Title: The Zebra Mussel


1
The ZebraMussel
  • What A
  • Homeowner
  • Needs to Know

1
2
June 1988 - Lake St. Clair
2
3
Zebra Mussel U.S. Range
December 1989
3
4
Zebra Mussel U.S. Range
December 1990
4
5
Zebra Mussel U.S. Range
December 1992
5
6
Zebra Mussel U.S. Range
December 1999
6
7
Potential Zebra Mussel U.S. Range
December 2020?
7
8
Recreational Boating...
The most likely inland spread vector
8
9
Water Treatment Plant Ozone Contact
Chamber (Monroe, MI, WTP)
9
10
Circulating Water Pump Bell Housing (Detroit
Edison, Monroe, MI)
10
11
But Huge pipes arent the only ones at
risk. Zebra mussels are already clogging
thousands of small intakes, as well.
11
12
Why Havent We Heard of This Problem Before Now?
  • Early colonization is spotty with low mussel
    densities
  • Densities of mussel veligers in water column are
    low
  • Power plants and drinking water facilities have
    huge water demands and draw in millions of
    veligers
  • Power plants and water treatment plants pump
    water for long periods of time, sucking in more
    veligers
  • Many residential systems may face imminent
    failure but havent been clogged yet
  • Many people affected by power plant or water
    treat-ment plant shutdowns clogged residential
    pipes impact fewer

12
13
Watch carefully Zebra Mussels come in ALL
sizes and coloration patterns
13
14
Water Intakes Excellent Zebra Mussel Habitat
  • Continuous source of food and oxygen
  • Continuous removal of wastes
  • Protection from predation
  • Protection from severe weather

14
15
Byssal Threads..
The zebra mussel's secret weapon
15
16
16
17
Zebra mussels can completely plug small water
intake pipes in very little time
17
18
Zebra Mussels in Residential Water Systems
18
19
Zebra Mussel Fouling ofResidential Water Systems
  • Intake pipe
  • Strainer
  • Foot valve
  • Pump
  • Pipe itself
  • Storage/pressure tank
  • Distribution pipes

19
20
Zebra Mussel Impacts onResidential Water Systems
  • Loss of pumping efficiency
  • Obstruction of foot valve
  • Clogging of intake pipe
  • Wear tear on pump
  • Clogging of distribution pipes
  • Taste odor problems
  • Increased corrosion

20
21
  • Are mussels growing around or within mouth of
    pipe?
  • Is there a noticeable decrease in water volume
    and pressure?
  • Are there unpleasant tastes and odors in the
    water?

21
22
Factors Influencing Rate of Zebra Mussel Fouling
of Residential Water Systems
  • Water chemistry of the waterbody
  • Extent of zebra mussel colonization near mouth of
    intake
  • Position of the mouth of intake in the water
  • Composition of the intake pipe
  • Volume and velocity of water flowing through the
    pipe

22
23
Reducing the Risk of Zebra Mussel Fouling
23
24
When to Implement Zebra Mussel Control in
Residential Water Systems
  • Continually (no mussels tolerated ever)
  • Periodically (some mussel growth is allowed,
    followed by removal of the mussels)

24
25
Residential Water Systems
25
26
Residential Water Systems
26
27
Residential Water Systems
  • Most difficult to protect
  • Often least costly to repair

27
28
Residential Water Systems
  • Easiest to protect
  • Most costly to repair

28
29
Protecting the Onshore Component of Residential
Water Systems
29
30
Onshore ComponentControl Alternatives
  • Replaceable or cleanable in-line filter
  • Chlorine injection at pump or pressure tank
  • Combination of filtration chlorination

30
31
In-Line Filtration
  • 40 micron maximum
  • Removes all life stages

31
32
Whole HouseIn-Line Filters
  • Single media filamentous angel hair (25 - 50 ?)
  • Ceramic filters (50 ?)
  • Spun cellulose or ceramic fiber cartridges (lt10
    ?)
  • Dual media filters
  • Fiber media around activated charcoal core (lt10
    ?)
  • Removes many flavors odors
  • Back-flushable filters or microstrainers (lt10 ?)

