Scalability Considerations for Programmable Networks

1
Scalability Considerationsfor Programmable
Networks

• Jim Griffioen
• Laboratory for Advanced Networking
• University of Kentucky, USA
• Collaborator Prof. Ken Calvert
• Students Su Wen, Andy Martin, Najati Imam,
  Muthulakshmi Muthukumaraswamy

Research supported by DARPA and Intel
2
Programmable Services(Outline)

• Background and problem description
• Design goals and consequences
• Overview of ESP, a lightweight network service
• A simple example
• Engineering considerations
• Other uses
• Status

3
The Internet

• The Internet has proven itself to be a robust,
  scalable, and flexible communication
  infrastructure
• Simple service abstraction
• Basic service is useful to a wide range of
  applications
• Additional services must be implemented at
  end-systems (end-to-end principle)
• Best-effort service
• Service can be implemented with low cost
• Processing Cycles can route packets quickly
• Router State aggregates router state
• Result Can support hundreds of thousand of flows
  and millions of end-systems

4
The Evolving Internet

• New and emerging applications require new
  network-level services not supported by the
  Internet Protocol
• Examples include
• Flow Prioritization (forwarding/dropping/routing)
• Congestion management (RED, ECN)
• Reliable dissemination (PGM)
• Specification-based anycasting
• Layered multicasting (RLM)
• Scalable aggregation services (Concast)
• Single source multicast (Express)
• .... And many more application specific
  services .

5
New Service Approaches

• Closed Approach Rely on router vendors to add
  new application-specific services to their
  equipment
• Extremely Open Approach Allows end-systems to
  dynamically load arbitrary code into network
  routers
• Application Layer Approach Implement new
  services soley at the application layer without
  involving the network layer

6
Basic Router Functions
receive
Lookup enqueue
transmit
Routing Table
congestion control
7
New Service Approaches

• Closed Approach Rely on router vendors to add
  new application-specific services to their
  equipment
• Extremely Open Approach Allows end-systems to
  dynamically load arbitrary code into network
  routers
• Application Layer Approach Implement new
  services soley at the application layer without
  involving the network layer

8
Programmable Router I
transmit
execute
receive
Virtual Machine
program
input
state store
9
Programmable Router II
transmit
execute
Active Application
Virtual Machine
state store
10
New Service Approaches

• Closed Approach Rely on router vendors to add
  new application-specific services to their
  equipment
• Extremely Open Approach Allows end-systems to
  dynamically load arbitrary code into network
  routers
• Application Layer Approach Implement new
  services only at the application layer without
  involving the network layer

11
A New Approach (ESP/LWP)

• We need a new approach, a middle ground, that
  opens the traditionally opaque network layer
  just enough.
• We want to allow end-systems to extract
  information about the network or control the way
  the network processes/handles packets without
  exposing too much or creating scalability or
  security problems

12
Our Design Goals

• A programmable network service that has IP-like
  characteristics
• Flexible
• Applicable to more than one kind of problem,
  including presently unknown problems
• Useful
• Deployable today
• Solves (or assists in solving) one or more real
  problems
• Scalable
• Can potentially be used by every end system
• Accomodates 100 000 simultaneous flows
• Robust
• Best effort

13
Requirements

• Allow user-specified information to be stored,
  modified, retrieved inside the network
• Necessary to solve interesting problems
• Too cheap to meter
• Service must be accessible without special
  authorization
• Crypto authentication/access policies dont scale
  to 100K flows
• Negligible management overhead
• DoS-resistance
• Leverage existing IP forwarding infrastructure
• Dont re-invent this wheel
• Necessary for deployability

14
User-controlled State

• Conventional wisdom Not scalable
• Too expensive to provide for 100K flows
• Overhead of managing setup, soft-state refresh,
  garbage collection
• Limiting factors
• Time-space product of memory usage (per flow)
• Signaling overhead and robustness against errors
• Goal
• Bound the Time-Space product
• Reduce or avoid signaling overhead
• Expect and tolerate errors

15
Per-Packet Processing

• Centralized computation at routers does not scale
• Cannot assume all packets processed by a single
  processor
• Need per-port processing
• Should be comparable to IP forwarding
• Approximately constant cost per packet (i.e.,
  active network capsules are not reasonable)
• Hardware-friendly
• Goal
• Bounded per-packet processing costs
• Processing may not modify the IP header!
• Instructions may modify packet payload or state
  store

16
Ephemeral State Processing

• ESP Solution
• fixed-lifetime state store
• no management overhead
• fixed-length computations
• ESP Components
• 1) Ephemeral State Store
• Associative memory set of (tag, value) pairs
• Fixed size tags and values (e.g. 64 or 128
  unstructured bit strings)
• Tags ? names of variables
• Tags randomly selected gt private stores
• Bindings persist for a (short) fixed time??, then
  vanish
• Bindings cannot be refreshed
• No management overhead

