access
  conflicts.

17
RISC Instruction Sets

• The instruction sets of RISC processors are
  reduced, or smaller in size than those of CISC
  processors.
• A CISC processor might have over 300 instructions
  in its instruction set, but RISC CPUs typically
  have fewer than 100.

18
Instruction Formats for the SPIM (MIPS) CPU
19
Instruction Pipelines and Register Windows

• two implementation techniques commonly used in
  RISC processors to improve performance
• instruction pipeline
• allows RISC processors to execute one instruction
  per
• clock cycle
• incorporation of large numbers of registers
  within the CPU
• allows more variables to be stored in registers,
  rather
• than memory, which reduces the time needed to
• access data

20
Instruction Pipelines

• An instruction pipeline is very similar to a
  manufacturing assembly line.
• An instruction pipeline processes an instruction
  the way the assembly line processes a product.
• The first stage fetches the instruction from
  memory.
• The second stage decodes the instruction and
  fetches any required operands.

21
Instruction Pipelines cont.

• The third stage executes the instruction.
• The fourth stage stores the result.
• As with the assembly line, each stage processes
  instruction simultaneously (after an initial
  latency, or delay, to fill the pipeline).
• This allows the CPU to execute one instruction
  per clock cycle.

22
Instruction Pipelines cont.

• The IBM 801, the first RISC computer, also uses a
  four-stage instruction pipeline.
• Other processors, such as the RISC II use only
  three stages they combine the execute and store
  result operations in a single stage.
• The MIPS processor uses a five-stage pipeline it
  decodes the instruction and selects the operand
  registers in separate stages.
• Note that each stage has a register that latches
  its data at the end of the stage to synchronize
  data flow between stages.

23
Instruction Pipelines cont.

• Although we could employ several complete control
  units to process instructions, a single pipelined
  control unit offers hardware several advantages.
• The primary advantage is the reduced hardware
  requirements of the pipeline.
• A second advantage of instruction pipelines is
  the reduced complexity of the memory interface.

24
Three-stage RISC Pipeline
Fetch instruction
Decode instr. select regs.
Execute instr. store result
25
Four-stage RISC Pipeline
Fetch instruction
Decode instr. select regs.
Store result
Execute instruction
26
Five-stage RISC Pipeline
Fetch instruction
Decode instruction
Select registers
Store result
Execute instruction
27
Data flow through three-stage RISC pipeline
28
Data flow through four-stage RISC pipeline
29
Data flow through five-stage RISC pipeline
30
Pipelines Problems

• One problem is memory access.
• Another problem is caused by branch statements.

31
How to solve these problems?

• problem 1 - memory access
• As we noted previously, the cache must separate
  instructions and data to avoid memory conflicts
  from the different stages of the pipeline.
• problem 2 - branch statements
• There is not much that the pipeline can do about
  this. Instead, an optimizing compiler is needed
  to reorder the instructions to avoid this problem.

32
Register Windowing

• The CPU can access data in registers more quickly
  than data in memory, so having more registers
  makes more data available faster.
• Having more registers also helps reduce the
  number of memory references, particularly when
  calling and returning from subroutines.

33
Register Windowing cont.

• Although a RISC processor has many registers, it
  may not be able to access all of them at any
  given time.
• Most RISC CPUs have some global registers, which
  are always accessible.
• The remaining registers are windowed so that only
  a subset of the registers are accessible at any
  specific time.

34
Register windowing in the SPARC processor
Global registers (8)
Common input registers (8)
Window 1
Local registers (8)
Windowed registers
Window 2
Window 3
Common output registers (8)
35
Register Windowing cont.

• The RISC CPU must keep track of which window is
  active and which windows contain valid data.
• A window pointer register contains the value of
  the window that is currently active.
• A window mask register contains 1 bit per window
  and denotes which windows contain valid data.

36
Register Windowing cont.

• Register windows provide their greatest benefit
  when the CPU calls a subroutine.
• During the calling process, the register window
  is moved down one window position.
• In SPARC example, if window 1is active and the
  CPU calls a subroutine, the processor activates
  window 2 by updating the window pointer and
  window mask registers.

37
Register Windowing cont.

• The CPU can pass parameters to the subroutine via
  the registers that overlap both windows, instead
  of through memory this save a significant amount
  of time in accessing data.
• The CPU can use the same registers to return
  results to the calling routine.

38
Register windowing in a CPU during execution of
the main routine
0
Window pointer register (First window active)
0 0
First window
1213141516
Param. 1 Param. 2 Param. 3
Window mask register
1 0 0 0
(Only first window has valid data)
47
39
Register windowing in a CPU executing a
subroutine
Window pointer register (Second Window active)
0
0 1
First window
Param. 1 Param. 2 Param. 3 Result
1213141516
Window mask register
Second window
1 10 0
27
(First two windows has valid data)
47
40
Register windowing in a CPU after returning
from the subroutine
0
Window pointer register (First window active)
0 0
First window
1213141516
Window mask register
1 0 0 0
Result
(Only first window has valid data)
47
41
Register Renaming

• Most recent processors may use register renaming
  to add flexibility to the idea of register
  windowing.
• A processor that uses register renaming can
  select any registers to comprise its working
  register window.
• The CPU uses pointers to keep track of which
  registers are active and which physical register
  corresponds to each logical register.

42
Register Renaming cont.

• Unlike register windowing, in which only specific
  registers are active at any given time, register
  renaming allows any group of physical registers
  to be active.
