Basic Computer Organization

1
Basic Computer Organization

• Chapter 2
• S. Dandamudi

2
Outline

• Basic components
• The processor
• Execution cycle
• System clock
• Number of addresses
• 3-address machines
• 2-address machines
• 1-address machines
• 0-address machines
• Load/store architecture

• Flow control
• Branching
• Procedure calls
• Memory
• Basic operations
• Types of memory
• Storing multibyte data
• Input/Output
• Performance Data alignment

3
Basic Components

• Basic components of a computer system
• Processor
• Memory
• I/O
• System bus
• Address bus
• Data bus
• Control bus

4
Basic Components (contd)
5
The Processor

• Processor can be thought of executing
• Fetch-decode-execute cycle forever
• Fetch an instruction from the memory
• Decode the instruction
• Find out what the operation is
• Execute the instruction
• Perform the specified operation

6
The Processor (contd)

• System clock
• Provides timing signal
• Clock period

1
Clock frequency
7
Number of Addresses

• Four categories
• 3-address machines
• 2 for the source operands and one for the result
• 2-address machines
• One address doubles as source and result
• 1-address machine
• Accumulator machines
• Accumulator is used for one source and result
• 0-address machines
• Stack machines
• Operands are taken from the stack
• Result goes onto the stack

8
Number of Addresses (contd)

• Three-address machines
• Two for the source operands, one for the result
• RISC processors use three addresses
• Sample instructions
• add dest,src1,src2
• M(dest)src1src2
• sub dest,src1,src2
• M(dest)src1-src2
• mult dest,src1,src2
• M(dest)src1src2

9
Number of Addresses (contd)

• Example
• C statement
• A B C D E F A
• Equivalent code
• mult T,C,D T CD
• add T,T,B T BCD
• sub T,T,E T BCD-E
• add T,T,F T BCD-EF
• add A,T,A A BCD-EFA

10
Number of Addresses (contd)

• Two-address machines
• One address doubles (for source operand result)
• Last example makes a case for it
• Address T is used twice
• Sample instructions
• load dest,src M(dest)src
• add dest,src M(dest)destsrc
• sub dest,src M(dest)dest-src
• mult dest,src M(dest)destsrc

11
Number of Addresses (contd)

• Example
• C statement
• A B C D E F A
• Equivalent code
• load T,C T C
• mult T,D T CD
• add T,B T BCD
• sub T,E T BCD-E
• add T,F T BCD-EF
• add A,T A BCD-EFA

12
Number of Addresses (contd)

• One-address machines
• Uses special set of registers called accumulators
• Specify one source operand receive the result
• Called accumulator machines
• Sample instructions
• load addr accum addr
• store addr Maddr accum
• add addr accum accum addr
• sub addr accum accum - addr
• mult addr accum accum addr

13
Number of Addresses (contd)

• Example
• C statement
• A B C D E F A
• Equivalent code
• load C load C into accum
• mult D accum CD
• add B accum CDB
• sub E accum BCD-E
• add F accum BCD-EF
• add A accum BCD-EFA
• store A store accum contents in A

14
Number of Addresses (contd)

• Zero-address machines
• Stack supplies operands and receives the result
• Special instructions to load and store use an
  address
• Called stack machines (Ex HP3000, Burroughs
  B5500)
• Sample instructions
• push addr push(addr)
• pop addr pop(addr)
• add push(pop pop)
• sub push(pop - pop)
• mult push(pop pop)

15
Number of Addresses (contd)

• Example
• C statement
• A B C D E F A
• Equivalent code
• push E sub
• push C push F
• push D add
• Mult push A
• push B add
• add pop A

16
Load/Store Architecture

• Instructions expect operands in internal
  processor registers
• Special LOAD and STORE instructions move data
  between registers and memory
• RISC and vector processors use this architecture
• Reduces instruction length

17
Load/Store Architecture (contd)

• Sample instructions
• load Rd,addr Rd addr
• store addr,Rs (addr) Rs
• add Rd,Rs1,Rs2 Rd Rs1 Rs2
• sub Rd,Rs1,Rs2 Rd Rs1 - Rs2
• mult Rd,Rs1,Rs2 Rd Rs1 Rs2

