Automated Robot Checkers

1
Automated Robot Checkers
2
Agenda

• Project Overview
• Specifications and Objectives
• Preliminary Design
• Cost Estimate

3
Project Overview
4
Background

• Fun and interactive project
• Possible marketability
• Eye catcher

5
Purpose of Design

• To create an embedded system that interfaces to
  the PC through the USB port
• Solution
• Artificially intelligent robotic arm controlled
  by an embedded system
• PC GUI used for settings control and to provide
  visual representation of board
• Game interaction monitored through sensors

6
(No Transcript)
7
IO Diagram
8
Specifications
9
Specifications Robotic Arm

• Lynx 5 Satellite Arm
• Arm has 4 degrees of freedom and pinchers
• Controlled by 5 servos
• Input pulse width to servo determines degrees of
  rotation (1 - 2 ms)
• 0.72 of accuracy of motion
• 180 of motion range per axis
• Servos operate at 6 V DC

10
Specifications Control Unit

• OOPic board with built-in microcontroller OPic
• 20MHz internal clock
• Internal RAM and EEPROM
• Includes OOPic2 firmware
• Serial control protocol (SCP) allows interaction,
  control, and debugging during operation.

11
Specifications Control Unit (cont.)
12
Servo Explanation
13
Preliminary Design
14
Pseudo code For Microcontroller
15
GUI Prototype
16
Metal Contacts
17
Magnetic Sensor
18
Cost Estimate
19
(No Transcript)
20
Questions?
