CSE 5346 Networks II High Performance
Networks
2
Introduction

• Performance and Quality of Service

3
Course Foundation Assumptions (pre-requisites)

• Good understanding of packet-switched networking
  concepts and principles of operation
• Good understanding of Internet protocols and
  architectures (e.g., IP protocol stack)
• Solid foundation in computer operating systems
  fundamentals
• Ability to learn simple programming languages
  (such as ns/2 tcl, C/C)
• Ability to perform independent research, analyze
  findings and document results

4
What will we cover?

• Networking Introduction/Review
• Today setting the stage
• Frame Relay, ATM High Speed LANs
• Performance Modeling and Estimation
• Congestion, Network Traffic Analysis/Management
  and Routing
• Quality of Service
• Compression Standards and Practice
• Advanced Topics (time permitting) VoIP, Mobile
  IP, Mobile Agents

5
How will we cover it?

• Classroom lectures
• Quizzes and exams
• Incremental modeling and simulation project using
  ns/2
• Self-study research, and simulation reports by
  students
• Study and student presentations on relevant
  papers RFCs

6
Chapter 1 - Introduction

• An Overview of Networking - the Need for Speed
  and Quality of Service

7
The Evolution of Networks Internetworking

• ARPANET to Internet
• Initial packet switched technology
• DOD ARPA funded
• 4 nodes in 1969 _at_ 50kbps
• TELNET FTP first standard network applications
• 1972 Killer App email!

• Internet to WWW
• Cerf Kahn TCP, 1974
• ARPANET NCP to TCP, 1982-1983
• NSF backbone
• ARPANET shut down, 1990
• Mosaic 1992
• U.S. Government Internet funding terminated in
  1995

8
Growth of the Internet
As of January 2005 gt 300 million computers
in 209 countries
9
What is an/the Internet?

• connected computing devices hosts, end-systems
• PCs, workstations, servers
• PDAs, phones, toasters, cars
• running network applications
• communication links
• fiber, copper, radio, satellite
• routers/switches forward packets (chunks) of
  data thru network

router
workstation
server
mobile
10
The Need for Speed!

• Scale
• growing number of hosts -gt growing demands on
  bandwidth
• new technologies result in new paradigms for
  device and connection types
• e.g. ??

• Application
• demand for large to huge file transfers
• increasing critical nature of Internet use
• demand for real-time performance
  characteristics
• demand for guarantees of service levels
• e.g. ??

• User Expectations!

11
High-Speed Networks IDN to ATM

• IDN (Integrated Digital Network)
• early 60s, answer to growth of digital,
  computer-controlled, circuit-switched networking
• WE 4ESS introduced in 1976, 1st large scale
  commercial time-division switch
• ISDN (Integrated Services Digital Network)
• integrated voice and data on the same digital
  transmission links/exchanges
• small incremental cost for data over existing
  digital voice network

12
High-Speed Networks IDN to ATM

• Frame Relay
• popularized standard (c. 1988) for packet
  switching over ISDN
• most widely deployed WAN technology in use today
• B-ISDN (Broadband ISDN)
• c. 1988 emerging demand for broadband services
• new high-speed technologies available
• emerging bandwidth hungry applications

13
High-Speed Networks IDN to ATM

• ATM (Asynchronous Transfer Mode)
• early 90s outgrowth of emerging need for
  high-speed switching over B-ISDN WAN
• rapidly evolved as high-speed packet switching
  technology of its own accord
• primary deployment today is
• public network infrastructure
• LAN backbone
• private network, VPN WAN
• services not widely deployed/available until
  late-90s.

14
High-Speed Networks ATM Backbone Example
15
High-Speed Networks LANs

• High-speed LANs
• driven by explosive growth in speed and computing
  power of PCs in 1990s
• emergence of client-server computing architecture
• use of centralized server farms
• emergence of power workgroups and workgroup
  applications
• need for local high-speed LAN backbones

16
IP-based Internets (aka TCP/IP networks)

• Internetworking the dominant paradigm of
  computer networking
• Evolution - key internetworking
• technologies
• packet switching
• TCP/IP
• TCP reliable end-to-end transport
• IP internet routing and delivery
• dynamic routing, load balancing
• high speed Ethernet LANs

17
Advancements in TCP/IP Networks

• Recent advancements driven by the need to support
  multimedia and real-time traffic
• Emergence of Internets Integrated Services
  Architecture (ISA, or IntServ) and Differentiated
  Service (DS, or DiffServ)
• New QoS Architecture/Framework is driving
  protocol changes
• IPv6 introduces new features for QoS
• RSVP Resource ReSerVation Protocol
• RTP Real Time Protocol
• Multicast routing (IGMP, MOSPF, PIM)
• Multi-Protocol Label Switching (MPLS)

18
The Need for Improved (better) Levels of Service

• Applications
• often create inelastic traffic
• often sensitive to delay
• often sensitive to jitter
• often critical in nature
• generate elastic traffic as well

• Internet Best-Effort Service
• all packets treated equally
• designed for elastic traffic
• no guarantees of bandwidth or throughput
• no guarantees of delay
• no guarantee of jitter (delay variation)

• User Requirements!

19
Delay Sensitivity Criticality
20
Delays in Packet Switched (e.g. IP) Networks

• End-to-end delay (simplified)
• (dprop dtrans dqueue dproc) x Q

• Where
• Propagation delay (dprop)
• Transmission delay (dtrans)
• Queuing delay (dqueue)
• Processing delay (dproc)
• Number of links (Q)

21
So whats the problem?
What makes this so hard? (I.e., what are we going
to focus on in this course.)
22
Delays in Packet Switched (e.g. IP) Networks

• End-to-end delay (simplified)
• (dprop dtrans dqueue dproc) on each link

• Where
• Propagation delay (dprop) d/s
• Transmission delay (dtrans) L/R
• Queuing delay (dqueue) ?
• Processing delay (dproc) ?
• Number of links (Q) ?
