Bioinformatic Databases

1
Bioinformatic Databases

• Microbiology 343
• David Wishart
• david.wishart_at_ualberta.ca

2
Objectives Outline

• The biological data explosion appreciating
  the size scope
• Different types of database knowing which
  database is right for the given job
• The web is your friend (on-line DBs)
• EcoCyc, PDB, Bind, BacMap, etc.
• Using PubMed

3
The U of A Library

• 10.02 million total holdings
• 4.81 million books journals
• 3.69 million microfilms
• 1.39 million maps
• 39,141 journal subs
• 8,000 PhD dissertations
• 12 library bldngs
• 2 Terabytes of data

4
The Library of Congress

• 120 million items in storage
• 54 million manuscripts
• 18 million books
• 12 million photographs
• 4.5 million maps
• 4.4 million technical reports
• 1.1 million PhD dissertations
• 20 Terabytes of data

5
Some Numbers

• 3 scientific journals in 1750
• 120,000 scientific journals today
• 500,000 medical articles/year
• 4,000,000 scientific articles/year
• 14,000,000 abstracts in PubMed derived from 4600
  journals
• 10 billion web pages on Google
• 800,000,000,000,000 bytes on the Web

6
Some Numbers

• A researcher would have to scan 130 different
  journals and read 27 papers per day to follow a
  single disease, such as breast cancer.
• Baasiri, R.A., Glasser, S.R., Steffen, D.L.
  Wheeler, D.A. Oncogene 18, 7958-7965 (1999)

7
Some Graphs
8
A Tidal Wave of Data
9
Different Databases in Bioinformatics

• Sequence Databases
• SNP/mutation DBs
• Structure Databases
• Expression Databases
• Spectral Databases
• Metabolism Databases
• Drug Databases

• Cell/Strain Databases
• Organism Databases
• Interaction Databases
• Function/Ontology DBs
• Bibliographic DBs
• Disease Databases
• Databases of Databases

10
Why So Many Databases?

• To collect and preserve valuable data
• To make data accessible and easily searched
• To standardize data representation or data
  formats
• To organize data into knowledge

11
Different Types of Databases

• Public (web-accessible, downloadable)
• Local or Private (restricted to registered users
  or not web-accessible)
• Archival (anything goes)
• Curated (managed data submission)
• Specialty databases (special interest)
• General databases (wide interest)

12
Where To Go For More Info?
Nucleic Acids Research Web Server Issue (every
Jan.)
http//nar.oupjournals.org/
13
Sequence Databases

• GenBank
• www.ncbi.nlm.nih.gov/
• EMBL/trEMBL/UniProt
• www.ebi.ac.uk/trembl/
• DDBJ
• www.nig.ac.jp/
• PIR
• http//pir.georgetown.edu/
• SwissProt
• www.expasy.ch/sprot/

14
Sequence Databases

• Some specialize in DNA sequence data (GenBank,
  DDBJ)
• Some specialize in protein sequence data (PIR,
  Swiss-Prot, UniProt)
• Some are specific for organisms or classes of
  organisms (yeast, fruitflies, human, certain
  bacteria)

15
Sequence Annotation

• Most sequence databases usually include more
  information than just the raw sequence data
• This additional information is called
  annotation and it may be done either
  automatically or manually
• Annotations include information about
  gene/protein name, length, position, references,
  corrections, etc

16
Different Levels of Annotation

• Sparse typical of most archival DNA sequence
  databases (GenBank, DDBJ)
• Moderate typical of more curated databases or
  protein-specific databases (PIR, trEMBL)
• Detailed typical of organism-specific databases
  or databases with a very high level of curation
  (Swiss-Prot, EcoCyc, BacMap)

17
Different Levels of Database Annotation

• GenBank (large of sequences, minimal
  annotation)
• PIR (large of sequences, slightly better
  annotation)
• SwissProt (small of sequences, even better
  annotation)
• Organsim-specific DB (very small of sequences,
  best annotation)

18
GenBank Annotation
19
Swiss-Prot Annotation
20
Organism-specific Databases

• Flybase
• http//flybase.harvard.edu/
• ENSEMBL (human)
• http//www.ensembl.org/
• CYGD (yeast)
• http//www.mips.biochem.mpg.de/proj/yeast/
• BacMap (all bacteria)
• http//wishart.biology.ualberta.ca/BacMap/
• EcoCyc (E. coli)
• http//ecocyc.org