32
33
Whole HouseIn-Line Filters
  • Least expensive
  • Require periodic filter cartridge replacement
  • Increased backpressure can force live larvae
    through filter
  • Back-flushable filters clean filter media by
    reversing flow of water and flushing out filter
    media

33
34
Whole HouseIn-Line Filters
Cleaning / replacement timing depends upon
  • Amount of silt, algae, zebra mussel veligers, and
    other particles drawn into system
  • Intakes location in the waterbody
  • Time of year
  • Spring summer silt loads
  • Storm silt loads
  • Summer algal growth

34
35
Whole HouseIn-Line Filters
  • Do not allow material trapped within filter to
    bypass the filter during cleaning / replacement
  • Cleaning / replacement of clogged filters is an
    on-going cost time commitment
  • Automatic back-flushable filters can eliminate
    one of the maintenance tasks

35
36
In-Line Chlorination
  • Kills all life stages
  • Kills many other pathogens
  • Remove taste with carbon filter

36
37
Filter-Chlorinator Combo
  • Healthier water
  • Kills or removes all mussels

37
38
Hand-Driven Shore Well
Pumphouse
Driven pipe with well point
Infiltration from waterbody
38
39
"High Tech" Shore Well
39
40
Shore Well with Infiltration Channel
40
41
41
42
Drilled Wells
The ultimate onshore preventive measure
  • May not be viable alternative where
  • No available aquifer
  • Sulfurous water
  • Salty water
  • Polluted ground water

42
43
Offshore Strainers
Use of screens or strainers at intake end of pipe
  • Effectiveness depends upon
  • Mesh size of screen
  • Size of mussels being drawn into pipe
  • Common mesh on small intake (1/4 - 1/2 inch)
    keeps out leaves but not zebra mussel veligers
    (as small as 70 ? 3/1000 inch)
  • Simple screens are ineffective as a zebra mussel
    control method

43
44
Offshore Strainers
Effectiveness can be increased by reducing mesh
size
  • Too small openings can clog quickly with silt,
    algae, and debris
  • Screens can become fouled

44
45
Offshore Filtration
  • Constructed alternatives
  • Infiltration galleries
  • Raised fill beds
  • Manufactured alternatives
  • Prefabricated sand filters
  • Ceramic filters
  • Cartridge filters

45
46
46
47
Infiltration Gallery
47
48
Raised Fill Bed
48
49
Backflushing Offshore Filters
  • Infiltration galleries and raised fill beds will
    eventually clog with fine particles
  • Backflush by pumping water from shore through
    pipe system to flush out fine particles
  • Sand beds can become compacted over time
  • Cracks can form in sand
  • Zebra mussel veligers can be drawn into pipe
  • Backflushing fluffs sand up, prevents cracks

49
50
Prefabricated Sand Filter
50
51
Manufactured Offshore Filters
Homeowners should investigate the product
  • When, where, how long, under what conditions have
    filters been field tested?
  • Names of clients with filters in water for
    reasonable length of time
  • What happens if system clogs prematurely?
  • Is automatic backwashing available as option?

51
52
Offshore Filters andWater Potability
Offshore sand filtration can remove zebra mussels
and other large particles
  • By itself, offshore filtration is not intended to
    provide potable (drinkable) water
  • Additional treatment by chlorination or
    ultraviolet light needed to kill bacteria
  • Consult county Cooperative Extension Service or
    health department about drinking water standards

52
53
Environmental Impacts ofConstructed Offshore
Filters
  • Turbidity during excavation and backfilling
    impacts local water quality temporarily
  • Use trenching equipment rather than backhoes
  • Use silt screens around excavation site
  • Disturbance of natural lake or river bottom
    habitat
  • New habitat provided by stone cover material
  • Prefabricated sand filter minimizes habitat
    loss with smaller disturbance
    footprint
  • Permanent change in bottom habitat type from
    natural to human-influenced substrate

