Title: FeedTreeSharing Web micronews with peertopeer event notification


1
FeedTree--Sharing Web micronews with peer-to-peer
event notification
  • Dan Sandler, Alan Mislove
  • Rice University

2
Brief View
3
OUTLINE
  • Terminology
  • Pastry
  • Scribe
  • FeedTree
  • Comments

4
Terminology
  • Micronews
  • Event Notification
  • Feed
  • RSS

5
RSS
WebServer
Client
user
Client
user
HTTP
HTTP
Client
user
HTTP
RSSresource
6
Pastry
O
2128-1
  • Rowstron-Druschel 2001
  • DHT Functionality
  • 128 bit circular id space
  • nodeIds (uniform random)
  • objIds (uniform random)
  • Invariant node with numerically closest nodeId
    is objects root


objId
nodeIds
7
PastryRouting
2128-1
O
  • Msg with key X is routed to live node with nodeId
    closest to X
  • Problem complete routing table not feasible

X
route(X,M)
8
PastryRouting
  • Properties
  • log16 N steps
  • O(log N) state
  • Prefix matching algorithm

d471f1
d467c4
d462ba
d46a1c
d4213f
Route(d46a1c)
d13da3
65a1fc
9
Description Pastry a peer-to-peer location
and routing substrate
0XXX
1XXX
2XXX
3XXX
1122
3321
START 1122 routes a message to 3000.
3032
First hop fixes first digit (3)
3001
Second hop fixes second digit (30)
END 3001 closest live node to 3000.
  • Routes messages to the nodeId numerically closest
    to the destination in lt ?log2b (N)? steps
  • Not only focuses on minimizing number of overlay
    hops but also the delay experienced
  • Route chosen for a message is likely to be good
    with respect to the proximity metric

10
ScribeCooperative group communication
  • Scribe Tree-based group management
  • Multicast, anycast, manycast primitives
  • Scalable large numbers of groups, members, wide
    range of members/group

11
Description Scribe is a Publish/Subscribe Event
Notification Application
Publisher
Publisher
Topic of interest
Subscriber
Subscriber
  • Decentralized Peer-to-Peer Model
  • A multicast tree is formed by joining the Pastry
    routes from each group member to a rendezvous
    point associated with a group.

12
ScribeArchitecture
Scalable communication service
Subscription management Event notification
SCRIBE
P2P location and routing layer
PASTRY
DHT
13
Tree-based protocols SCRIBE Tree Management
  • Create route to groupId
  • Join route to groupId
  • Tree union of Pastry routes from members to the
    root.
  • Multicast from the root down to the leaves
  • Low link stress
  • Low delay

Root
join( groupId)
groupId
Multicast (groupId)
join( groupId)
14
Scribe Tree-based protocols SCRIBE Tree
Management
d467c4 root
26b20d
d471f1
d467c4 root
Proximity space
d13da3
65a1fc
65a1fc
Name space
d13da3
26b20d
15
Design Joining a group (subscribing)and
multicasting a message (publishing)
Forwarder (may or may not be part of the group)
A1100
B1000
Event
C1011
1100
D1101
E1001
H1111
1101
1011
1001
F0100
G0111
0100
0111
16
FeedTree --a Plan to Save RSS
17
Design FeedTree sits on top of scribe/pastry
layer
18
FeedTree Architecture
  • A complete RSS document is created
  • containing pieces of timely micronews
  • Signed with the publishers private key
  • Multicast in the overlay
  • The user can be notified immediately

19
Full FeedTree Support
  • Web content management systems join the overlay
    by becoming long-lived FeedTree nodes
  • It automatically creates a new FeedTree message
    and publishes it to multicast tree.

20
Incremental FeedTree support
  • Adapted to FeedTree with a republishing engine
  • It sifting out new content and distributing it
    via FeedTree

21
Development Status
  • A software prototype
  • Deployment internally at Rice
  • Plan to expand to the PlanetLab

22
Comments 1
  • In this 6-page-long paper, only half page is
    actually about the FeedTree
  • No experiments, no data, no evaluation!

23
Lesson learned
A hot concept
A popular infrastructure
This paper


RSS Pastry Scribe Published!
24
QA
25
THANKS