21
The EcoCyc Database
22
The EcoCyc Database

• EcoCyc is a scientific database for the bacterium
  E. coli K12 MG1655
• The EcoCyc project assembles its data via
  literature-based curation of the entire genome
  along with information on transcriptional
  regulation, transporters, and metabolic pathways
• Actively developed since 1999

23
The EcoCyc Database

• Users may query the database for E. coli
  sequences, pathways, genes, reactions, compounds,
  metabolic charts and gene expression data
• Supports sequence searches and interactive
  visualization of key genomic and proteomic
  features

24
The EcoCyc Database

• EcoCyc supports the visualization of
• gene layouts within the E. coli chromosome
• individual biochemical reactions
• a complete biochemical pathway (with compound
  structures
• Users may display an enzyme, the reaction that
  the enzyme catalyzes, or the gene that encodes
  the enzyme

25
EcoCyc Statistics
26
Structure Databases

• RCSB-PDB
• http//www.rcsb.org/pdb/
• MSD
• http//www.ebi.ac.uk/msd/index.html
• CATH
• www.biochem.ucl.ac.uk/bsm/cath/
• SCOP
• www.scop.mrc-lmb.cam.ac.uk/scop/

27
Sequences vs. Structures
200000
160000
120000
Sequences
Structures
80000
40000
0
28
Protein DataBank (PDB)
http//www.rcsb.org/pdb/Welcome.do
29
Looking at E. coli Trx (2trx)
30
Homework

• Explore the PDB, click on some of the links, try
  the visualization tools
• Use the advanced search mode to find out how many
  proteins have been solved by NMR that have
  between 200 and 350 residues
• Find out how many structures are similar (lt3 Angs
  RMSD) to 2trx

31
Metabolism Databases

• KEGG
• http//www.genome.ad.jp/kegg/metabolism.html
• Roche/Boeringer
• http//www.expasy.org/cgi-bin/search-biochem-index

• EcoCyc
• http//ecocyc.org/
• WIT
• http//wit.mcs.anl.gov/WIT2/

32
Interaction Databases

• BIND
• http//www.bind.ca/
• DIP
• http//dip.doe-mbi.ucla.edu/
• PIM
• http//www.hybrigenics.fr/
• PathCalling
• http//portal.curagen.com/extpc/com.curagen.portal
  .servlet.Yeast

33
Bibliographic Databases

• PubMed Medline
• http//www.ncbi.nlm.nih.gov/PubMed/
• Science Citation Index
• http//isi4.isiknowledge.com/portal.cgi
• Your Local eLibrary
• www.XXXX.ca
• Current Contents
• http//www.isinet.com/isi/

34
Bibliographic Databases

• Research paper from author X
• Sequence from gene X in organism Y
• All information about organelle W in model
  organism Y
• All information about disease X caused by microbe
  Z
• Orthologs of disease gene Y in other model
  organisms

35
Where to go? PubMed
http//www.ncbi.nlm.nih.gov/PubMed/
36
PubMed

• Allows users to search by journal, key words,
  titles etc.
• Uses MeSH (Medical SubHeadings) to allow
  automated search of synonyms (renal transplant
  kidney transplantation)
• API available to query PubMed automatically and
  remotely
• Few users know how to use PubMed properly or to
  its full extent

37
ouellette bf au AND yeast
Details
38
(No Transcript)
39
MeSH Medical Subject Heading
("ouellette bf"au AND (("yeasts"MeSH Terms OR
"saccharomyces cerevisiae"MeSH Terms) OR
yeastText Word))
40
Integrated Text/Sequence Searching with Entrez
Wishart DS au AND coli
41
Results
Click Here!
42
(No Transcript)
43
PubMed Icons
44
Results
Click Here!
45
(No Transcript)
46
How Do You Search Sequence Databases?

• Most kinds of non-biological databases are
  designed to be searched using exact matches of
  dates, keywords or numbers
• Sequence databases are different in that we only
  want to or only can query them with approximate
  or inexact matches this is a challenging
  problem
• Next Lecture Sequence Searching

47
Sample Exam Question

• Which database(s) would you use to find out about
  E. colis pyruvate synthase
• A) structure
• B) reactions
• C) interacting partners
• D) enzymology
• E) sequence variations
