Dimensionality reduction

1
Dimensionality reduction

• Alexis Boukouvalas
• Work in collaboration with D. M. Maniyar and D.
  Cornford

2
Goals

• Develop methods for dimensionality reduction of
  either the input and/or output space of models.
• To gain an understanding initially use a toy
  dataset to compare existing methods.
• Later on utilize methods on real world models.
• Goal is to extend methods to work with high
  number of variables - 105

3
Methods

• Feature Selection
• Also known as Screening in statistical literature
• Select p most relevant of the original k
  variables.
• Meaning of variables is preserved gt method
  results are interpretable
• Projective methods
• Variables are transformed XF(X)
• Transformations can be linear or non-linear
• Interpretation is non-trivial especially for
  non-linear mappings.

4
Toy data set (1)

• Generate N base vectors x of dimensionality d
  from sampling a Latin hypercube. Normalize the
  data.
• Evaluate the generative model g(.)
• Corrupt the model output with independent
  identically distributed Gaussian noise. Initially
  we set noise variance is 0.1signal variance.
• Screening Augment with extra noise dimensions
• e Bx input noise
• Noise is always N(0,I). B matrix is described on
  the next slide.
• Projection Project to a higher dimensional
  space using x WF(x)

5
Toy data set (2)

• Screening B matrix determines correlation
  between noise and model variables
• B0 constructs noise variables that are
  uncorrelated to the model variables.
• k randomly selected rows have a single non zero
  entry corresponding to the noise variable being
  linearly correlated to a single model variable.
  Currently k0.5noise variables and coefficient
  is set to 0.5
• Same as previous but two elements of k rows are
  non-zero, k0.8 and coefficients are randomly
  taken from the set -0.2,-0.5,0.5,0.7

6
Toy data set (3)

• Projection Project into higher dimensional
  space q
• x WF(x)
• W is a qd weight matrix and F() are basis
  functions which are responsible for the
  projection mapping. A typical choice of such
  projection mapping is to use Radial Basis
  Functions (RBF).

7
Toy data set - extensions

• Different noise models
• Correlated
• Multiplicative
• Non-linear interactions of noise variables with
  model variables
• Mix screening and projection

8
Feature Selection

• Variable selection methods have been broadly
  categorised in three categories
• Variable Ranking. Input variables are ranked
  according to the prediction accuracy of each
  input calculated against the model output.
• Wrapper methods. The emulator is used to assess
  the predictive power of subsets of variables
• Embedded methods. For both variable ranking and
  wrapper methods, the emulator is considered a
  perfect black box. In embedded methods, the
  variable selection is done as part of the
  training of the emulator.

9
Wrapper Methods

• Forward selection where variables are
  progressively incorporated in larger and larger
  subsets
• Backward elimination proceeds in the opposite
  direction.
• Efroymsons algorithm aka stepwise selection.
  Proceed as forward selection but after each
  variable is added, check if any of the selected
  variables can be deleted without significantly
  affecting RSS.
• Exhaustive search where all possible subsets are
  considered.
• Branch and Bound. Eliminate subset choices as
  early as possible. E.g. is variables A-Z, RSS of
  A,B subset 100, then C-Z subset branch need not
  be followed if RSS of all C-Z variables gt 100.

10
Embedded methods

• An embedded method commonly employed in the
  context of Gaussian Processes is Automatic
  Relevance Determination (ARD) where the
  characteristic length scales l determine the
  input relevance

11
Preliminary experiments

• The following algorithms were used in the
  experiments
• BaseRelevant Baseline run using the relevant
  dimensions only. The RMSE was obtained by
  training a GP on the relevant dimensions. This
  value can be interpreted as the optimal RMSE
  value.
• BaseAll Baseline run using all the dimensions,
  i.e. relevant extra. Again the RMSE was
  obtained by training a GP on this set. The
  difference BaseAll-BaseRelevant is a measure of
  the effect of the extra variables on the
  predictive accuracy of the GP.
• CorrCoef Pearson Correlation Coefficient. A
  variable ranking is performed using the formulae
  10 and the top 3 variables are selected and used
  to train a GP.
• LinFS Employ a forward selection subset
  selection strategy using a multivariate linear
  regression model. The RMSE is obtained from
  evaluating the selected subset on a multiple
  linear regression model.
• GPFS Again employ forward selection to
  generate subsets but use a GP rather than a
  linear model.
• ARD Employ the ARD method to rank the input
  variables and select the top 3 to train a GP
  model.

