1 Microbiological Surrogate Endpoints in Clinical
Trials of Infectious Diseases
- John H. Powers, MD
- Lead Medical Officer
- Antimicrobial Drug Development and Resistance
Initiatives - Office of Drug Evaluation IV
- Center for Drug Evaluation and Research
- U.S. Food and Drug Administration
2Introduction
- Differentiating clinical practice guidelines and
clinical trials - Definitions of endpoints, clinical endpoints,
surrogate endpoints, and biomarkers - Utility of surrogate and differentiating risk
factors from surrogate endpoints - Strengths and limitations of surrogate endpoints
- Surrogates in the setting of topical antiseptics
- Conclusions
3Clinical Practice and Clinical Trials
- Clinical practice
- use of drug products already proven to be safe
and effective - not concerned with causality of outcomes
- treatment guidelines describe use of products
based on best available evidence (optimally based
on clinical trials) - Clinical trials
- experiments in humans to determine if drugs
products are safe and effective - determine causality of outcomes related to
interventions - provide evidence for formulation of practice
guidelines (not usually vice versa) - need yardstick for determining if products are
safe and effective
4Definitions
- Endpoint - measure of the effect of an
intervention on outcome (e.g. success or failure)
in a clinical trial in treating or preventing a
disease - Several implications
- WHAT to measure - should be clinically relevant
to the disease in question - HOW to measure it - should be able to measure
differences between therapies should they exist
i.e. developing a yardstick to differentiate
effective from ineffective drugs - WHEN to measure it (timing) should be clinically
relevant to the disease - HOW MUCH to measure (magnitude) should correlate
with clinical outcomes that are meaningful to
patients - HOW TO ANALYZE results as method may affect
conclusions
5GI symptoms bother me
Im worried and concerned
Heartburn disturbs my sleep
I cannot bend over or exercise
I cannot eat and drink whatever I like
My whole life is affected
6Definitions
- Disease
- a constellation of signs and symptoms experienced
by the patient - infectious diseases caused by pathogenic
organisms with resultant host response causing
symptoms - Kochs postulates relate to proving cause of
disease, not effect of an intervention - cause and effect are separate considerations
- Patients seek the care of clinicians because of
symptoms, not because of presence of organism - Verheij TJ et al. Fam Pract 19907175-80.
- In prevention trials, seek to prevent symptoms
from occurring - Powers JH Clin Infect Dis 200439S211-17.
7Definitions
- Clinical endpoint direct measure of how a
patient feels, functions or survives - mortality
- resolution or prevention of symptoms of disease
- Surrogate endpoint laboratory measurement or
physical sign used as a substitute for clinical
endpoint - culture results, radiological testing, histology
- other data like PK-PD predicts effect on organism
- Surrogate endpoint by itself does not confer
direct clinical benefit to the patient - NIH Biomarkers Definitions Working Group, Clin
Pharmacol Ther.20016989-95. - International Conference on Harmonization, ICH E9
document
8Definitions
- Biomarkers are analytical tools used to assess
biological parameters - Biomarkers are useful for purposes other than
surrogate endpoints in trials - 1) diagnostic tool - use of test as an inclusion
criteria to define the disease based on presence
of organism (increases specificity of diagnosis) - 2) describe mechanism of action of drug - effect
on organisms is mechanism, not goal of therapy - 3) risk factor for acquisition of disease -
colonization with particular organisms may be
risk factor - 4) risk factor for outcome - indicator of disease
prognosis (HIV viral load and CD4 in HIV) - Sande MA et al. NIH Consensus Conference on HIV,
JAMA 19932702583-89. - 5) surrogate endpoints
9Definitions
- Surrogate - Etymology Latin surrogatus, past
participle of surrogare to choose in place of
another, substitute, from sub- rogare to ask
to put in the place of another - Merriam-Webster Dictionary
- Surrogate endpoint is substituting
microbiological outcomes for clinical outcomes
(both success AND failure) of disease in pivotal
clinical trials to prove drug efficacy - Surrogate endpoints very useful in early drug
development as proof of principle of drug
efficacy and selecting candidate drugs
10Utility of Surrogates
- Useful in phase 3 trials when surrogate endpoint
can be measured sooner than clinical endpoint - When clinical endpoint events are more rare, can
complete trial with smaller sample size - Examples of successful surrogates
- lowering cholesterol to prevent CV disease
- lowering blood pressure to prevent CV disease
- suppression of HIV viral load as surrogate
endpoint in treatment of HIV/AIDS
11HIV Viral Load and CD4 as Risk Factors
12Risk Factor and Endpoints Differ
- Level of HIV viral load and CD4 count both are
risk factors for disease progression in HIV/AIDS - HIV viral load functions well as surrogate
endpoint but CD4 count not as useful as endpoint
in clinical trials - 7 of 8 trials in with positive effect on CD4
showed positive effect on progression to
AIDS/death - BUT effect on CD4 positive in 6 of 8 trials with
negative effect on AIDS progression/death - CD4 count may not change fast enough over time
course of trial - Fleming TR. Stat Med 1994131423-35.