18
Number of Addresses (contd)

• Example
• C statement
• A B C D E F A
• Equivalent code
• load R1,B mult R2,R2,R3
• load R2,C add R2,R2,R1
• load R3,D sub R2,R2,R4
• load R4,E add R2,R2,R5
• load R5,F add R2,R2,R6
• load R6,A store A,R2

19
Flow of Control

• Default is sequential flow
• Several instructions alter this default execution
• Branches
• Unconditional
• Conditional
• Procedure calls
• Parameter passing
• Register-based
• Stack-based

20
Flow of Control (contd)

• Branches
• Unconditional
• branch target
• Absolute address
• PC-relative
• Target address is specified relative to PC
  contents
• Example MIPS
• Absolute address
• j target
• PC-relative
• b target

21
Flow of Control (contd)
22
Flow of Control (contd)

• Branches
• Conditional
• Jump is taken only if the condition is met
• Two types
• Set-Then-Jump
• Condition testing is separated from branching
• Condition code registers are used to convey the
  condition test result
• Example Pentium code
• cmp AX,BX
• je target

23
Flow of Control (contd)

• Test-and-Jump
• Single instruction performs condition testing and
  branching
• Example MIPS instruction
• beq Rsrc1,Rsrc2,target
• Jumps to target if Rsrc1 Rsrc2

24
Flow of Control (contd)

• Procedure calls
• Requires two pieces of information to return
• End of procedure
• Pentium
• uses ret instruction
• MIPS
• uses jr instruction
• Return address
• In a (special) register
• MIPS allows any general-purpose register
• On the stack
• Pentium

25
Flow of Control (contd)
26
Flow of Control (contd)

• Parameter passing
• Register-based
• Internal registers are used
• Faster
• Limit the number of parameters
• Due to limited number of available registers
• Stack-based
• Stack is used
• Slower
• Requires memory access
• General-purpose
• Not limited by the number of registers

27
Memory

• Memory can be viewed as an ordered sequence of
  bytes
• Each byte of memory has an address
• Memory address is essentially the sequence number
  of the byte
• Such memories are called byte addressable
• Number of address lines determine the memory
  address space of a processor

28
Memory (contd)

• Two basic memory operations
• Read operation (read from memory)
• Write operation (write into memory)
• Access time
• Time needed to retrieve data at addressed
  location
• Cycle time
• Minimum time between successive operations

29
Memory (contd)

• Steps in a typical read cycle
• Place the address of the location to be read on
  the address bus
• Activate the memory read control signal on the
  control bus
• Wait for the memory to retrieve the data from the
  addressed memory location
• Read the data from the data bus
• Drop the memory read control signal to terminate
  the read cycle
• A simple Pentium memory read cycle takes 3 clocks
• Steps 12 and 45 are done in one clock cycle
  each
• For slower memories, wait cycles will have to be
  inserted

30
Memory (contd)

• Steps in a typical write cycle
• Place the address of the location to be written
  on the address bus
• Place the data to be written on the data bus
• Activate the memory write control signal on the
  control bus
• Wait for the memory to store the data at the
  addressed location
• Drop the memory write control signal to terminate
  the write cycle
• A simple Pentium memory write cycle takes 3
  clocks
• Steps 13 and 45 are done in one clock cycle
  each
• For slower memories, wait cycles will have to be
  inserted

31
Memory (contd)

• Some properties of memory
• Random access
• Accessing any memory location takes the same
  amount of time
• Volatility
• Volatile memory
• Needs power to retain the contents
• Non-volatile memory
• Retains contents even in the absence of power
• Basic types of memory
• Read-only memory (ROM)
• Read/write memory (RAM)

