Current and Resistance

1
Chapter 17

• Current and Resistance

2
17.1 Electric Current

• Whenever electric charges move, an electric
  current is said to exist
• The current is the rate at which the charge flows
  through a certain cross-section
• For the current definition, we look at the
  charges flowing perpendicularly to a surface of
  area A

3
Definition of the current

• Charge in motion through an area A. The time
  rate of the charge flow through A defines the
  current (charges per time)
• IDQ/Dt
• Units C/sAs/sA
• SI unit of the current Ampere

-
4
Electric Current, cont

• The direction of current flow is the direction
  positive charge would flow
• This is known as conventional (technical) current
  flow, i.e., from plus () to minus (-)
• However, in a common conductor, such as copper,
  the current is due to the motion of the
  negatively charged electrons
• It is common to refer to a moving charge as a
  mobile charge carrier
• A charge carrier can be positive or negative

5
17.2 Current and Drift Speed

• Charged particles move through a conductor of
  cross-sectional area A
• n is the number of charge carriers per unit
  volume V (concentration)
• nADxnV is the total number of charge carriers in
  V

6
Current and Drift Speed, cont

• The total charge is the number of carriers times
  the charge per carrier, q (elementary charge)
• ?Q (nA?x)q unit (1/m3)(m2 m)AsC
• The drift speed, vd, is the speed at which the
  carriers move
• vd ?x/?t
• Rewritten ?Q (nAvd?t)q
• Finally, current, I ?Q/?t nqvdA

?x
7
Current and Drift Speed, final

• If the conductor is isolated, the electrons
  undergo (thermal) random motion
• When an electric field is set up in the
  conductor, it creates an electric force on the
  electrons and hence a current

8
Charge Carrier Motion in a Conductor

• The electric field force F imposes a drift on
  an electrons random motion (106 m/s) in a
  conducting material. Without field the electron
  moves from P1 to P2. With an applied field the
  electron ends up at P2 i.e., a distance vdDt
  from P2, where vd is the drift velocity
  (typically 10-4 m/s).

9
Does the direction of the current depend on the
sign of the charge? No!
qvd
E
vd

• (a) Positive charges moving in the same
  direction of the field produce the same positive
  current as (b) negative charges moving in the
  direction opposite to the field.

E
vd
(-q)(-vd) qvd
10
Current density

• The current per unit cross-section is called
  the current density J
• JI/A nqvdA/Anqvd
• In general, a conductor may contain several
  different kinds of charged particles,
  concentrations, and drift velocities. Therefore,
  we can define a vector current density
• Jn1q1vd1n2q2vd2
• Since, the product qvd is for positive and
  negative charges in the direction of E, the
  vector current density J always points in the
  direction of the field E.

11
Example

• An 18-gauge copper wire (diameter 1.02 mm)
  carries a constant current of 1.67 A to a 200 W
  lamp. The density of free electrons is 8.5?1028
  per cubic meter. Find the magnitudes of (a) the
  current density and (b) the drift velocity.
•

12
Solution

• (a) Ad2p/4(0.00102 m)2p/48.2?10-7 m2
• JI/A1.67 A/(8.2?10-7 m2)2.0?106 A/m2
• (b) From JI/Anqvd, it follows

vd1.5?10-4 m/s0.15 mm/s
13
17.3 Electrons in a Circuit

• The drift speed is much smaller than the average
  speed between collisions
• When a circuit is completed, the electric field
  travels with a speed close to the speed of light
• Although the drift speed is on the order of 10-4
  m/s the effect of the electric field is felt on
  the order of 108 m/s

14
Meters in a Circuit Ammeter

• An ammeter is used to measure current
• In line with the bulb, all the charge passing
  through the bulb also must pass through the meter
  (in series!)

15
Meters in a Circuit - Voltmeter

• A voltmeter is used to measure voltage (potential
  difference)
• Connects to the two ends of the bulb (parallel)

16
Look at the four circuits shown below and
select those that will light the bulb.
QUICK QUIZ 17.2
17
17.4 Resistance and Ohms law

• In a homogeneous conductor, the current density
  is uniform over any cross section, and the
  electric field is constant along the length.

b
a
VVa-VbEL
18
Resistance

• The ratio of the potential drop to the current
  is called resistance of the segment
• Unit V/AW (ohm)

19
Resistance, cont

• Units of resistance are ohms (O)
• 1 O 1 V / A
• Resistance in a circuit arises due to collisions
  between the electrons carrying the current with
  the fixed atoms inside the conductor

20
Ohms Law

• V ? I ? Vconst.?I ? VRI
• Ohms Law is an empirical relationship that is
  valid only for certain materials
• Materials that obey Ohms Law are said to be
  ohmic
• IV/R
• R??, I?0, open circuit R?0, I??, short circuit

21
Ohms Law, final
Ohmic

• Plots of V versus I for (a) ohmic and (b)
  nonohmic materials. The resistance RV/I is
  independent of I for ohmic materials, as is
  indicated by the constant slope of the line in
  (a).

Nonohmic