13Strengths and Limitations
- The logic string for topical antiseptic
products - colonization with organisms precede infection
(risk factor) - organisms can cause infection and resulting host
response - since organisms cause infection, eliminating or
decreasing organisms should results in positive
clinical outcomes for patients - So logical, so objective..but is it correct?
- DeGruttola V et al. Ann Intern Med
1997175237-46. - Deductive, not inductive reasoning
- Need to test this logic to see if it is true
- Prentice RL Stat Med 19898431-440.
14Strengths and Limitations
- Reasons why surrogate may not accurately predict
clinical outcomes - unmeasured harms caused by intervention
- unmeasured benefits caused by intervention
- other mechanisms of disease other than those
affected by intervention - issues with measuring surrogate
- issues with measuring clinical outcomes
15Strengths and Limitations
- Surrogate may not take into account unmeasured
- benefits and harms of treatment (not just
correlate) - Knowledge about how a drug achieves clinical
results may be incomplete - Conservation of processes in human body
16Strengths and Limitations
- Unmeasured benefits
- effects of drug other than eradication of
organisms - sub-inhibitory effects of antimicrobials on
organisms - bactericidal therapy not necessary in many
infections - direct effects of antimicrobials on host immune
system - Labro MT et al. Curr Opin Investig Drugs
2002361-8. - Nau R et al. Clin Micro Rev 20021595-110.
- Unmeasured harms
- deleterious effects on host that may promote
infection - replacement of one organism with another that may
cause infection - other sources of infection other than those
affected by drug
17Strengths and Limitations
- Unmeasured benefits
- rifaximin approved for treatment of travelers
diarrhea - drug have similar rate of positive cultures for
pathogens in stool compared to placebo - drug still decreased time to resolution of
diarrhea compared to placebo (for some, not all
organisms) - Steffen R et al. Am J Gastroenterol
2003981073-8. - Unmeasured harms
- dose escalation trial of clarithromycin for
disease due to Mycobacterium avium-intracellulare
in patients with AIDS - higher doses had higher rates of negative blood
cultures (microbiological outcomes) but also
higher mortality (clinical outcomes) - Chaisson et al. Ann Intern Med 1994121905-911
18Strengths and Limitations
Intervention may affect one pathway of disease
and not other pathways that are as important or
more important in resulting clinical outcomes
19Strengths and Limitations
- Other mechanisms of disease not affected by
intervention - several trials show decreased rates of
colonization with S. aureus (microbiological
outcome) with intranasal mupirocin - prevention of infections (clinical outcome) in
patients not lower than placebo - Kalmiejer MD et al. Clin Infect Dis
200235353-8. - Perl TM et al. N Engl J Med 20023461871-7.
- Wertheimer HF et al. Ann Intern Med
2004140419-25. - May be due to infection caused by sources of S.
aureus other than the nose
20Strengths and Limitations
- Issues with accuracy of how surrogate is
measured - it may be reproducible (precision) but is it
telling - us the correct inference (accuracy)?
- what, when, how and magnitude of what is measured
21Strengths and Limitations
- Culture techniques based on methodology from late
1800s with inherent error (same organisms can
give MIC one to tube dilutions different on
serial testing) - Issues with microbiological outcomes
- patient population sampled
- sampling technique
- culture methodology
- when culture is performed (on therapy) and
follow-up period - frequency of sampling
- criteria applied for classification (all or
nothing vs. quantitative)
22Strengths and Limitations
Suppression vs. Eradication
Patient 1
Microbial load
level of detection
Patient 2
baseline
end of study
on therapy
Time
23Strengths and Limitations
- Measurement of clinical endpoint may not
- be relevant based on natural history of disease
- inaccurate measurement of clinical endpoint does
not - justify use of unvalidated surrogate
24Strengths and Limitations
- Example
- Catheter tip decolonization claimed to be
validated as surrogate endpoint for clinical
trials in prevention of catheter-related
bloodstream infections (BSI) based on
correlation of two endpoints - Rijnders BJA et al. Clin Infect Dis
2002351053-8. - Definition of bloodstream infection in some of
these studies is positive blood culture AND a
positive culture of a catheter tip - residual antimicrobial activity in the removed
catheter sufficient to prevent growth from the
cultured catheter segments would substantially
reduce the apparent rate of catheter-related
bloodstream infections. could it be that use of
minocyclinerifampin impregnation prevents growth
from catheters in the microbiology laboratory but
does not eliminate the clinical syndrome of
catheter-related bloodstream infection? - Paterson DL N Engl J Med 19993401761.
