SYNAPSES

1
SYNAPSES
D. C. Mikulecky Professor of Physiology http//v
iews.vcu.edu/mikuleck/
2
TWO TYPES OF SYNAPSE

• ELECTRICAL
• CHEMICAL

3
ELECTRICAL
GAP JUNCTION PROVIDES PATH FOR IONS TO FLOW
FROM ONE CELL TO ANOTHER
CELL 1
CELL 2
4
CHEMICAL THE SYNAPSE
INCOMING NERVE
POST SYNAPTIC NERVE
SPACE
5
EVENTS IN CELLULAR COMMUNICATION
INPUT SIGNAL (CHEMICAL,MECHANICAL, PHOTO,
ELECTRICAL)
RECEPTOR
TRANSDUCER
EFFECTOR ENZYMES,GENOME,CONTRACTILE FILAMENTS,
SECRETORY GRANULES
RESPONSE (OUTPUT)
SECRETION CONTRACTION/RELAXATION
DIVISION PHAGOCYTOSIS
6
HOW ARE WE WIRED?CONNECTIONS BETWEEN NERVE CELLS
AXON
CELL BODY
AXON TERMINALS
AXON HILLOCK
DENDRITES
7
THE NATURE OF CHEMICAL TRANSMISSION BETWEEN NERVES

• PRESYNAPTIC EVENTS
• POSTSYNAPTIC EVENTS
• IN THE SPACE

8
PRESYNAPTIC EVENTS

• THE ALL OR NONE ACTION POTENTIAL TRIGGERS THE
  RELEASE OF CHEMICAL TRANSMITTER

9
INCOMING ACTION POTENTIAL

• DEPOLARIZES
• TRIGGERS CALCIUM CHANNELS
• CALCIUM ENTERS THE CELL

10
THE SYNAPSE
INCOMING ACTION POTENTIAL
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES





ION CHANNEL



ENZYME
11
THE SYNAPSE INCOMING ACTION POTENTAL
INCOMING ACTION POTENTIAL
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES





ION CHANNEL



ENZYME
12
CALCIUM INFLUX

• CAUSES VESSICLES TO BE RELEASED
• VESSICLES MIGRATE TO MEMBRANE
• EXOCYTOSIS
• NEUROTRANSMITTER ENTERS SPACE

13
THE SYNAPSE CALCIUM CHANNELS OPEN
INCOMING ACTION POTENTIAL
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES





ION CHANNEL



ENZYME
14
THE SYNAPSE NEUROTRANSMITTER ENTERS SPACE
CALCIUM CHANNEL

RECEPTOR

SYNAPTIC VESSICLES





ION CHANNEL


ENZYME
15
POST SYNAPTIC EVENTS

• IONOTROPIC (LIGAND GATED) CHANNELS
• VOLTAGE GATED CHANNELS
• ELECTROPHYSIOLOGICAL PRINCIPLES

16
IONOTROPIC CHANNELS

• BIND NEUROTRANSMITTER
• OPEN CHANNEL
• HYPER OR DE-POLARIZATION

17
THE SYNAPSENEUROTRANSMITTER BINDS TO
POSTSYNAPTIC RECEPTOR
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES







ION CHANNEL


ENZYME
18
HOW ARE WE WIRED?CONNECTIONS BETWEEN NERVE CELLS
AXON
CELL BODY
AXON TERMINALS
AXON HILLOCK
DENDRITES
19
POSTSYNAPTIC POTENTIALS
EPSP
RESTING POTENTIAL
TIME
20
SPATIAL SUMMATION
SIMULTANEOUS INPUT FROM TWO SYNAPSES
ABOVE THRESHOLD
THRESHOLD
TIME
21
SPATIAL SUMMATION
SIMULTANEOUS INPUT FROM TWO SYNAPSES
ABOVE THRESHOLD
THRESHOLD
TIME
22
TEMPORAL SUMMATION
TOO FAR APART IN TIME NO SUMMATION
TIME
23
TEMPORAL SUMMATION
CLOSER IN TIME SUMMATION BUT BELOW THRESHOLD
THRESHOLD
TIME
24
THE GOLDMAN-HODGKIN-KATZ (GHK) EQUATION
Ko ?Nao Vm 60 LOG
-------------------------- Ki ?Nai
? IS THE RATIO OF SODIUM TO POTASSIUM
PERMEABILITY
25
TEMPORAL SUMMATION
STILL CLOSER IN TIME ABOVE THRESHOLD
THRESHOLD
TIME
26
EPSP-IPSP CANCELLATION
27
HOW EXCITATION OCCURS-THE ROLE OF DEPOLARIZATION
AND HYPERPOLARIZATION

• SUMMATION CAN DEPOLARIZE THE CELL BEYOND
  THRESHOLD
• HYPERPOLARIZATION BLOCKS

28
(No Transcript)
29
NEURO TRANSMITTERS

• ACETYL CHOLINE
• DOPAMINE
• NOREPINEPHRINE
• EPINEPHRINE
• SEROTONIN

• HISTAMINE
• GLYCINE
• GLUTAMINE
• GAMMA-AMINOBUTYRIC ACID (GABA)

30
IN THE SPACE

• ENZYME CHEWS UP LIGAND
• MASS ACTION CAUSES LIGAND TO DISSOCIATE FROM
  RECEPTOR

31
THE SYNAPSE
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES




ION CHANNEL




ENZYME
32
THE SYNAPSE
CALCIUM CHANNEL

RECEPTOR
SYNAPTIC VESSICLES





ION CHANNEL



ENZYME
