Combining Simulators and FPGAs An Out-of-Body
Experience

• Eric S. Chung, Brian Gold, James C. Hoe, Babak
  Falsafi
• echung, bgold, jhoe, babak_at_ece.cmu.edu

SIMFLEX/PROTOFLEX
2
The RAMP full-system challenge

• RAMP vision for studying systems w/ FPGAs
• functional cycle-accurate simulation
• scalability, speed, flexibility on FPGAs
• full-system (run unmodified binaries OS)

?
?
?
IRQ controller
I/O MMUcontroller
DMAcontroller
CPU
CPU
Terminal
PCI Bus
Memory
Ethernetcontroller
SCSIcontroller
Graphics card
Disk
Disk
Full-sys RAMP will incur large effortyet, not
all behaviors frequently used (e.g., I/O)
3
Combining simulators FPGAs

• Simulators already provide full-system
• ? why not simulate infrequent behaviors (e.g.,
  I/O devices)?

Simulator
FPGA
CPU
CPU
CPU
CPU
Ethernet
Memory
SCSI
Ethernet
SCSI
Memory
disk
disk

• Advantages
• avoid impl. infreq. behaviors ? lowers full-sys
  FPGA development
• low impact on scalability perf. on FPGA

4
Outline

• Motivation
• Migration
• Implementation status
• Conclusion

5
Migration
Target design
FPGA
Simulator
Target objectsex func or timing cpu

• 3 ways to map target object to host
• FPGA-only Simulation-only Migratable
• Migratable objects
• switch modes between FPGA simulator hosts
• target behavior need not be 100 in FPGA mode
• e.g., impl. 80 target behavior in FPGA, 100 in
  simulator

6
Migration example

• Target-to-host mappings
• CPU migratable
• Memory FPGA-only
• Devices SW-only

CPU
FPGA
Memory
SCSI
Example CPU instruction stream
CPU state transfer
Simulator
load
CPU
add
time
multiply
I/O SCSI cmd
SCSI
Memory
add
sub
..
disk
7
Advantages

• Lowers development effort
• avoid bring-up of infrequent behaviors
• migrate validate ref. models from simulator
• tailor impl. to workload (avoid rarely used
  instrs, good for CISC x86)
• Fast scalable
• perf-critical objects on FPGA (eg, CPU, memory)
• scalable for MPs ? add migratable CPUs

FPGA
Simulator
CPU
CPU
CPU
CPU
CPU
CPU
Memory
SCSI
Memory
SCSI
disk
8
Subtleties

• Objects separated in simulator/FPGA interact
• examples interrupts, DMA
• handle by forwarding messages between
  FPGA/simulator
• FPGA-only SW-only mapped objects easy to locate
• migrated objects require tracking

Simulator
FPGA
CPU
CPU
DMA
Memory
SCSI
SCSI
Memory
disk
Forwarded DMA
9
Subtleties

• Objects separated in simulator/FPGA interact
• examples interrupts, DMA
• handle by forwarding messages between
  FPGA/simulator
• FPGA-only SW-only mapped objects easy to locate
• migrated objects require tracking

Option 2Forced migration
Option 1Forwarded interrupt
Simulator
FPGA
CPU
CPU
Interrupt
Memory
SCSI
SCSI
Memory
disk
Cross-host interactions rare ? low impact on
FPGA perf.
10
Subtleties cont.

• Migration cost
• migrating object requires state copy
• e.g., migratable CPU has registers TLBs
• FPGA-to-simulator latency sim. time limits
  migrations/instr
• FPGA simulator asynchrony
• simulated time ticks at different rates in FPGA
  simulator
• must synchronize for deterministic replay
  accurate device timing

11
Outline

• Motivation
• Migration
• Implementation in progress
• Conclusion

12
Implementation status

• Target system
• Sun Firetm 3800 Server (up to 24-way)
• UltraSPARC III ISA
• Solaris 8
• Proof-of-concept software-to-software migration
• run 2 instances of Virtutech Simics
• migration designed tested in 2 weeks
• can migrate on arbitrary behavior (e.g., ADD
  instruction)

13
BlueSPARC core (in progress)

• In-order SPARCV9 core
• supports 144 out of 170 integer instr behaviors
• supports partial MMU w/ I- D-TLBs
• goal 99.999 of instrs behaviors in target
  workloads
• SPEC (mostly user-level), OLTP/DB2 (high TLB
  misses, 40 time in priv-mode)
• CPI ranges 5 to 7 cycles
• synth 15k LUTs on Virtex-II Pro 30, 85MHz,
  12MIPS (worst-case)
• developed in Bluespec HDL, 6000L in 6 weeks
• Core validation
• run RTL in lockstep w/ Simicss UltraSPARC
  simulation model
• workload validation w/ SPEC, OLTP/DB2, OpenSPARC
  verif. suite

14
Migration on FPGA (in progress)
Virtutech Simics
Xilinx XUP Virtex-II Pro 30
Simics UltraSPARC
BlueSPARC
PowerPC
Migration messageinterface
Simulated target devices
DDR memory
ethernet

• PowerPC functions
• core memory initialization from Simics
  checkpoints
• facilitates migration for BlueSPARC
• connects simulated devices to memory (e.g., SCSI
  DMA)

15
Conclusion

• Contributions
• virtualizes infrequent behaviors using simulation
• simplifies full-system FPGA emulator, still
  fast/scalable
• incremental validation from reference system
• Future work
• support migration in RDL?
• adding cores scaling across multiple FPGAs
• We are ready for BEE2
• Thanks! Questions? echung_at_ece.cmu.edu
• PROTOFLEX/SIMFLEX (http//www.ece.cmu.edu/simflex
  )
