Title: ENERGY


1
ENERGY
2
Topics to be addressed
  • Energy sources that fuel our civilization
  • History of energy use
  • Patterns of energy production and consumption
  • Crude oil, coal, natural gas, and nuclear energy
  • Environmental, political, and social impacts of
    fossil fuel use

3
Energy sources used today
4
  • Growth in coal has slowed, but oil and gas are
    still rising.

Figure 17.5
5
Canadians are the highest per-capita energy
users on planet Earth !
CLIMATE
DISTANCES
INDUSTRY
LIFESTYLE/WEALTH
6
Figure 17.3
7
(No Transcript)
8
(No Transcript)
9
OIL
  • Hydrocarbons
  • Found in sedimentary rock
  • Remains of prehistoric animals, forests
  • and sea floor life (FOSSIL FUELS)
  • Toxic to wildlife (spills)
  • Climate change
  • Air pollution and acid rain

10
Canadian production about 3 million
barrels/day (ie., now red on map!)
11
Fossil fuels
  • These are fossils in the sense that they are made
    of remnant decayed material from ancient
    organisms.
  • Compressed tissues of plants (and some animals)
    from 100500 million years ago store chemical
    energy from photosynthesis.
  • This greatly concentrated energy is released when
    we burn coal, oil, or gas.

12
Fossil Fuels
  • Anaerobic (without oxygen) decomposition is
    required for fossil fuel formation.
  • (Aerobic decay in presence of oxygen)
  • Anaerobic environments exist at the bottom of
    the ocean, in deep lakes, and in swamp sediments.

13
FOSSIL FUEL FORMATION
  • Plants and animals die
  • Organic material settles in anaerobic site and is
    partly decomposed
  • Organic material is buried
  • Heat and pressure alter chemical bonds
  • Coal, gas, oil formed

Figure 17.6
14
  • Coal Compressed under high pressure to form
    dense carbon structures.
  • Natural gas Primarily methane, CH4, is produced
  • By bacteria near surface
  • By heat and pressure deep below ground
  • Crude oil Sludgelike mix of hundreds of types of
    hydrocarbon molecules. Forms at temperatures and
    pressures found 1.53 kilometers below ground.

15
Alaskas North Slope
The ANWR National Wildlife Reserve Contentious
US Issue
Figure 17.1
16
Distribution of Conventional Fossil Fuel Reserves
Figure 17.8
17
Distribution of Conventional Fossil Fuel Reserves
  • Saudi Arabia has the most oil.
  • Russia has the most natural gas.
  • The U.S. has the most coal.

18
Oil Drilling
  • Liquid oil exists in pores in rock deep
    underground.
  • We must drill into rock and extract oil by using
    a pressure differential.
  • The more oil is extracted, the harder it is to
    extract

19
Refining Crude Oil
  • Crude oil from the ground is a messy mix of
    hundreds of hydrocarbons.
  • It is put through a refining process to segregate
    different components.
  • Small-chain hydrocarbons boil at cooler
    temperatures in a distillation column, isolating
    lighter weight oils (e.g., butane).
  • Long-chain hydrocarbons boil at hot temperatures,
    isolating heavier oils (e.g., lubricating oils).

20
Refining crude oil
21
Petroleum Products
  • Refined components of crude oil are used to
    manufacture many of the material goods we use
    every day.
  • Petroleum products include
  • Helmet, water bottle, sunglasses, clothing,
  • sunscreen, gear and chain grease

Figure 17.11
22
Oil Conservation
  • Although oil is a limited resource, prices have
    remained low enough that few people feel the need
    to conserve
  • Conservation measures taken in the 1970s
    resulting from fears of oil shortages were mostly
    abandoned, but recent price increases may cause
    history to repeat itself
  • As oil supplies dwindle, conservation will again
    become popular.

23
  • Geologist M. King Hubbert predicted U.S. oil
    production would peak around 1970 and then
    decline.
  • He was only a few years off.