53
54
Offshore Ceramic andCartridge Filters
  • Abrasive ceramic filter media removes or destroys
    mussel veligers
  • Cartridge filters trap particles, including zebra
    mussel veligers
  • Porosity should be small enough so that no mussel
    life stages will pass live into intake pipe
  • Available with manual or automatic backwash
  • Should ask how often the filter media needs to be
    replaced or cleaned

54
55
Nonfouling Pipe Materials
Copper or galvanized intake pipes
  • Discourage zebra mussel attachment
  • Lose effectiveness as they corrode or oxidize
  • Should be augmented by other methods

55
56
Periodic Cleaning ofOffshore Component
  • Allows some clogging by mussels, followed by
    periodic maintenance
  • Cleaning
  • Mechanical
  • Thermal
  • Pipe replacement
  • Protect onshore component with its own system
  • Install Y connection cleanout at shore end of
    pipe to facilitate cleaning

56
57
Periodic Cleaning ofOffshore Component
Plumbers snake for short pipes with easy access
  • Loosened mussels must be removed by
  • Pumping through a strainer at the pump
  • Opening foot valve and backflushing
  • Not possible in pipes with
  • Tight bends
  • Check valves
  • Radical diameter changes

57
58
Oxygen Deprivation
  • Zebra mussels breathe oxygen as water passes
    over their gills
  • Seal both ends of pipe long enough for water to
    lose all of its oxygen
  • Oxygen demand greatest in warm water
  • Oxygen deprivation most effective in summer
  • 2 to 3 days anaerobic water at 74º F 100 kill
  • Most suited to weekend cottages that routinely
    have water system shutdowns
  • Year-round homes will need second intake

58
59
Removable Intake Pipes
Weekend cottage low water demand not for
drinking
  • Single short flexible plastic pipe directly on
    lakebed
  • Pull from water - leave on shore - dry in sun
  • Dead mussels snaked from pipe
  • Replace into water next weekend
  • Several times a season based on speed of fouling
  • Dual short flexible plastic pipes
  • Pull one-at-a-time from water, leave on shore,
    dry in sun, and clean
  • Pumping continues through second pipe
  • Onshore piping protected by onshore filtration

59
60
Thermal Treatment
Periodic flushing with hot water
  • 90º F for about 1 hour 100 kill
  • gt 130º F immediate kill
  • Foot valve must be open to allow flow of hot
    water
  • Cold lake water is heat sink - need enough hot
    water to fill pipe and keep hot long
    enough for kill
  • Hot water discharge negative environmental
    impact
  • Dead mussels must be removed by backflushing
  • Portable steam generator from shore end of pipe
  • Live steam instant kill
  • Less hot water discharge

60
61
Chemical Treatment
  • No environmentally sound chemical treatment
    system for offshore part of residential water
    intakes
  • Never pour or backwash chemicals down intakes
  • Environmentally harmful effects on fish,
    zooplankton, and bottom-dwelling invertebrates
  • Might be harmful to human health
  • Could be illegal if discharged into surface
    waters
  • Not effective in killing zebra mussels due to
    short contact time afforded in a residential
    intake pipe

61
62
Deeper Intakes
  • Deep water intake might minimize colonization
  • Water too cold
  • Insufficient food supply
  • Zebra mussels survive near-freezing Great Lakes
    winters with little damage below ice scour zone
  • Veligers found down to about 200 feet
  • Cost of very deep intakes prohibitively expensive
  • If waters below thermocline become oxygen
    depleted, sub-thermocline intakes could minimize
    colonization

62
63
Multi-Residence Systems
Most control alternatives can be scaled up to
meet needs of multiple residences
  • Cost per residence could be lower than for single
    residence systems
  • Multi-residence systems help eliminate
    proliferation of smaller, less efficient
    individual systems
  • Might be more environmentally sound

63
64
64
65
Written and Produced By Charles R. ONeill,
Jr. New York Sea Grant 2001
Write a Comment
User Comments (0)
About PowerShow.com
