General presentation

1
Electronic Design Services
V 2.0 5 Dec 07
2
Core Competency
3
Design Services

• Product Development
• Re-engineering
• Obsolescence Management
• Hardware Development
• Software Development
• V V
• Value added Services
• PCB Design
• Lab Testing
• RoHS compliance
• Proto Build

Obsolescence Management
Product Dev.
Re-Engineering
S/W Development
H/W Development
V V
Value added Services
Proto Build
4
Product Development

• Full Product life cycle implementation
• Concept to end product
• Design activities include analog digital
  designs, Processor based designs
• Interface circuit development, Power management
• Development of necessary firmware
• Development of Mechanical enclosures.
• Environment testing, EMI/EMC compliance testing

5
Re-Engineering

• Re engineering of the existing product for
  enhancement of features
• Use of state of the art technology
• Maintain the same form factor
• Plug and play solutions
• Develop necessary firmware, software
• RoHS compliance

6
Obsolescence Management

• Provide solution for obsolescence of
  components
• Redesign electronic circuit to interface with
  new components
• Use of CPLDs/ FPGAs to minimize digital circuits
• Redesign of magnetic

7
Hardware , Firmware Development

• Design of hardware boards as per the
• specs
• Procurement of components
• Embedded firmware S/W development, Embedded
  Linux porting
• PCB Layout
• PCB procurement, assembly testing
• Environmental condition testing
• EMI/EMC compliance testing

8
Mobile Gate Communication

MPC5200 Based CPU Module
Radio Module
9
ZigBee Based Development
Sample ZigBee Star Network
MSP430 Controller Board
GSM Antenna
Remote Zigbee module
Siemens MC75 GSM Modem
Zigbee Coordinator Module
10
Software Development

• PC based software development
• Application development using C, C, C, VB,
  ASP .Net technologies
• Extensive use of modeling language Object
  Oriented Technologies
• Use of Rhapsody and Rational Rose
• GUI development
• Web based software, tools development

11
ScanNet
12
ScanNet Summary Page for End User
13
Verification Validation

• Manual testing
• Black box testing
• White box testing
• Extensive use of testing tools like RTRT,
  CANTATA
• Complete SDLC verification

14
Proto Type Build

• Build proto types as P0, P1 , P2 for functional
  test , environmental test and factory acceptance
  test
• Conduct functional tests on P0 models. Run Signal
  integrity , DFM tests and Thermal analysis tests
  as per Specs
• Conduct the required type tests, EMI/EMC tests on
  P1.
• Generate all engineering drawings and assembly
  drawings etc. and finalise as P2 for factory
  acceptance for serial production
• Can take up 10-50 small number proto builds

15
Value Added Services

• PCB Development
• PTH to SMT conversion and manufacturing files
  generation considering DFMS, DFT and compliance
  issues.
• Designing of 2-14 layer PCBs using PCAD 2002 ,
  Cadence Allegro(PCB Design Studio), Cadstar and
  ORCAD packages.
• Compliant to Design for Manufacturability and
  Assembly(DFMA) and Design for Testability(DFT)
  methods.
• PCB Designing following the guidelines of the
  client and IPC standards.
• PCB manufacturing files (Gerber files) generation
  from schematic
• RoHS compliance
• TEST LAB FACILITIES
• Type Tests ,Screening Burn-in,Performance
  Test,Climatic Test,Cold, Dry Heat, Hi/Low
  Temperature Cycling, Steady state, Corrosion and
  Thermal Shock, Durability Test,
  Bump,Vibration,Acceleration,Shock etc. as per
  IS,IEC and MIL
• EMC Compliance Tests facilities available at
  SAMEER centers (Society for Applied Microwave
  Electronics Engineering Research)
• Safety
• Dielectric Strength, Insulation Test,
  Flammability, Radiation etc. as per IEC, EN, UL
  IS standards
• EMI, CE, RE and CS as per relevant CISPR,VDE,
  FCC,IS, EN, IEC Standards

16
Skill Set Hardware

• Skill set Hardware
• Micro-controllers based development using
  Intel, Hitachi, Microchip, TI, ARM, Motorola,
  Rabbit, Infineon, Atmel, Cygnal chipset
• Digital Design
• Analog Design
• FPGA based development in VHDL/Verilog Altera,
  Xilinx
• DSP based development
• Protocols/interfaces RS232, RS422, RS485,
  RF,Ethernet 10/100, GPS, GSM, GPRS, WLAN, cPCI,
  TCP/IP, MODBUS,PROFIBUS, CANopen, IrDA, Zigbee
  and proprietary protocols
• Switch mode power supply design
• RF design
• PCB Design CadStar, Cadence Allegro, PCAD,
  ORCAD, Altium designer

17
Skill Set Software

• Application development in C , C,VB, VC , C
  and .NET
• COM/DCOM implementation
• Assembly language programming
• Development of device drivers
• Communication Protocol Development
• Web enabling Embedded Devices
• Application Development in uCos, WinCE,
  Embedded Linux
• Object Oriented Design and Analysis using
  Rational Tools,
• Rhapsody
• Simulation in Matlab and Labview
• Testing using Cantata , Chipview, RTRT

18
Development Tools

• C51 based Kiel Development Station
• DSP Development Station (TI 5x DSPs)
• TI MSP development Suite
• Motorola Development Suite
• FPGA Tools Xilinx, Altera Platforms, EDK tools
• Microchip Development station
• GPS/GSM/GPRS/WLAN development setup
• ZigBee , RFID development setup
• Matlab, Simulik , tool boxes
• Labview
• Rabbit Dynamic C
• Rhapsody design Development suite
• RTRT, Cantata
• Cadence Allegro v15.0 (Concept HDL, Allegro PCB
  Studio)
• PCAD 2004, ORCAD 9.1Cadstar , Dx Designer, Altium
• RELEX , FMECA tool
• Full fledged ESD protected lab

19
Test Lab Facilities

• The Electronic Test and Development Centers
  (ETDCs) under Standardization Testing Quality
  Certification Directorate (STQC) are National
  Accreditation Labs in India
• Facilities available for various tests like
• Type Tests ,Screening Burn-in,Performance
  Test,Climatic Test,Cold, Dry Heat, Hi/Low
  Temperature Cycling, Steady state, Corrosion and
  Thermal Shock, Durability Test,
  Bump,Vibration,Acceleration,Shock etc. as per
  IS,IEC and MIL
• EMC Compliance Tests facilities available at
  SAMEER centers (Society for Applied Microwave
  Electronics Engineering Research)
• Safety
• Dielectric Strength, Insulation Test,
  Flammability, Radiation etc. as per IEC, EN, UL
  IS standards
• EMI, CE, RE and CS as per relevant CISPR,VDE,
  FCC,IS, EN, IEC Standards

20
Test Lab Facilities

• UL , CE Certification
• TUV Certifying body has an Indian wing at
  Bangalore. All approval tests and certification
  shall be carried out by this agency
• TÜV Rheinland Group evaluates, tests and
  certifies the safety and quality of products in
  virtually all categories from toys to
  state-of-the-art computer equipment and heavy
  industrial machinery.

21
Thank You
