Simultaneous Placement and Scheduling of Sensors

1
Simultaneous Placement andScheduling of Sensors

• Andreas Krause, Ram Rajagopal,Anupam Gupta,
  Carlos Guestrin

rsrg_at_caltech
..where theory and practice collide
TexPoint fonts used in EMF. Read the TexPoint
manual before you delete this box. AAAAAAAAAAA
2
Traffic monitoring

• CalTrans wants to deploy wireless sensors under
  highways and arterial roads
• Deploying sensors is expensive(need to close and
  open up roads etc.)
• ? Where should we place the sensors?
• Battery lifetime ¼ 3 years
• Need 10 years lifetime for feasible deployment ?
• Solution Sensor scheduling (e.g., activate every
  4 days)
• ? When should we activate each sensor?

3
Monitoring water networks

• Contamination of drinking watercould affect
  millions of people

Contamination
Sensors
Simulator from EPA

• Place sensors to detect contaminations
• Battle of the Water Sensor Networks competition
• ? Where and when should we sense to
  detect contamination?

4
Traditional approach
1.) Sensor PlacementFind most informative
locations
2.) Sensor SchedulingFind most informative
activation times (e.g., assign to groups round
robin)

• If we know that we need to schedule, why not
  take that into account during placement?

5
Our approach
1.) Sensor PlacementFind most informative
locations
Simultaneously optimize overplacement and
schedule
2.) Sensor SchedulingFind most informative
activation times (e.g., assign to groups round
robin)

• If we know that we need to schedule, why not
  take that into account during placement?

6
Model-based sensing

• Utility of sensing based on model of the world
• For traffic monitoring Learn probabilistic
  models from data (later)
• For water networks Water flow simulator from EPA
• For each subset A µ V compute sensing quality
  F(A)

Model predicts High impact
Low impactlocation
Contamination
Medium impactlocation
S3
S1
S2
S3
S4
S2
Sensor reducesimpact throughearly detection!
S1
S4
Set V of all network junctions
S1
Low sensing quality F(A)0.01
High sensing quality F(A) 0.9
7
Problem formulation

• Sensor Placement
• Given finite set V of locations, sensing quality
  F
• Want Aµ V such that
• Sensor Scheduling
• Given sensor placement A µ V
• Want Partition A A1 A2 Ak s.t.

Ak sensors activated at time k
Want to maximize average performance over time!
8
The SPASS Problem

• Simultaneous placement and scheduling (SPASS)
• Given finite set V of locations, sensing quality
  F
• Want Disjoint sets A1, , Ak such that A1
  Ak m and
• Typically NP-hard!

At sensors activated at time t
9
Greedy average-case placement and scheduling
(GAPS)
Greedily choose s sensor location t time step
to add s to
Start with A1,,Ak For i 1 to m (s,t)
argmax(s,t) F(At s) F(At) At At s
s8
3
2
1
s1
4
1
s10
4
s13
s5
s12
s6
2
s2
1
s11
s9
s7
2
3
1
How well can this simple heuristic do?
10
Key property Diminishing returns
Placement A S1, S2
Placement B S1, S2, S3, S4
S2
S2
S3
S1
S1
S4
Theorem Krause et al., J Wat Res Mgt
08 Sensing quality F(A) in water networks is
submodular!
Adding S will help a lot!
Adding S doesnt help much
S
New sensor S

S
B
Large improvement
A
Submodularity

S
Small improvement
For A µ B, F(A S) F(A) F(B S) F(B)
11
Performance guarantee

• Theorem
• GAPS provides constant factor approximation
• ?t F(AGAPS,t) 1/2 ?t F(At)
• Proof Sketch
• SPASS requires maximization of a monotonic
  submodular function over a truncated partition
  matroid
• Theorem then follows from result by Fisher et al
  78
• ? Generalizes analysis of k-cover problem (Abrams
  et al., IPSN 04)
• ? Can also get slightly better guarantee (¼ 0.63)
  using more involved algorithm by Vondrak et al.
  08

12
Average-case scheduling can be unfair

• Consider V s1,,sn, k 4, m 10
• ? Want to ensure balanced coverage

?t F(At) high!
mint F(At) low ?
s1
s6
Score F(Ai)
s13
s10
s5
s8
s12
s11
s2
s7
s2
A2
A3
A4
A1
13
Balanced SPASS

• Want A1, , Ak disjoint sets s.t. A1
  Ak m and
• Greedy algorithm performs arbitrarily badly ?
• We now develop an approximation algorithm for
  this balanced SPASS problem!

14
Key idea Reduce worst-case to average-case

• Suppose we learn the value attained by optimal
  solution
• c mint F(At) OPT
• Then we need to find a feasible solution A1,,Ak
  such that
• F(At) c for all t
• If we can check feasibility for any c, we can
  find optimal c using binary search!
• How can we find such a feasible solution?

15
Trick Truncation

• Need to find a feasible solution such that
• F(At) c for all t
• For Fc(A) minF(A), c
• F(At) c for all t ? ?t Fc(At) k c
• Truncation preserves submodularity! ?
• Hence, to check whether OPT mint F(At) c,
  we need to solve average-case problem

F(A)
Fc(A)
A
16
Challenge Use of approximation

• Only have an ½-approximation algorithm (GAPS) for
  average case problem

nocoverage!
? Can lead to unbalanced solution! mint F(At) 0
17
Remedy Can rebalance solution

• Can attempt to rebalance the solution, to obtain
  uniformly high score for all buckets

c
Score Fc(Ai)
s6
s12
s5
s11
s2
A2
A3
A4
A1
18
Is rebalancing always possible?