Figure 17.15a
24
Depletion of Oil Reserves
  • World oil reserves are a finite resource as well.
  • Some observers predict they have peaked.

Figure 17.15b
25
Vehicle Fuel Efficiency
  • Automobile fuel efficiency rose after the oil
    shocks of the 1970s, but has stagnated since then.

Figure 17.13
26
OIL SANDS
  • Clay, sand, water and bitumen
  • Black oil rich in sulphur
  • Oil sands must be heated and treated
  • with steam to separate bitumen
  • Energy intensive
  • Sulphur dioxide emissions
  • Huge waste disposal ponds
  • Habitat fragmentation
  • Greenhouse gas emissions

27
Tar sand
Bitumen
Photos Syncrude
28
COAL
New technology may present cleaner coal burning
options (eg. improved boiler efficiency)
  • Most CO2 and
  • air pollution per
  • unit energy
  • Sydney tar ponds
  • - the most
  • contaminated site
  • in Canada

Illustration Brooks Johnson, Ontario Clean Air
Alliance
29
  • Several types of coal exist, depending on the
    amount of heat and pressure that overlying
    sediments have exerted.

Figure 17.16
30
  • Coal is mined either underground, in subsurface
    mining, or from the surface, in strip mining.

Figure 17.17
31
Natural Gas
  • Gaseous hydrocarbon mixture
  • Primarily methane CH4
  • Also C3H8 and C4H10
  • Now 45 of Canadas energy production
  • Much cleaner and more efficient
  • Problems potent greenhouse gas,
  • wildlife disruption, flaring H2S

32
Natural Gas History
  • Seeps known for 2,000 years
  • Used for street lighting in the 1800s
  • Became commonly used after WWII once pipeline
    technology became safer

33
Natural Gas Formation
  • Forms in two ways
  • Biogenic gas formed at shallow depths by
    anaerobic decomposition of organic matter by
    bacteria
  • Thermogenic gas formed at deep depths as
    geothermal heating separates hydrocarbons from
    organic material
  • (Formed directly OR from crude oil altered by
    heating. Thus gas deposits often occur with oil
    deposits.)

34
Gas Extraction
  • Initially, gas comes out on its own from natural
    pressure.
  • Later, it must be pumped out.

Horsehead pump to extract natural gas
Figure 17.18
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
NUCLEAR ENERGY
39
15 of Canadas electricity gt50 of Ontarios
electricity
40
Nuclear Power
  • 6.8 of worlds primary energy supply
  • 16.9 of worlds electricity production
  • Grew 15-fold since 1970
  • Has stagnated due to safety concerns and economics

41
Nuclear energy
  • Two ways to produce nuclear energy
  • Fission used for power
  • Fusion not yet used commercially

42
Nuclear Energy
  • Comes from the radioactive element uranium
  • The nuclear fuel cycle enriches forms of uranium
    to make it into usable fuel.
  • Waste fuel is radioactive and must be specially
    disposed of.

Figure 17.24
43
Nuclear Energy Fission
  • Fission energy is released by splitting apart
    uranium nuclei by bombarding them with neutrons.
  • This is the process used in nuclear reactors and
    weapons.

Figure 17.25a
44
Nuclear Energy Fission
  • Note that several neutrons
  • are produced from each
  • reaction with one neutron.
  • This means the reaction
  • could be a runaway reaction, or explosion.
  • In a commercial reactor, the reaction must be
    controlled.
  • Metal rods are used to absorb the extra neutrons.
    Engineers move these control rods to regulate the
    reaction.

Figure 17.25a
45
Nuclear Reactor
  • In a reactor, fission boils steam to turn a
    turbine and generate electricity

Figure 17.26
46
Nuclear Troubles
  • Although nuclear power is clean, lacking the
    pollutants of fossil fuels, it has faltered, due
    to
  • Cost overruns
  • Public fears of catastrophic accidents
  • Three Mile Island, 1979
  • Chernobyl, 1986
  • 450 nuclear plants remain operating today in the
    world 100 have closed.