- Studies submitted to FDA show no effect on BSI
relative to placebo despite effect on
decolonization
25Correlating Surrogates
clinical success
success with surrogate
- Surrogate must measure effects similarly for
- all drugs studied
26Correlating Surrogates
clinical success
success with surrogate
- Surrogate must measure effects similarly for all
drugs studied - adapted from Baker SG et al. BMC Medical Research
Methodology 2003316.
27Regulatory Issues
- Traditional approval based on surrogate endpoints
only in cases where endpoint already validated to
predict clinical endpoint - Accelerated approval based on surrogate endpoints
(Subpart H, 21 CFR 314.510) - serious and life threatening disease
- surrogate endpoint reasonably likely to predict
clinical outcome - requires confirmatory post-approval trial based
on clinical endpoint (usually from a trial that
is already ongoing) - TFM predates these regulations
28Surrogates and Topical Antiseptics
- Unmeasured harms
- unintended effects on microscopic breakage in
skin may result in greater infection rate
(example of shaving and peri-operative
infections) - Seropian R et al. Am J Surg 1971121251-4.
- effects on common pathogens may be less than that
on marker organisms in skin - selection of resistance to systemic
antimicrobials? - Unintended benefits
- some products may have positive effects other
than those on organisms - effects on common pathogens may be greater than
that on marker organisms used to contaminate skin
29Surrogates and Topical Antiseptics
- Other mechanisms not affected by intervention
- data obtained on surrogate endpoint is from most
superficial layer of skin (stratum corneum of
epidermis) - source of organisms causing infection may not be
the same as site measured by surrogate - skin stripping experiments using cellophane
tape - 12 different sites on body had variable colony
counts of coagulase negative staphylococci - top 5 layers of stratum corneum had higher colony
counts and next 20 layers with stable counts - return of same organisms 18 hours
post-sterilization with alcohol indicates
reservoir of normal skin flora may be below
stratum corneum in hair follicles/glands in
dermis - Brown E et al. J Infect Dis 1989160644-50.
30Skin Anatomy
31Skin Anatomy
32Surrogates and Topical Antiseptics
- Issues with measurement of surrogate
- Population in whom surrogate is measured may be
different from actual use population in
unmeasured ways - Organisms measured not necessarily those that
cause infection - Is timing of measurements relevant to disease
process? - Are conditions of testing same as those that
would be encountered in real life situations? - Does variations in methodology (vigor of
scrubbing, use of neutralizers) affect
consistency of results? - What log reduction is clinically significant? How
to analyze numbers obtained on log reductions?
Changing method of analysis may change clinical
conclusions
33Surrogates and Topical Antiseptics
- Clinical endpoints
- What is data showing correlation of reduction in
bacteria with decrease in infection rates? - What does dose response curve look like for
infection rates and numbers of bacteria? Is this
a threshold effect (lower infection rates below
some amount of bacteria) or a continuous
variable? - Are correlations the same for all types of
products?
34Surrogates and Topical Antiseptics
Dose Response of Numbers of Skin Bacteria and
Infection Rates
Rate of infection
Change in numbers of bacteria on skin
35Surrogates and Topical Antiseptics
Dose Response of Numbers of Skin Bacteria and
Infection Rates
Rate of infection
Change in numbers of bacteria on skin
36Surrogates and Topical Antiseptics
37Conclusions
- Surrogate endpoints must not only correlate
with clinical outcomes but must also take into
account - unmeasured harms and benefits
- methodology and uncertainties in measuring
surrogate - appropriate measurement of clinical endpoint
- Clinical endpoint for efficacy of topical
antiseptic products would be prevention of
infections - condition of testing today are not those of
Semmelweis - Further discussion today on what is known about
surrogates in setting of topical antiseptics
38- Far better an approximate answer to the right
question, which is often vague, than an exact
answer to the wrong question, which can always be
made precise. -
- John W. Tukey (1962)
- Annals of Mathematical Statistics
- 1962331-67.
