Combined Data Mining Approach for Intrusion Detection

1
Combined Data Mining Approach for Intrusion
Detection
Urko Zurutuza, R. Uribeetxeberria, E. Azketa, G.
Gil, J. Lizarraga, M. Fernández
2
Overview
Introduction Anatomy of an attack IDS
alarms Problem description and proposal for
solution
1
Model Description Data Preprocessing Alarm
Clustering Cluster Association Rules Attack
Scenario Generation
3
Experimental Results DARPA 2000 Intrusion
Detection Data Set Real Scenario
4
Conclusions and Further Work
5
3
Introduction
Computer Security research group of Mondragon
University

• Security in embedded systems
• Audit and evaluation mechanisms
• Intrusion detection Honeypots

4
Introduction Anatomy of an Attack
Perimeter Vulnerability Evaluation
Exploitation
Reconnoissance
Gaining access
Covering tracks
No
Scanning
Privilege scalation
Maintaining access
Enumeration
Pilfering
Denial of Service
IDS alarms
5
Introduction
Problem description

• A single global attack generate
• Large quantity of alarms
• Manyfold different alarms
• Manyfold false positives
• Consecuences for system administrators
• Difficulty for understanding all the information
• Too much false information
• Too many alarms to analyze

Solution proposal

• Remove false positives to
• Isolate real alerts
• Find relationships among real alerts to
• Identify known attack steps
• Find relationships among different attack steps
  to
• Identify global attack scenarios
• We can perform the overall process automatically
  using data mining techniques
• Data Mining tool WEKA (Java API )

6
Features describing multiple alarms
Selected features
Pre-processing
Clustering
Clusters
Clusters described by main feature
Clustering
Association
Comparison
Description of traffic patterns and known attack
patterns
Attack sequence
Step 1
Comparison
Chronological ordering
Step 2

7
Model Description
Prelude database
8
Model Description
9
Model Description
10
Experimental results DARPA 2000 Dataset
IDS Alarm logging architecture

11
Experimental results DARPA 2000 Dataset
1.- CLUSTERING
12
Experimental results DARPA 2000 Dataset
2.- ASSOCIATION
1. address_source172.16.114.1 4318 gt
alert_ident472 ip_len56 4318 conf(1) 2.
alert_ident472 4318 gt address_source172.16.114
.1 ip_len56 4318 conf(1) 3. address_source172.
16.114.1 alert_ident472 4318 gt ip_len56 4318
conf(1) 4. address_source172.16.114.1
ip_len56 4318 gt alert_ident472 4318 conf(1)
5. alert_ident472 ip_len56 4318 gt
address_source172.16.114.1 4318 conf(1) 6.
alert_ident472 4318 gt ip_len56 4318 conf(1)
7. address_source172.16.114.1 4318 gt
ip_len56 4318 conf(1)
Summarize and drop redundant rules!!
13
Experimental results DARPA 2000 Dataset
2.- ASSOCIATION
Summarized attack rules
3.- COMPARISON
Codified abstract-level rules
14
Experimental results DARPA 2000 Dataset
3.- COMPARISON
Codified abstract-level rules
Vs.
Atack Traffic Patern rules
15
Experimental results DARPA 2000 Dataset
4.- Chronological Ordering Attack Scenario
Result From 12,064 alarms to 6 meta-alarms
explaining the attack scenario
16
Experimental results Real Scenario
17
Experimental results Real Scenario
1.- CLUSTERING

• 26,660 IDS alarms accumulated in few hours
• EM Algorithm obtained 7 clusters

18
Experimental results Real Scenario
2.- ASSOCIATION

• Apriori association rules algorithm extracts 1133
  rules.
• Rule dedundancy reduction decreases to 60

19
Experimental results Real Scenario
3.- COMPARISON
Codified abstract-level rules
Attack Traffic Patern rules
20
Experimental results Real Scenario
4.- Chronological Ordering Attack Scenario
Result From 26,660 alarms to 6 meta-alarms
explaining the attack scenario
21
Conclusions and Further Work
22
Thank You
?