17
Ephemeral State Processing

• 2) Set of packet-borne instructions
• Fixed-length computations (one per packet)
• create/update bindings
• update fields in packet payload (only)
• operands control behavior
• On termination, forward or discard packet
• 3) Wire protocol
• Instructions are carried in specially marked ESP
  packets recognized and executed hop-by-hop by
  routers on the way to the destination
• Contain the instruction to execute and its
  parameters
• Piggy-backed computations are possible

18
ESP Probes

• Two Common Types of ESP Probes
• Setup Probe
• create or modify value bindings for the given ESP
  tags
• Collect Probe
• retrieve values associated with the given ESP tags

19
Example Nack Suppression
1. Sender multicasts packet w/ seq N
20
Example Nack Suppression
21
Example Nack Suppression
Count-filter (CF) instruction
Operands Counter tag c Threshold
value thr
if (c ? ?) c 1 fwd else if (c lt pkt.thr)
c fwd else discard
(N,1)
(N,1)
(N,1)
2. Receivers who did not receive pkt N send
Nack with piggybacked ESP instruction CF
22
Example Nack Suppression
Count-filter (CF) instruction
Operands Counter tag c Threshold
value thr
if (c ? ?) c 1 fwd else if (c lt pkt.thr)
c fwd else discard
(N,1)
(N,1)
(N,1)
(N,2)
(N,2)
23
Example Nack Suppression
Count-filter (CF) instruction
Operands Counter tag c Threshold
value thr
if (c ? ?) c 1 fwd else if (c lt pkt.thr)
c fwd else discard
(N,1)
(N,1)
(N,1)
(N,2)
(N,2)
(N,2)
24
Another Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
D
S
r1
r2
r3
Stimulus
C
E
Send COUNTCH use tag c
Time0
25
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
D
S
r1
r2
r3
C
E
Send COUNTCH use tag c
Time1
26
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
D
S
r1
r2
r3
C
E
Send COUNTCH use tag c
Time2
27
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
D
S
r1
r2
r3
(c,1)
C
E
Send COUNTCH use tag c
Time3
28
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
(c,1)
D
S
r1
r2
r3
(c,1)
(c,1)
C
E
Send COUNTCH use tag c
Time4
29
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
(c,1)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,1)
C
E
Send COUNTCH use tag c
Time5
30
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
(c,2)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,2)
C
E
Send COUNTCH use tag c
Time6
31
Example Finding Slowest ReceiverPhase 1
If (c ? ?) c discard else c1 forward
COUNTCH instruction
B
A
(c,3)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,2)
C
E
Send COUNTCH use tag c
Time7
32
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,3)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,2)
C
E
Send COLLECT use tags c,v
Time8
33
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,3)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,2)
C
E
Send COLLECT use tags c,v
Time9
34
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,3)
(c,1)
D
S
r1
r2
r3
(c,2)
(c,2)
C
E
Send COLLECT use tags c,v
Time10
35
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,3)
(c,1)
D
S
r1
r2
r3
(c,1) (v,3)
(c,2)
C
E
Send COLLECT use tags c,v
Time11
36
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
5
(c,3)
(c,1)
D
S
r1
r2
r3
(c,1) (v,3)
(c,1) (v,2)
C
E
Time12
37
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,2) (v,5)
(c,1)
D
2
S
r1
r2
r3
(c,1) (v,3)
(c,1) (v,2)
C
E
Time13
38
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,1) (v,2)
(c,1)
D
S
r1
r2
r3
4
(c,1) (v,3)
(c,1) (v,2)
C
E
Time14
39
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,0) (v,2)
(c,1)
D
S
r1
r2
r3
(c,1) (v,3)
(c,1) (v,2)
C
E
Time15
40
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,0) (v,2)
(c,1)
D
S
r1
r2
r3
(c,1) (v,3)
(c,0) (v,2)
C
E
Time16
41
Example Finding Slowest ReceiverPhase 2
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,0) (v,2)
(c,1)
D
S
r1
r2
r3
(c,0) (v,2)
(c,0) (v,2)
C
E
Time17
42
Example Finding Slowest ReceiverResult
v min(v,pkt.v) if (--c 0) pkt.v v
forward
COLLECT instruction
B
A
(c,0) (v,2)
(c,0) (v,2)
D
S
r1
r2
r3
2
(c,0) (v,2)
(c,0) (v,2)
C
E
Time18
43
Wire Protocol
IP
Op Code
Standalone
Flow ID
RA ProtoESP
Loc
Err
Operands
Piggyback
e.g. RTP

• Location field specifies where processing occurs
• (and where state is stored)
• Input port
• Output port
• Both
• Neither (aborted instruction)
• Centralized context
• Flow ID sorts packets for serial execution
• Error field carries error code from exceptions

44
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Normal IP Output Processing
45
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Normal IP Output Processing
46
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Input Context
Normal IP Output Processing
47
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Input Context
Normal IP Output Processing
48
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Input Context
Normal IP Output Processing
Both Contexts
49
Input/Output/Central Processing Contexts
Switch Fabric
ESP
Output Context
Normal IP Input Processing
Input Context
Normal IP Output Processing
Both Contexts
Central Context
50
Engineering ESP