• If there are elements s where F(s) is large,
  rebalancing may not be possible

Rebalanced solutionstill has mint F(At)
0
c
s7
s3
Score Fc(Ai)
s2
A2
A3
A4
A1
19
Distinguishing big and small elements

• Element s2 V is big if F(s) ? c for some fixed
  0lt?lt1
• If we can ensure that F(At) ? c for all tthen
  we get ? approximation guarantee!
• Can remove big elements from problem instance!

Will find out howto choose ? later!
c
big elements
Score Fc(s)
? c
s1
s2
s3
s4
sn

20
How large should ? be?

GAPS solutionon small elements
c
s9
s8
s7
Score Fc(Ai)
rebalanced solution
s6
s5
? c
s10
s11
s2
s12
s4
A1
A2
A3

Ak
satisfied time steps
Lemma If ? 1/6, can always successfully
rebalance (i.e., ensure all time steps are
satisfied)
21
eSPASS Algorithm

• eSPASS
• Efficient Simultaneous Placement and Scheduling
  of Sensors
• Initialize cmin0, cmax F(V)
• Do binary search c (cmincmax)/2
• Allocate big elements to separate time steps (and
  remove)
• Run GAPS with Fc to find A1,,Ak, where k k -
  big elements
• Reallocate small elements to obtain balanced
  solution
• If mint F(At) c/6 increase cmin
• If mint F(At) lt c/6 decrease cmax
• until convergence

22
Performance guarantee

• Theorem
• eSPASS provides constant factor 6 approximation
• mint F(AeSPASS,t) 1/6 mint F(At)

Can also obtain data-dependent bounds which are
often much tighter
23
Experimental studies

• Questions we ask
• How much does simultaneous optimization help?
• Is optimizing the balanced performance a good
  idea?
• How does eSPASS compare to existing algorithms
  (for the special case of sensor scheduling)?
• Case studies
• Contamination detection in water networks
• Traffic monitoring
• Community sensing
• Selecting informative blogs on the web

24
Traffic monitoring

• Goal Predict normalized road speeds on
  unobserved road segments from sensor data
• Approach
• Learn probabilistic model (Gaussian process) from
  data
• Use eSPASS to optimize sensing quality
• F(A) Expected reduction in MSE when sensing
  at locations A
• Data
• from 357 sensors deployed on highway I-880 South
  (PeMS)
• Sampled between 6am and 11am during work days

25
Benefit of simultaneous optimization
OP Optimized Placement OS Optimized
Schedule RP Random Placement RS Random Schedule
Higher is better
Traffic data
Lifetime improvement (k groups)

• ¼ 30 lifetime improvement for same accuracy!
• For large k, random scheduling hurts more than
  random placement

26
Average-case vs. Balanced Score
Higher is better
Traffic data

• Optimizing for balanced score leads to good
  average-case performance, but not vice versa

27
Data-dependent bounds
Higher is better
Traffic data

• Our data-dependent bounds show that eSPASS
  solutions are typically much closer to optimal
  than 1/6

28
Water network monitoring

• Real metropolitan area network (12,527 nodes)
• Water flow simulator provided by EPA
• 3.6 million contamination events
• Multiple objectives Detection time, affected
  population,
• Place sensors that detect well on average

29
Benefit of simultaneous optimization
OP Optimized Placement OS Optimized
Schedule RP Random Placement RS Random Schedule
Higher balanced score
Water networks
More sensors

• Simultaneous optimization significantly
  outperforms traditional approaches

E.g., 3x reduction in affected population when m
24, k 3
30
Comparison with existing techniques

• Comparison of eSPASS with existing algorithms for
  scheduling (m V)
• MIP Mixed integer program for domatic
  partitioning with accuracy requirements
  (Koushanfary et al. 06)
• SDP Approximation algorithm for domatic
  partitioning (Deshpande et al. 08)
• Results on temperature monitoring (Intel
  Berkeley) data set with 46 sensors
• Goal Minimize expected MSE

31
Comparison with existing techniques
Lower error (MSE)
Worst-case error

• eSPASS outperforms existing approaches for sensor
  scheduling

Temperature data
32
Trading off power and accuracy

• Suppose that we sometimes activate all
  sensors(e.g., determine boundary of traffic jam,
  localize source of contamination)
• Want to simultaneously optimize mint F(At)
  and F(A1 Ak)
• Scalarization for some 0 lt l lt 1, we want to
  optimize l mint F(At) (1-l) F(A1 Ak)
• Theorem Our algorithm, mcSPASS (multicriterion
  SPASS) guarantees factor 8 approximation!

Balanced performance
High-density performance
33
Tradeoff results
max l mint F(At) (1-l) F(A1 Ak)
Stage-wise (? 0)
eSPASS (? 1)
mcSPASS (? .25)
34
Tradeoff results
1
l mint F(At) (1-l) F(A1 Ak)
0.99
0.98
High-density performance
0.97
0.96
0.95
0.94
0.82
0.84
0.86
0.88
0.9
0.92
Water networks
Scheduled performance

• Can simultaneously obtain high performancein
  scheduled and high-density mode

35
Conclusions

• Introduced simultaneous placement and scheduling
  (SPASS) problem
• Developed efficient algorithms with strong
  guarantees
• GAPS 1/2 approximation for average
  performance
• eSPASS 1/6 approximation for balanced
  performance
• mcSPASS 1/8 approximation for trading off
  high-density and balanced performance
• Data-dependent bounds show solutions close to
  optimal
• Presented results on several real-world sensing
  tasks
