PHYS2211N Lecture

1
PHYS2211N Lecture 2

• Jan12, 2005

2
Jan 12, 2005

• Todays Agenda
• More on vectors
• Displacement
• Velocity and speed
• Acceleration
• UNC vs GT (ESPN)

3
PRS DEMONSTRATION

• Prior to this class, have you taken physics at
  either the high school or college level? (Note
  Do not count physical science courses as
  physics.)
• 1. Yes 2. No

4
Vectors...Review

• An arrow is commonly used to represent a vector
  quantity moreover, there are two common ways to
  symbolize a vector quantity
• Boldface notation A
• Arrow notation

A
5
Coordinate Systems

• Before we can talk about out things move we need
  to decide how to concretely define where an
  object is.
• In 2-D, or 3-D there are two basic types of
  coordinate systems
• Cartesian coordinates (x,y,z) use units
• three mutually perpendicular directions.
• Conventions require right-handed system
• 2) Polar (or spherical) coordinates (r,q,f) use
  a distance and one or more angles

6
Vector additiongraphical method

• Consider the vectors A and B. Find A B.

B
B
A
A
A
C A B
B

• The Head-to-Tail Rule
• We can pick up and move vectors at will. Just
  dont change their length or their direction!!

7

• Which of the following corresponds to the
  diagram?
• 1. C B A
• 2. C A - B B
• 3. C B - A
• 4. B C - A

8
Vector Subtraction
Displacement
9
Displacement

• The change in the position vector is a vector
  called displacement.

10
A vector divided (or multiplied) by a scalar is
another vector. We define a vector average
velocity as We define average speed as Note
average speed is NOT the magnitude of the average
velocity vector.
11
Example 1 My GPS in my
Land Rover says that the Phys building is 5.77
miles from my house in a direction of 195 degrees
(wsw). The speedometer on my car say I drive 8.0
miles to work. If the trip takes 25 min, what is
my average velocity, and average speed.
12
My average speed is My average velocity is
13
Useful trivia

• Navigation directions are measured from north
  being direction 0 degrees. This is what is used
  for wind, ships, and airplanes.
• The numbers on the end of runways are the
  direction/10. If you land at an airport and see
  27 on the end of the runway, you are flying
  directly towards the west.

14
If you run once around a circular track of radius
R in time T, what is your average speed and
average velocity? Your average speed is 2pR/T
and your average velocity is
15
Vocabulary of Mechanics

• Speeding Up vs Slowing Down

• Accelerate vs Decelerate

• Positive acceleration vs Negative
  acceleration

16
Mechanics Vocabulary

• How fast?
• Speed

distance traveled

• Average Velocity

Rate of Change of Position
17
Mechanics Vocabulary

• Average Acceleration

Rate of Change of Velocity
18
Example 1.4 (Skier)
19
The motion diagram for a sprinter running around
a circular track (displacement vectors shown).
What is the direction of the acceleration at
point A?
(Select 9 to indicate the acceleration is zero.)
3
4
2
5
1
6
8
7
A
20
Circular Motion
21
Vocabulary of Mechanics

• Speeding Up vs Slowing Down

• Accelerate vs Decelerate

• Positive acceleration vs Negative
  acceleration