• Tag, value sizes
• 64 bits yields acceptably low collision
  probabilities
• Store capacity is independent of tag size
• Setting store lifetime ?
• Store capacity maximized by minimizing ?
• For scalability minimize ?
• But need to be able to complete useful
  computations
• For robustness maximize ?
• 10 seconds (enough for 2-3 round-trips through
  the network)
• Challenges
• Wire-speed implementation
• Minimize store access time
• Minimize store cost

51
Probability of Tag Collision (64 bits)
18 20 22 24
26 28 30
52
Prototype Status

• FPGA
• Microcoded processor small ESS
• Extendable ESP instruction set
• Non-pipelined proof-of-concept
• Design runs full speed on 100MHz Virtex chip
• ESS 6 cycle access time
• Network Processor
• ESP/ESS Running on StrongARM
• Moving to ?Engines
• Software ESS
• 2 ?sec access time

53
H/W Ephemeral State Processor
Input Packet
Output Packet
Packet Register
Input Control
Output Control
Macro Controller
? Instruction Store
Ephemeral State Store
? Con- troller
? Instruction Reg
Tag Registers
Value Registers
Location Registers
ALU
54
Network Processor Implementation
Router

• Per-port ESP facility
• Transparent to router
• Intel BridalVeil IXP1200 board
• 8 100M Ethernet ports
• ESP/ESS running on StrongARM core
• 6 microengines, four threads each
• SRAM DRAM
• Moving to ?Engines
• Software ESS
• 2 ?sec access time

55
Leveraging ESP

• Observation
• Application-specific processing often only needed
  at a few nodes
• Idea
• Use ESP to identify where processing needs to
  occur
• Deploy functionality directly from the end-systems

56
Lightweight Packet Processing Modules

• Simple, pre-defined functions in routers
• Enabled by end systems via signaling
• Signaling protocol identifies
• the functionality to be enabled
• the parameters to be used by the function
• the packets to apply the processing to
  (classifier)
• a timeout value
• Signaling independent of forwarding (not
  hop-by-hop)
• Note can use direct point-to-point
  authentication

57
Dup() An Example LWP Module

• dup() - a simple duplication function
• snoop specially marked packets (the signaling
  protocol identifies which packets)
• duplicate the packet
• change source and destination in the new
  packets IP header (destination specified by the
  signaling protocol)
• forward the new packet

58
Existing Multicast Services

• IP multicast
• Transmit a single packet that is delivered to
  multiple destinations
• Advantages
• Single address abstraction
• Bandwidth savings
• Scalability - (anonymity/best-effort)
• Drawbacks
• Network defines the abstraction (group membership
  and topology)
• Protocol Heterogeneity

59
Existing Multicast Services

• Application-Level Multicast
• Requires no network-level support
• End-systems construct overlay networks to connect
  group members
• Advantages
• Membership and topology controlled by app
• Provides multicast service everywhere there is
  unicast service
• Drawbacks
• Not particularly efficient
• Not scalable

60
New Building Block Services

• Our goal achieve the best of both
• Greater flexibility and control in developing
  network services for applications
• Performance and scalability similar to that of
  the network-based solutions
• Use simple building block services that give
  applications very limited control over the
  network to
• invoke lightweight packet processing modules at
  routers
• initiate ephemeral state probes that compute or
  gather information about the network

61
An Example Multicast Implementation

• Sender maintains the tree topology
• For multicast delivery
• Sender activates dup()s at each branch point
• Data transmitted hop-by-hop

dup?X() -- dup() that copies data to x
B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
D
S
r1
r2
r3
BP children r1 r3, B r3 A, C, D
C
E
62
An Example Multicast Implementation

• Q How does the sender know where to insert the
  dup() function?
• Caveat Dont want to know network topology
• A Through Ephemeral State Processing (ESP)

dup?X() -- dup() that copies data to x
B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
D
S
r1
r2
r3
BP children r1 r3, B r3 A, C, D
C
E
63
Tree Construction

• Finding the new Branch Point (BP)
• The sender multicasts a Setup ESP Probe

B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
(next, r3)
S
D
r1
r2
r3
C
Setup Probe If no dup() next pkt.dst
E
64
Tree Construction

• Pinpoint the new BP
• unicast to the new receiver (E)

B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
(next, r3)
S
D
r1
r2
r3
C
E
(pkt.best, r1) (pkt.next, null)
(pkt.best, null) (pkt.next, null)
65
Tree Construction

• Pinpoint the new BP
• unicast to the new receiver (E)

B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
(next, r3)
S
D
r1
r2
r3
C
E
66
Tree Construction

• Pinpoint the new BP
• unicast to the new receiver (E)

B
A
dup?A() dup?D() dup?C()
dup?B() dup?r3()
(next, r3)
S
D
r1
r2
r3
C
E
67
A Sender-Managed Multicast Tree

• Sender updates topology

B
A
dup?A() dup?D() dup?C()
dup?r3() dup?E()
dup?B() dup?r2()
S
D
r1
r2
r3
C
E
