Parametric Design using Digital Project

1
Parametric Design using Digital Project

• VBScript / VBA

2
VBScript?

• VBScript
• Microsoft Visual Basic Scripting Edition
• Started as a client-side scripting language to
  create interactive webpages
• Client-side?
• Operations on client in client-server environment
• Scripting language?
• Shorten edit-compile-link-run process
• No compiler, interpreter
• Batch, Unix shell, AutoLisp, VBA

3
VBScript Tutorials

• Functions and Procedures
• Sub statement
• Function statement
• Data types and Variables
• Class

4
Functions and Procedures

• Subroutine
• maintain and write programs by segregating
  related code into smaller, manageable sections
• reduce the number of lines of code
• Sub . . . End Sub Construct
• Function . . . End Function

5
Sub . . . End Sub

• construct is used to define a subroutine that
  is, a procedure that performs some operation but
  does not return a value to its calling program.

Sub cmdButton1_OnClick MsgBox(Hello) End Sub
6
Defining subroutines

• Automatically
• Constructor
• Ex) Class_Initialize
• Defining as an event handler
• executed automatically if it is defined as an
  event handleras a routine that is executed
  whenever some event occurs.
• Referring to it by name
• executed at any time by referring to it by name
  in another part of the script

7
Subroutine names

• The name can contain any alphabetical or numeric
  characters and the underscore character.
• The name must start with a letter, not a numeric
  character or underscore, and it cannot contain
  embedded spaces.
• The name cannot contain any spaces. Use the
  underscore character to separate words to make
  them easier to read.
• The name cannot be a VBScript reserved word, such
  as a VBScript statement.
• Examples
• Sub 123MySub( ) ' Illegal
• Sub My Sub Routine( ) ' Illegal
• Sub MySub123( ) ' Legal
• Sub MySubRoutine( ) ' Legal

8
Function . . . End

• construct is used to define a subroutine that
  is, a procedure that performs some operation and
  return a value to its calling program.

Function CubeIt(x) CubeIt x3 End Function
9
Passing Variables

• allows us to write custom "black box" routines
  that can behave differently depending on where
  the routine has been called from and also on the
  particular data values that the routine receives
  from the calling program.
• Passing by values
• Passing by references

10
Passing Variables

• Sub AnotherSubRoutine( )
• some code. . . .
• mySubRoutine intvar1, strvar2, lngvar3
• more code that executes after mySubRoutine
• End Sub
• Sub mySubRoutine(intDataIn1, strDataIn2, _
• lngDataIn3)
• code which uses incoming data
• End Sub

11
Passing by values

• Sub DoSubroutine( )
• Dim x
• x 10
• Response.Write "In DoSubroutine, x is " x
  "ltPgt"
• CallAnotherSub x
• Response.Write "Back in DoSubroutine, x is "
  x
• End Sub
• Sub CallAnotherSub(ByVal var1)
• var1 var12
• Response.Write "In CallAnotherSub, var1 is "
  var1
• End Sub

12
Passing by references

• Sub DoSubroutine( )
• Dim x
• x 10
• Response.Write "In DoSubroutine, x is " x
  "ltPgt"
• CallAnotherSub x
• Response.Write "Back in DoSubroutine, x is "
  x
• End Sub
• Sub CallAnotherSub(ByRef var1)
• var1 var12
• Response.Write "In CallAnotherSub, var1 is "
  var1
• End Sub

13
Exit statement

• Function functionname(argumentlist)
• . . . some calculation or manipulation
• If condition1 Then
• functionname result of calculation or
  manipulation
• Exit Function
• End If
• . . . perhaps some more code
• If condition2 Then
• functionname result of calculation or
  manipulation
• Exit Function
• End If
• End Function

14
Variable and Data types

• Variable
• allows us to refer to the variable by its name,
  rather than to focus on its implementation
  details
• is a placeholder or recognizable name for a
  memory location
• x 10
• y "Hello World"
• Constant
• keeps the same value throughout its lifetime
• cannot have its value changed throughout the life
  of the program
• Const myConstant 10

15
Declaring Variable and Constants

• VBScript allows the implicit declaration of
  variables
• Recommends to use Dim
• Dim Variable_Name

16
Data types

• VBScript has only a single data type, called a
  variant
• Variants contain many different types of data and
  can automatically select the most appropriate
  data type for the particular context in which it
  is being used

17
Types of Data in Variant

• Empty
• Null
• Boolean
• Byte
• Integer
• Long
• Single
• Double
• Date/Time
• Currency
• String
• Object
• Error

18
Class

• Template for an object.
• Class...End Class construct
• Variable
• Properties
• Method
• Event

19
Class Construct

• Class...End Class
• Class classname
• Class definition
• End Class
• Instantiation an object of a class
• Set objc new classname

