The Joint COntrols Project Framework

1
The Joint COntrols Project Framework

• Manuel Gonzalez Berges on behalf of the JCOP FW
  Team

2
Contents

• Overview
• Deliverables
• Who is using it?
• Development Process
• Current Status
• Summary

3
The Joint COntrols Project

• Set up in 1998 as a collaboration between the
  four LHC experiments and CERN as equal partners
• Project mandate
• To develop a common Framework and components
  for detector control of the LHC experiments and
  to define the required long-term support.
• JCOP comprises many activities
• Evaluation of different technologies
• Main subprojects
• Framework
• Detector Safety System (DSS)
• Gas Systems
• And others

4
The JCOP Framework

• Project established in May 2000
• Use Architecture WG Framework Design Proposal as
  starting point
• Aims
• Reduce the development effort
• Reuse of components
• Hide complexity
• Help in the learning process
• Facilitate the integration
• Reduce resources needed afterwards
• Homogeneous control system
• Operation
• Maintenance

5
Approach Followed

• Provide a higher layer of abstraction
• reduce knowledge of tools
• interface for non experts
• Customize Extend industrial components
• Modular/Extensible
• core
• mix match components
• As intuitive as possible
• Global rather than local optimization
• Not a complete control system!

6
Types of Users

• Component Developer
• Extends the Framework
• System Developer
• Develops a controls application using the
  Framework
• System Integrator
• Puts together systems developed separately
• End Users
• Domain Expert (e.g. gas, high voltage)

7
DCS Development
8
Architecture
9
Framework Deliverables

• Guidelines document
• Devices
• Tools
• Libraries
• Examples
• Tutorial training

10
Guidelines and Conventions

• Guidelines to produce a coherent control system
• Look and feel
• e.g. colours, fonts, layout
• Alarm classes
• Naming convention
• Exception handling
• File organization
• and so on

11
Devices

• Representation of real-world device or logical
  entity
• Device consists of
• Supervisory
• Data Point Type(s)
• Library
• Panels
• Front-end object
• Commercial
• Custom made

12
Supported Devices

• Generic Analog-Digital devices
• CAEN power supplies
• Wiener power supplies
• Wiener Fan Tray (crate control)
• PS and SPS machine data server
• ELMB
• Logical Node/View
• Device Support Extension

13
Tools (I)

• Device Editor/Navigator
• Main interface to the Framework
• System management installation, login, etc
• Configuration and operation of devices
• Controls Hierarchy
• High level view and behaviour of experiment
• Includes Finite State Machines (based on SMI)
• Provides predefined behaviour (partitioning
  rules)
• External Alarm Handler
• Receive alarms in PVSS from a external system
• Trending
• Simplify extend PVSS trends
• Pages of predefined plots, templates, tree

14
Tools (II)

• Generic External Handler
• To incorporate C code to panels and ctrl
  manager
• Easier to use than standard PVSS C
• Mass Configuration
• Initial release including creation and deletion
• Manipulation of device sets coming
• Component Installation

15
Framework Components
Supervisory Application
User
Framework
PVSS
Commercial
C/C code
Devices
External System
OPC, DIM, PVSS comms
OPC server
OPC server
OPC server
Equipment
16
Other deliverables

• Libraries
• Setting of address, alerts, archiving, etc
• List manipulation
• Exception handling
• Examples
• Panels
• Buttons
• Scripts
• Tutorial
• Use of several FW tools
• Available as a one day course from the CERN
  Training Service
• Can be run in our lab with real hardware or in
  users own lab with simulator

17
Who is using it?

• Fixed target experiments
• COMPASS
• HARP
• NA60
• LHC experiments testbeams
• ALICE / HMPID, TPC
• ATLAS / Muon Chambers, Inner Detectors
  integration
• CMS / Muon DT
• LHCb / Velo, Muon
• Gamma Irradiation Facility (GIF)
• Experiments Gas Control Systems
• LHC Accelerator UNICOS Framework
• Cryogenics
• Vacuum

18
Development Process

• Driven by the Framework Working Group
• Meetings every two weeks
• Identify new components and set priorities
  (planning)
• Review requirements
• Review implementation proposals
• Forum for exchanging ideas
• Members
• Representatives from each of the LHC experiments
• FW core team
• Agreed development process
• Iterative, lightweight
• Configuration Management

19
Development Process
Short requirements doc
FW WG Review
Implementation Proposal
FW WG Review
Implementation
Test
Documentation
Configuration Management
Information Management
20
Status

• Three major releases since June 2001
• Increasing functionality
• Incorporating feedback
• Current work
• Simplification of the integration of new device
  types
• Configuration from an external database
• Data Storage and Retrieval
• CASTOR
• Conditions Database
• ISEG power supplies
• Access Control
• Scalability tests

21
Summary

• Successful collaboration
• Development process
• Framework WG
• Feedback from users
• Deliverables in production
• Overhead of consultancy and support
• Useful feedback from users
• Recent external JCOP Review
• Approach adopted was supported
• Framework identified as one of the key elements
  of JCOP
• Good support for common devices
• Databases an important issue to be followed

22
Pointers

• JOint Controls Project
• http//cern.ch/itco/Projects-Services/JCOP
• External JCOP Review
• http//cern.ch/itco/Projects-Services/JCOP/Externa
  lReview
• JCOP Framework
• http//cern.ch/itcobe/Projects/Framework
