Control

1
Control

• Some Material taken from RobotSubsumption.pdf

2
Remember Where Are We Going?
Sumo-Bot competitions
3
Controlling Robot Movement Based on
Photo-Resistor Readings

• ' ----- Constants ------------------------------
  ---------
• LeftDark CON 108
• RightDark CON 114
• LeftWhite CON 20
• RightWhite CON 22
• ' Average light sensor value
• LeftThreshold CON LeftWhite LeftDark / 2
• RightThreshold CON RightWhite RightDark / 2
• ' ----- Variables ------------------------------
  ----------
• timeLeft VAR Word
• timeRight VAR Word
• ' ----- Main Routine ---------------------------
  ---------
• DO
• GOSUB Test_Photoresistors
• GOSUB Navigate
• LOOP

4
Code

• ' ----- Subroutine - Test_Photoresistors
  --------------
• Test_Photoresistors
• HIGH 6 ' Left RC time measurement.
• PAUSE 5
• RCTIME 6, 1, timeLeft
• HIGH 3 ' Right RC time measurement.
• PAUSE 5
• RCTIME 3, 1, timeRight
• RETURN

5
Code

• ' ----- Subroutine - Navigate to avoid light
  -------------
• Navigate
• IF (timeLeft lt LeftThreshold) AND (timeRight lt
  RightThreshold) THEN
• PULSOUT 13, 650 go backwards
• PULSOUT 12, 850
• ELSEIF (timeLeft lt LeftThreshold) THEN
• PULSOUT 13, 800 go right
• PULSOUT 12, 600
• ELSEIF (timeRight lt RightThreshold) THEN
• PULSOUT 13, 600 go left
• PULSOUT 12, 800
• ELSE
• PULSOUT 13, 850 go forwards
• PULSOUT 12, 650
• ENDIF
• PAUSE 20
• RETURN

6
Finite State Machine (FSM) Representation
both high
left low
right low
both low
7
Controlling Robot Movement Based on Proximity
Measurement

• ' STAMP BS2
• ' PBASIC 2.5
• ' ----- Pins -----------------------------------

• pingPin PIN 10
• ' ----- Variables -----------------------------
• irDetectLeft VAR Bit
• irDetectRight VAR Bit
• sonarForward VAR Bit
• pulseCount VAR Byte
• rawDist VAR Word
• ' ----- Constants ------------------------------
  -----
• RawToIn CON 889 ' 1 / 73.746 (with )
• Scale CON 200 ' raw x 2.00 uS

8
Code

• ' ----- Main Routine ---------------------------
  --------
• DO
• GOSUB Read_IR
• GOSUB Read_Sonar
• IF (sonarForward 0) THEN
• GOSUB Forward_Pulse
• ELSEIF (irDetectLeft 0) THEN
• GOSUB Turn_Left
• ELSEIF (irDetectRight 0) THEN
• GOSUB Turn_Right
• ELSE
• GOSUB Forward_Pulse
• ENDIF
• LOOP

9
Code

• ' ----- Subroutines ----------------------------
  ---------
• Read_IR
• FREQOUT 8, 1, 38500
• irDetectLeft IN9
• FREQOUT 2, 1, 38500
• irDetectRight IN0
• RETURN
• Read_Sonar
• PULSOUT pingPin, 5 ' activate sensor
• PULSIN pingPin, 1, rawDist ' measure echo pulse
• rawDist rawDist / Scale ' convert to uS
• rawDist rawDist / 2 ' remove return trip
• IF (rawDist RawToIn) lt 36 THEN
• sonarForward 0
• ELSE sonarForward 1 ENDIF
• RETURN

10
Code

• ' ----- Subroutines ----------------------------
  ----------
• Forward_Pulse
• PULSOUT 13, 850
• PULSOUT 12, 650
• RETURN
• Turn_Left
• PULSOUT 13, 650
• PULSOUT 12, 650
• RETURN

11
Code

• ' ----- Subroutines ----------------------------
  ----------
• Turn_Right
• PULSOUT 13, 850
• PULSOUT 12, 850
• RETURN
• Back_Up
• PULSOUT 13, 650
• PULSOUT 12, 850
• RETURN

12
Finite State Machine (FSM) Representation
13
How to Put It Together?
No Obj
Obj left
Obj right
Obj forward
Read IR sonar
Go forward
turn left
turn right
go forward
both high
left low
right low
both low
14
Possible Problems

• Jerky or halting movement
• Chase object over boundary
• Never detect opponent
• More?

15
Possible Solution

• Subsumption Architecture
• A programming process by which one behavior
  subsumes, or over-rides another based on an
  explicit priority that we have defined. First
  described by Dr. Rodney Brooks in "A robust
  layered control system for a mobile robot, IEEE
  Journal of Robotics and Automation., RA-2, April,
  14-23, 1986.
• FSM with exit conditions

16
FSM
17
Alternative FSM
Go forward
turn left
turn right
go forward
18
Program High-Level Outline

• Declare pin assignments, constants and variables
• Initialize thresholds
• Wait the required start delay
• Read boundary line sensors and move accordingly
• If the boundary line is not detected, read
  proximity sensors and move accordingly
• Repeat steps 4 and 5 until completion

19
Main Loop

• Do
• GOSUB Read_Line_Sensors
• IF (lightLeft lt leftThresh) AND (lightRight lt
  rightThresh) THEN
• GOSUB About_Face '
  boundary ahead
• ELSEIF (lightLeft lt leftThresh) THEN
• GOSUB Spin_Right
  ' boundary to left
• ELSEIF (lightRight lt rightThresh) THEN
• GOSUB Spin_Left
  ' boundary to right
• ELSE
• PULSOUT LMotor, LFwdFast
• PULSOUT RMotor, RFwdFast
• GOSUB Search_For_Opponent
• ENDIF
• Loop

20
Possible Enhancements

• Optimize the position of the sensors
• Optimize your mechanical design for fighting
• Consider using lego components including motors
• Design against being pushed out of the ring
• Optimize the code to maximize bot performance
• Evaluate tradeoffs in movement choices and sensor
  reading
• Optimize the programming constructs that you use
  to increase processing speed
• BRANCH value, (Case_0, Case_1, Case_2)
• LOOKUP Index, (Value0, Value1, ...ValueN),
  Variable
• LOOKDOWN Target, ComparisonOp Value0, Value1,
  ...ValueN, Variable