47
  • No greenhouse gas emissions/air
  • pollution (except mining)
  • Minimal land disturbance
  • High energy output with minimal
  • environmental impact
  • Problems
  • Storage of nuclear waste
  • (DGD in Canadian shield proposed)
  • Expensive
  • Public trust / meltdown risk
  • (older systems)

48
Renewable Energy Sources
  • Biomass Biogas from combustion of organic
    material
  • Hydropower from water flowing through dams
  • Solar from the suns rays
  • Wind from the wind
  • Geothermal from heat and heated water beneath
    the ground
  • Ocean sources from the tides and from waves
  • Hydrogen fuel and fuel cells that store
    renewable energy in usable form

49
GLOBAL ENERGY SUPPLY
50
SOURCES OF ELECTRICITY
51
(No Transcript)
52
Renewable Sources Outlook
  • The outlook for renewable sources is good.
  • Growth should continue.
  • But will governments raise subsidies to the
    level offered to fossil fuels?
  • Will research and development proceed fast
    enough?
  • Will consumers choose alternative energy sources

53
HYDROELECTRIC POWER
54
Turbine generator inside dam
55
(No Transcript)
56
  • Hydro Power
  • 12 of Canadas energy
  • No air pollution
  • Downstream irrigation regulation

57
(No Transcript)
58
Pros and cons of hydroelectric power
  • PROS
  • Renewable as long as water is not overdrawn from
    river system
  • Clean no greenhouse gas emissions
  • CONS
  • Dams cause numerous disruptive ecological effects
    to riparian environments
  • Dams bring a mix of impacts for people

59
WIND ENERGY
60
Wind Power
  • Takes kinetic energy of wind and converts it to
    electrical energy
  • Fastest growing power source today
  • Technology wind turbines, machines with turning
    blades that convert energy of motion into
    electrical energy by spinning a generator
  • Windmills have been used for centuries.
  • First wind turbine for electricity late 1800s

61
Mean 50m Wind Speed in Canada (m/s)
Source Canadian Wind Energy Atlas
62
(No Transcript)
63
Wind power
Annual average wind power
Figure 18.12a
64
Wind Power Wind Turbines
  • Wind spins the blades, which turn the gearbox,
    which turns the generator to produce electricity.

Figure 18.9
65
Wind Power Wind Turbines
  • Turbines are often located in groups (wind
    farms) at sites with exceptionally good wind
    conditions.

66
Wind Power
  • Most wind power so far is concentrated in a few
    nations.

Figure 18.11
67
Wind Power
  • By surveying with anemometers that measure wind
    speed, people can determine sites that will be
    best for wind power production.

From The Science behind the Stories
68
  • Near zero environmental impact
  • Potential exists to reverse current
  • level of impact from other sources
  • Each turbine powers at least 250
  • Alberta homes!
  • Its windy here!

69
Pros and Cons of Wind Power
  • PROS
  • Renewable, as long as wind blows
  • No emissions after equipment made, installed
  • Can allow local decentralized control over power,
    and local profit from electricity sales
  • Costs low after initial investment costs
    dropping
  • CONS
  • Not everywhere is windy enough
  • Windy sites can be far from population centers
  • Blades kill birds, bats
  • High start-up costs

70
Biomass
  • Organic substances produced by recent
    photosynthesis
  • (unlike fossil fuels, products of ancient
    photosynthesis)
  • More than 1 billion people
  • burn fuelwood as their
  • principal power
  • source for cooking,
  • heating, etc.