32
Memory (contd)

• Read-only memory (ROM)
• Cannot be written into this type of memory
• Non-volatile memory
• Most are factory programmed (i.e., written)
• Programmable ROMs (PROMs)
• Can be written once by user
• A fuse is associated with each bit cell
• Special equipment is needed to write (to blow the
  fuse)
• PROMS are useful
• During prototype development
• If the required quantity is small
• Does not justify the cost of factory programmed
  ROM

33
Memory (contd)

• Erasable PROMs (EPROMs)
• Can be written several times
• Offers further flexibility during system
  prototyping
• Can be erased by exposing to ultraviolet light
• Cannot erase contents of selected locations
• All contents are lost
• Electrically erasable PROMs (EEPROMs)
• Contents are electrically erased
• No need to erase all contents
• Typically a subset of the locations are erased as
  a group
• Most EEPROMs do not provide the capability to
  individually erase contents of a single location

34
Memory (contd)

• Read/write memory
• Commonly referred to as random access memory
  (RAM)
• Volatile memories
• Two basic types
• Static RAM (SRAM)
• Retains data with no further maintenance
• Typically used for CPU registers and cache memory
• Dynamic RAM (DRAM)
• A tiny capacitor is used to store a bit
• Due to leakage of charge, DRAMs must be refreshed
  to retain contents
• Read operation is destructive in DRAMs

35
Memory (contd)

• DRAM types
• FPM DRAMs
• FPM Fast Page Mode
• EDO DRAMs
• EDO Extended Data Out
• Uses pipelining to speedup access
• SDRAMs
• Use an external clock to synchronize data output
• Also called SDR SDRAMs (Single Data Rate)
• DDR SDRAMs
• DDR Double Data Rate
• Provides data on both falling and rising edges of
  the clock
• RDRAMs
• Rambus DRAM

36
Storing Multibyte Data
37
Storing Multibyte Data (contd)

• Little endian
• Used by Intel IA-32 processors
• Big endian
• Used most processors by default
• MIPS supports both byte orderings
• Big endian is the default
• Not a problem when working with same type of
  machines
• Need to convert the format if working with a
  different machine
• Pentium provides two instructions for conversion
• xchg for 16-bit data
• bswap for 32-bit data

38
Input/Output

• I/O controller provides the necessary interface
  to I/O devices
• Takes care of low-level, device-dependent details
• Provides necessary electrical signal interface

39
Input/Output (contd)

• Processor and I/O interface points for exchanging
  data are called I/O ports
• Two ways of mapping I/O ports
• Memory-mapped I/O
• I/O ports are mapped to the memory address space
• Reading/writing I/O is similar to reading/writing
  memory
• Can use memory read/write instructions
• Motorola 68000 uses memory-mapped I/O
• Isolated I/O
• Separate I/O address space
• Requires special I/O instructions (like in and
  out in Pentium)
• Intel 80x86 processors support isolated I/O

40
Input/Output (contd)

• Pentium I/O address space
• Provides 64 KB I/O address space
• Can be used for 8-, 16-, and 32-bit I/O ports
• Combination cannot exceed the total I/O address
  space
• can have 64 K 8-bit ports
• can have 32 K 16-bit ports
• can have 16 K 32-bit ports
• A combination of these for a total of 64 KB
• I/O instructions do not go through segmentation
  or paging
• I/O address refers to the physical I/O address

41
Performance Data Alignment
42
Performance Data Alignment (contd)
Unaligned
Aligned
43
Performance Data Alignment (contd)

• Data alignment
• Soft alignment
• Data is not required to be aligned
• Data alignment is optional
• Aligned data gives better performance
• Used in Intel IA-32 processors
• Hard alignment
• Data must be aligned
• Used in Motorola 680X0 and Intel i860 processors

44
Performance Data Alignment (contd)

• Data alignment requirements for byte addressable
  memories
• 1-byte data
• Always aligned
• 2-byte data
• Aligned if the data is stored at an even address
  (i.e., at an address that is a multiple of 2)
• 4-byte data
• Aligned if the data is stored at an address that
  is a multiple of 4
• 8-byte data
• Aligned if the data is stored at an address that
  is a multiple of 8

Last slide