20
Class Variables

• Class has variables
• Dim varName1 , varName2...
• Private varName1 , varName2...
• Public varName1 , varName2...
• Dim, Public
• Open to outside
• Private
• Closed to outside

21
Class Properties

• Access wrapper for private variables
• Property Get
• Property Let value
• Property Set reference

22
Class Properties

• Class Computer
• Private modStrType
• Private oOS
• Public Property Let ComputerType(strType)
• modStrType strType
• End Property
• Public Property Get ComputerType( )
• ComputerType modStrType
• End Property
• Public Property Set OperatingSystem(oObj)
• Set oOS oObj
• End Property
• Public Property Get OperatingSystem( )
• Set OperatingSystem oOS
• End Property
• End Class

23
Class Method

• Functions or subroutines in a class
• Class LaptopComputer
• Private modOwner
• Public Property Let CompOwner(strOwner)
• modOwner strOwner
• End Property
• Public Property Get CompOwner( )
• CompOwner modOwner
• End Property
• Public Function GetOwner( )
• GetOwner modOwner
• End Function
• End Class

24
Class Event

• Two events are automatically associated with
  every class you create
• Class_Initialize
• is fired whenever you instantiate an object based
  on this class
• Class_Terminate
• is called when the script engine determines that
  there are no remaining references on an object

25
Statement

• A statement in a program is a basic sentence that
  expresses a simple ideaits purpose is to give
  the computer a basic instruction. Statements
  define the types of data allowed, how data are to
  be manipulated, and the ways that procedures and
  functions work.

26
Statements in VBScript
27
IF Then Else Statement

• If condition Then statements Else elsestatements

• ' Or, you can use the block form syntax
• If condition Then
• statements
• ElseIf condition-n Then
• elseifstatements . . .
• Else    elsestatements
• End If
• If A gt 10 Then A A 1 B B A C C B
• If A gt 10 Then
• A A 1
• B B A
• C C B
• End If

28
Select Case Statement

• Select Case testexpression
• Case expressionlist-n
• statements-n . . .
• Case Else
• elsestatements-n
• End Select
• Dim Color, MyVar
• Sub ChangeBackground (Color)
• MyVar lcase (Color)
• Select Case MyVar
• Case "red" document.bgColor "red"
• Case "green" document.bgColor "green"
• Case "blue" document.bgColor "blue"
• Case Else MsgBox "pick another color"
• End Select
• End Sub

29
For...Next Statement

• For counter start To end Step step
•  statements
• Exit For
•  statements Next
• For I 1 To 10
• For J 1 To 10
• For K 1 To 10
• . . .
• Next
• Next
• Next

30
Do...Loop Statement

• Do While Until condition
•    statements
•    Exit Do
•    statements
• Loop
• Do    statements
• Exit Do
• statements
• Loop While Until condition

31
Do...Loop Statement

• Do Until DefResp vbNo
• MyNum Int (6 Rnd 1)
• ' Generate a random integer between 1 and 6.
• DefResp MsgBox (MyNum " Do you want
  another number?", vbYesNo)
• Loop
• Dim Check, Counter
• Check True Counter 0 ' Initialize
  variables.
• Do ' Outer loop.
• Do While Counter lt 20 ' Inner loop.
• Counter Counter 1 ' Increment
  Counter.
• If Counter 10 Then ' If condition is
  True...
• Check False ' set value of flag
  to False.
• Exit Do ' Exit inner loop.
• End If
• Loop
• Loop Until Check False ' Exit outer loop
  immediately.

32
VBA Tutorials

• VBScript, VBA, VB
• Object Oriented Programming
• Data types
• Class

33
VBA?

• Visual Basic for Application
• Hosted in other application
• Interpreted language

34
What can you do with VBA?

• Creating instances of OLE (ActiveX) objects
  within your code
• Creating classes (reusable custom software
  objects)
• Linking to ODBC databases like Access and SQL
  Server
• Integrating with the messaging API (MAPI) to
  create Exchange/Mail applications
• Integrating with Internet and intranet solutions
• Creating custom dialog boxes and forms
• Storing and retrieving data from the Windows
  registry
• Detecting and handling errors
• Incorporating ActiveX controls into the
  application interface
• Passing data between VBA-enabled applications
  with a minimum of programming and fuss
• Driving a second VBA-enabled application from
  within a first VBA-enabled Application
• And more

35
VBScript vs. VBA

• Weakly typed language vs. Typed
• Early binding
• Binding
• Association of values with identifier
• vs. Late binding
• Integrated Development Environment

36
VBA vs. Visual Basic

• Hosted vs. Independent
• Interpreted vs. Complied
• Platform dependency
• Object?
• An instance of a Class
• An individual unit of run time data storage
• Data member, Method

37
Object Oriented Programming

• OOP is all about programming using something
  called an object
• OOP consists of designing a bunch of classes most
  of which will be used as templates to make
  objects
• The objects will be used to hold data and will be
  initialized with constructors and perform useful
  functions by being asked to run their methods

From CS1322 lecture slide
38
What is an object?

