Metamorphic Rocks

1
Metamorphic Rocks

• If something is gneiss, dont take it for
  granite.

2
(No Transcript)
3
Metamorphic Agents

• Pressure (gt1,000 times atmospheric pressure)
• Temperature (gt300 degrees C)
• Chemical Fluids (mineral saturated hot water)

4
Metamorphic Environments

• Contact (thermal) intrusion by magma
• Hydrothermal ion-rich hot water circulates
  through cracks
• Mountain Building regional metamorphism

5
Metamorphic Changes -Rocks adjust to new
conditions by

• Changes in texture
• Changes in mineralogy

6
Changes in Texture

• Compaction
• Recrystallization - may cause
• Foliation
• Lineation

7
Changes in Minerology

• Recrystallization small crystals reform into
  larger crystals of the same mineral
• Formation of new minerals elements recombine to
  form new minerals
• Garnet, Chlorite and others found only (or
  mostly) in metamorphic rock

8
Grades of Metamorphosis

• Low Grade Low temperature and pressure results
  in slate and phyllite
• Rock cleavage in slate
• Foliated
• Fine grained
• Slate looks dull, phyllite is shiny

9
Grades of Metamorphosis (cont.)

• Intermediate Grade higher temperatures and
  pressures than Low Grade
• Schist
• Foliated
• Mica, garnet

10
Grades of Metamorphosis (cont.)

• High temperatures and pressures
• Gneiss and Migmatite
• Dark light banding of mica (dark), quartz
  feldspar (light)

11
Foliated Metamorphic Rock Sequence

• Slate parent rock is shale (sedimentary)
• Phyllite parent rock is slate
• Schist parent rock is phyllite
• Gneiss parent rock is schist
• Migmatite parent rock is gneiss

12
Non-Foliated Metamorphic Rocks Their Parent
Rocks

• Marble Parent rock is limestone or dolostone
  (calcite, reacts with acid)
• Quartzite Parent rock is sandstone
• Anthacite Parent rock is bituminous coal
• Hornfels Parent rock is any rock type

13
Metamorphic Rock Dichotomous Key

• Proceed to Dichotomous Key Activity

14

• View in slide show, then click to view
• Dichotomous Metamorphic Key