71
  • Biomass
  • Wood, agricultural wastes, garbage
  • 15 of worlds energy
  • 6 of Canadas energy
  • Mainly in developing nations
  • Less emission of greenhouse gases if
  • forest replacement exceeds removal (wood)
  • Biofuels for cars (ethanol - Brazil)
  • Problems land clearing and associated
  • problems (wood)

72
Pros and Cons of Biomass
  • PROS
  • Renewable, as long as forests arent depleted
  • Usually inexpensive
  • Some waste can be used for energy
  • Capturing methane reduces that greenhouse gas
  • CONS
  • Does not always reduce CO2 emission as much as
    other renewables
  • Cutting trees for fuelwood can lead to
    deforestation
  • Growing crops for fuel (e.g., corn for ethanol)
    is highly inefficient

73
  • Biogas Production from Manure
  • Electricity Generation
  • Gas for cooking
  • Heat
  • Utilized in Southern Alberta
  • (eg. Iron Creek Hutterite Colony)

Photos Rokai Pig Farm, Kaunas,
Lithuania http//www.folkecenter.dk/en/rokai/rokai
.html
INLET
OUTLET
74
  • Difficulties
  • Temperature optima maintenance
  • Acidity pH sensitive anaerobic bacteria
  • (lime required)
  • NH3 toxicity (control input rate)
  • CH4 wont liquefy difficult to store
  • (must use or burn)

75
Geothermal Energy
76
Geothermal Energy
  • Radioactive decay of elements deep in Earths
    core creates heat that rises toward the surface.
  • This heats magma of volcanoes, and also
    underground water.
  • Sometimes water spurts through to the surface in
    geysers.
  • Geothermal power plants use the energy of
    naturally heated water to generate electricity.

77
Geothermal Energy
  • Underground heat warms water, and steam turns
    turbines and generators.
  • Condensed steam is reinjected into the aquifer to
    keep up pressure.

Figure 18.13a
78
Geothermal Energy
  • Iceland uses geothermal energy to heat water for
    86 of its homes.
  • Heat pumps using surface heat can also be very
    efficient.

Geothermal plant in Iceland
Figure 18.13b
79
Pros and Cons of Geothermal Power
  • PROS
  • Renewable, as long as water is heated naturally
  • Much lower greenhouse gas emissions than fossil
    fuels
  • Can be inexpensive in areas where geothermal
    heating naturally occurs
  • CONS
  • Heated water may give out after a whilehotspot
    moves or aquifer pressure drops
  • Salts in water can corrode equipment, shorten
    lifespan
  • Limited to geographic areas where geothermal
    heating naturally occurs

80
Ocean Energy Sources
  • Three sources from oceans
  • Tidal power The twice-daily flow of tides
    (rising and falling of seas due to the moons
    gravitational pull) creates energy of motion that
    can be converted to electricity.
  • Wave power Motion of waves at ocean shores
    creates energy of motion that can be converted to
    electricity.

81
Tidal Energy
  • The LaRance power station in France is the
    worlds largest tidal generating station. Its
    turbines spin with both incoming and outgoing
    tides.

Figure 18.14b
82
Tidal Power
83
Wave Energy
  • There are several designs for wave energy
    stations.
  • In this one, air is compressed in a chamber with
    each incoming wave, driving a turbine to spin a
    generator.

Figure 18.15
84
Pros and Cons of Ocean Power
  • PROS
  • Renewable, as long as oceans behave as they
    always have
  • No greenhouse gas emissions
  • CONS
  • Development could take up large portions of
    coastline valuable for other uses
  • Could interfere with ecology of estuaries and
    intertidal shorelines

85
SOLAR ENERGY
Source DOE, USA
86
Solar Energy
  • Use of energy
  • from the Sun
  • Huge potential Each day Earth receives enough
    sunlight to power human consumption for 27 years,
    if we could somehow capture it all.

87
Solar energy
  • Passive solar designs buildings to maximize
    capture of sunlight in winter, but keep buildings
    cool in summer through window placement,
    absorbent materials
  • Active solar uses technological devices to
    focus, move, or store solar energy
  • Solar panels dark heat-absorbing metal plates in
    glass-covered boxes, often mounted on roofs

88
Solar energy Active solar
  • Portable solar cookers focus suns rays onto a
    small areahere, boiling water in Nepal. These
    are becoming popular throughout the developing
    world.

Figure 18.6
89
  • Numerous mirrors focus sunlight on a receiver
    atop a power tower in the California desert.
    This facility was the first to generate much
    solar power commercially.