• A chunk of memory which contains some data and
  methods which can operate on the data.
• Something that when created may have had special
  code run to initialize it.
• Something which has additional behavior defined
  by methods which can
• Be passed data via parameters
• Perform calculations/operations which may
• Change some of its data
• Perform some desired operation
• Return the value of some of its data
• Return the results of calculations using both
  data passed in and data contained in the object

From CS1322 lecture slide
39
How do we define different types of objects?

• For each different type of object we write a
  class.
• New classes may be based on existing classes to
  allow code reuse
• A class serves as a blueprint or template
  defining how all objects made from this class
  operate and what data they hold.
• One class may be used to make one or many objects

From CS1322 lecture slide
40
Classes and Objects
Class It describes the form of an object. It is
a template or blueprint. It specifies data
representation, behavior, and inheritance (via
variables, methods and parents)
Object It is an instance of a class. It has a
unique copy of every non-static variable.
(i.e., the instance variables but not
the class variables (those labeled with
static).
Difference between a class and an object of
that class is analogous to the difference
between a type and a variable of that type.
Naming Conventions Classes Identifiers begin
with cap letters for each word in
the identifier, e.g., class GraduateStudent Objec
ts Identifiers begins with lower case letter,
then caps for other words in
identifier, e.g.,
graduateStudentPresident
From CS1322 lecture slide
41
3 key features

• Abstract data types
• Encapsulation of data and behavior
• Classes as templates used to produce 1 or more
  instances or objects
• Inheritance
• Provides for code-reuse
• Polymorphism/Dynamic Binding
• Different objects in the same family may have
  identically named methods
• The language takes care of sorting out the
  correct method to invoke for us

From CS1322 lecture slide
42
Procedural vs. Object Oriented

• Procedural
• We create an array to store some data
• We write a procedure that can be passed an array
  an it will sort it

• Object Oriented
• We create a class that contains an array AND a
  routine that will sort that array
• The data and the behavior (ability to sort) are
  in one "container

From CS1322 lecture slide
43
Data Types in VBA

• Boolean
• Byte
• Integer
• Long
• Single
• Double
• Date/Time
• Currency
• String
• Object
• User Defined type
• Variant

44
Declaring Variables and Constants

• Dim VariableName As datatype
• Private VariableName As datatype
• Public VariableName As datatype

45
Variable scope

• Private
• visible in the entire module, but nowhere else
• Friend
• visible in the entire project and thus has
  project-level scope.
• Public
• visible not only to the project in which it is
  declared, but also to any external project that
  holds a reference to the project

46
Assessing variables

• Public Module Module1
• Public iModulePublic As Integer
• Friend iModuleFriend As Integer
• End Module
• Project1.Module1.iModulePublic 100
• Project1.Module1.iModuleFriend 100

47
Array

• An array is a static structure. That is, once
  declared, its size or number of elements may not
  be changed
• A major advantage of arrays is direct random
  access to any element in O(1) time.
• In general arrays are homogeneous, that is each
  cell holds the same type of thing. This concept
  will be "stretched" when we come to polymorphism.

48
Array Declaration

• Dim myArray(5) As Integer
• myArray Array(12,3,13,64,245,75)
• Dim iDynamicArray() As Integer
• ReDim iDynamicArray(10)

49
Multi Dimensional Array

• Dim arrayname(upperboundDimension1, _
• upperboundDimension2, ....) As Datatype
• Private myArray() As Integer
• Private Sub cmdButtonOne_OnClick
• ReDim myArray(10,5)
• End Sub
• Private Sub cmdButtonTwo_OnClick
• ReDim myArray(4,10,2)
• End Sub

50
Class

• Properties
• Events
• Methods

51
Enumerated Constants

• Public Enum empTypes
• empTypeOne 1
• empTypeTwo 2
• empTypeThree 3
• End Enum
• If iType empTypes.empTypeOne Then
• If iType empTypeOne Then

52
Custom Event

• To report the progress of an asynchronous task
  back to the client application from an
  out-of-process ActiveX EXE component.
• To pass through events fired by the underlying
  control in an ActiveX custom control.
• As a central part of a real-time multiuser
  application in an n-tier client-server
  application. (Incidentally, events cant be fired
  from within a Microsoft Transaction Server
  Context.)
• To receive notification of events fired in
  automation servers.
• To query the user and receive further input.

53
Usage
54
Reference

• OReilly VBScript in a Nutshell, 2nd Edition