12
Experiment 1No correlation

• 200 observations,3 model dimensions, 6 total

Algorithm Variables Selected RMSE Elapsed time
BaseRelevant 1,2,3 0.9128 1.44142
BaseAll 1,2,3,4,5,6 1.0473 1.60529
CorrCoef 1,4,2(,3,5,6) 2.1642 1.50487
LinFS 1,4,2 2.7803 0.134283
GPFS 1,2,3 0.9092 18.2017
ARD 1,2,3 0.9134 5.56684
5.56684
5.56684
13
Experiment2Two var correlation

• 200 observations,3 model dimensions, 6 total

Algorithm Variables Selected RMSE Elapsed time
BaseRelevant 1,2,3 0.9111 1.42363
BaseAll 1,2,3,4,5,6 1.0633 1.66093
CorrCoef 1,4,5(,2,6,3) 2.6794 1.31676
LinFS 1,4,6 2.8083 0.143308
GPFS 1,2,3 0.9274 19.0051
ARD 1,2,3 1.0076 5.0611
5.56684
5.56684
14
Experiment 3 ARD

• Initial results for high-D input, two-correlated,
  model inputs 100, noise dimensions 500, number of
  observations 500.

Length - Input Number 31.8373 361 18.7081
501 14.2097 296 12.7581 51 12.3160
456 11.8689 496 11.3176 166 10.2424
310 10.2220 420 9.6192 325 9.0732
363
Length - Input Number 8.6898 53
8.5453 347 7.9338 419 7.8201 294
7.8017 188 7.4327 103 7.3760 13
7.1526 572 7.0997 478 6.9481 393
6.6417 187
15
Summary of Experiments

• Best performing methods are GPFS and ARD which
  usually find the optimal subset. However the GPFS
  method is on average more than three times slower
  than ARD.
• The CorrCoef and LinFS methods are
  computationally inexpensive but provide
  unsatisfactory results.
• Even for simple mapping functions (sinx) on
  underdetermined systems where number of
  observations lt dimensions, ARD breaks down.

16
Research Directions

• Batch hierarchical screening
• Explore the potential of partitioning the input
  space into groups of inputs, applying screening
  methods on the groups and combining the important
  inputs
• Some work already done for linear models (Gabriel
  and Pan 1979)
• Grouping of variables such that if two variable
  Xi Xj are in different groups, then their
  regression sum of squares (RSS) are additive,
  i.e. if Si is the reduction in RSS from including
  Xi and Sj for Xj, then when including both Xi Xj
  Si.jSiSj

17
Research directions (2)

• Coupled Emulation
• separate emulators for different outputs, linked
  with some model for the covariance
• Connections to sequential methods to handle large
  datasets. Linked to Sequential Sparse GPs?
• Projective methods in conjunction with feature
  selection.

18
Projective methods
From Van der Maaten et al 2007
19
But

• But Van der Maaten et al 2007 compared the
  non-linear to linear methods and found them no
  better. Reasons they propose relate to curse of
  dimensionality, overfitting of local models and
  others.

20
References

• Dimensionality Reduction A Comparative Review,
  L.J.P. van der Maaten E.O. Postma H.J. van den
  Herik 2007
• Andr Elisseeff Isabelle Guyon. An Introduction to
  Variable and Feature Selection. Journal of
  Maching Learning Research, 311571182, 2003.