90
Solar Furnace, Ordellio, France
91
Application Steel Production Facility
Source www.technologystudent.com/energy1/solar4.h
tm
92
Solar Energy Active Solar
  • Gaviotas, Colombia, uses solar panels in homes
    and businesses for heating, cooling, and water
    purification
  • (This photo is from Bogotá)

Figure 18.5
93
Solar Energy PV Cells
  • Photovoltaic cells (PV cells) convert solar
    energy directly into electrical energy by making
    use of the photoelectric effect
  • Sunlight strikes one of a pair of
    negatively-charged metal plates
  • Electrons migrate to opposing plates, and
    electric current is produced.
  • In PV cells, light strikes negatively charged
    phosphorus-
  • enriched silicon, and electrons migrate downward
    through silicon to positively charged
    boron-enriched silicon.

94
Solar Energy PV Cells
  • Electrons move from the phosphorus side of the
    silicon plate to the boron side, creating
    electric current. PV cells are arranged in
    modules, panels, and arrays.

Figure 18.8
95
Solar Power
  • Is little used, but fast growing
  • Currently only 0.04 of primary energy supply
    in the U.S.
  • Growing at 33 per year Cheaper technologies
    are taking off in developing countries.
  • More expensive technologies are growing more
    slowly in developed countries.

96
Pros and Cons of Solar Power
  • PROS
  • Renewable, as long as sun keeps on shining
  • Suns energy abundant, if technology can capture
    it
  • Allows for local decentralized control over power
  • No greenhouse gas emissions (although some are
    created in manufacture of technology)
  • CONS
  • Not everywhere is sunny enough
  • Up-front investment cost is high takes years to
    pay for itself

97
HYDROGEN POWER
Photo WIRED
98
Hydrogen
  • Hydrogen simplest and most abundant element in
    universe
  • Could potentially serve as basis for clean, safe,
    efficient energy system
  • How it would work
  • Electricity generated from intermittent renewable
    sources like wind or solar can be used to produce
    hydrogen.
  • Fuel cells can then use hydrogen to produce
    electrical energy for power.

99
Production of Hydrogen Fuel
  • Hydrogen gas (H2) does not exist freely on Earth.
  • We need to make it.
  • Electrolysis is the cleanest way
  • Split water into hydrogen and oxygen
  • 2 H2O ? 2 H2 O2
  • This can potentially be very clean, releasing no
    greenhouse gas emissions.

100
Production of Hydrogen Fuel
  • However, cleanliness of hydrogen production
    depends on source of electricity for
    electrolysis!
  • If the source of electricity needed for
    electrolysis is not clean (e.g., from coal), then
    greenhouse emissions will still occur.
  • Besides electrolysis, hydrogen can also be
    produced from organic molecules like fossil
    fuels. This entails greenhouse emissions.
  • H 75 of the universes mass !
  • Combustion engines can be fuelled by hydrogen
    (Ballard Power Canadian company and leader in
    this field)

101
Fuel Cells
  • In a fuel cell, hydrogen gas is used to produce
    electricity.
  • The reaction is simply the opposite of
    electrolysis
  • 2 H2 O2 ? 2 H2O
  • How it works
  • Hydrogen molecules are stripped of electrons.
  • H ions move through a membrane.
  • Electrons complete a circuit, creating
    electricity.

102
Fuel cells
Figure 18.16
103
(No Transcript)
104
O2 4H 4e- gt 2H2O
2H2 gt 4H 4e
NET REACTION 2H2 O2 gt 2H2O
You can drink the exhaust !
105
Pros and Cons of Hydrogen Power
  • PROS
  • We will never run out of hydrogen
  • Can be clean and non toxic, with no greenhouse
    gas emissions
  • Fuel cells potentially convenient, safe, and
    efficient
  • CONS
  • Depending on way hydrogen is produced, it may not
    be environmentally clean
Write a Comment
User Comments (0)
About PowerShow.com
