Performance Measurement of Linux2'6 kernel

1
Performance Measurement of Linux-2.6 kernel

• Awanish Kumar Trivedi
• Wipro Technologies
• Biswa Ranjan Nayak
• Wipro Technologies

2
Performance Measurement of Linux-2.6 kernel

• Agenda
• Interrupt latency
• Context Switch Latency
• Verifying the Linux-2.6 O(1) scheduler.
• QA

3
Agenda

• Performance Measurement metrics
• Open Source Benchmarks
• Typical case study

4
Performance Metrics

• Interrupt Latency
• What it means?
• Classical Approach.
• Realfeel code.
• Context Switch Overhead
• What it Means?
• How do you measure?
• Linux 2.6 O(1) Scheduler.

5
Interrupt Latency

• Measurement of time from the instant an interrupt
  is generated till it gets serviced.
• Classical Approach- using Parallel Port
• Realfeel Working
• Expected Results

6
Classical Approach

• The interrupt is generated by some external
  source.
• The interrupt handler is called.
• The interrupt generation can be emulated.
• The time difference can be calculated.
• Using a parallel port. Sorting the write and
  interrupt lines.

7
Realfeel Code

• RTC driver is set to generate a periodic
  interrupt with a particular frequency.
• The read call is used so that the application
  blocks till the interrupt is received and time
  taken.
• The difference of time is calculated every time
  from the current reading to the previous reading.
• Ideal case for interrupt generation is well known
  in advance which is subtracted from the latest
  result.
• The difference is used to plot the graph.

8
Expected result of Realfeel Data

• The interrupt latency should be ideally constant.
• The plotted graph should lie almost on the
  x-axis.
• The graph should not show any jitters.

9
Test Target Details
10
Graph plotted for Realfeel
The comparative graph for 2.6.10 vanilla and
wrlinux kernel for realfeel.
11
Comparison for realfeel
The combined graph for 2.6.10 vanilla and wrlinux
kernel for realfeel.
12
Context Switch Overhead

• Time spent in storing and restoring of process
  states for multitasking.
• Lmbench open source Benchmark
• Code by Richard Gooch

13
Linux-2.6 O(1) scheduler

• What is Big O notation ?
• What does O(1) stands for ?
• How to verify that ?
• Plot

14
O(1) scheduler

• O(1) is the Big Oh Notation used to describe
  the worst case analysis for linux-2.6 scheduler.
• The O(1) implies that the performance for the
  scheduling will not degrade as the number of
  process is increased.
• The process context switch overhead and load on
  the target was calculated at regular intervals.
• Slowly the load on the target was increased.
• The data were used to plot the graph.

15
Expected Result

• Since the scheduler efficiency will not degrade
  then the context switch overhead should ideally
  be constant.
• The expected graph should ideally be a vertical
  line starting with an offset value on X axis
  showing the context switch overhead.
• The resultant graph does show that there are
  jitters at specified location.

16
Graph plots for context switch overhead
The comparative graph for 2.6.10 vanilla and
wrlinux kernel for scheduler latency.
17
Plot showing comparison between vanilla and the
wrlinux
The combined graph for 2.6.10 vanilla and wrlinux
kernel for scheduler latency.
18
Bibliography

• http//www.atnf.csiro.au/people/rgooch/benchmarks/
  linux-scheduler.html
• http//brain.mcmaster.ca/hahn/realfeel.c
• http//jaist.dl.sourceforge.net/sourceforge/lmbenc
  h/lmbench-3.0-a4.tgz
