Modern Physics Lecture IX

1
Modern PhysicsLecture IX
2
The Quantum Hypothesis

• In this lecture we examine the evidence for
  light quanta and the implications of their
  existence
• Waves as Particles
• The photoelectric effect
• Compton scattering
• Particles as Waves
• Electron diffraction
• The Double Slit Revisited

3
Photoelectric effect

• When light strikes the cathode, electrons are
  emitted
• Electrons moving between the two plates
  constitute a current

4
Photoelectric Effect

• Properties of the photoelectric effect
• Electrons are only emitted above a certain
  cut-off frequency
• This frequency is different for different
  materials
• It is called the work function
• Below the work function no electrons are
  emitted no matter how intense the light is
• The maximum energy of the ejected electron is
  KmaxeDVs

5
Photoelectric Effect

• Properties
• No photoelectrons are emitted if the frequency
  falls below some cut-off frequency fc
• The maximum energy of the photons is independent
  of the light intensity
• The maximum kinetic energy of the photoelectrons
  increases with increasing frequency
• Photoelectrons are emitted almost instantaneously
  from the surface

6
Photoelectric Effect

• Explanation
• Einstein extended Plancks explanation for
  blackbody radiation to suggest that in fact the
  quanta of energy used in blackbody radiation are
  in fact localised particle like energy packets
• Each having an energy given by hf
• Emitted electrons will have an energy given by
• Where f is known as the work function of the
  material

7
Photoelectric Effect

• Quantum interpretation
• If the energy of a photon is less than the work
  function f, the photon cannot give enough energy
  to the electron to leave the surface
• Kmax does not depend on light intensity, because
  doubling the number of photons would only double
  the number of electrons and not double their
  energy
• Kmax increases with frequency because energy and
  frequency are related
• If light is particle-like, then all of the energy
  will be delivered instantaneously thus liberating
  an electron with no time delay between the light
  hitting the surface and the electron escaping

8
Inverse photoelectric effect - Production of
X-rays

1. Photons are absorbed in whole - electrons can
   transfer part of their energy.
2. Brehmsstrahlung - electrons decelerate in
   electromagnetic field of nuclei Ef Ei - h ?,
   wide distribution
3. Maximal frequency - minimal wavelength (observed
   empirically first) eV h ?max h c / ?min
4. Also discrete spectrum (atomic levels)

9
Roentgen Lamp
Tungsten - wolfram
10
Compton Scattering

• If light is like a particle does it have
  momentum?
• In Compton scattering x-rays impart momentum to
  matter, scattering electrons like billiard balls
• Thus photons also have momentum. The momentum of
  a photon is given by

Recoiling electron
f
q
Incident Photon, l0
Scattered Photon, l
11
Photons and Electromagnetic Waves

• How can light be considered a photon (particle)
  when we know it is a wave
• Light has a dual nature it exhibits both wave
  and particle characteristics
• There is a smooth transition of these properties
  across the electromagnetic spectrum
• At low frequencies (radio waves) photons have a
  vanishingly small energy and the wave properties
  dominate
• At high frequencies (x-rays, g-rays) it is the
  particle properties that dominate
• But

12
Louis de Broglie1892 - 1987
13
Wave Properties of Matter

• In 1923 Louis de Broglie postulated that perhaps
  matter exhibits the same duality that light
  exhibits
• Perhaps all matter has both characteristics as
  well
• Previously we saw that, for photons,

• Which says that the wavelength of light is
  related to its momentum
• Making the same comparison for matter we find

14
de Broglie Wavelength of Electrons

• We now calculate the wavelength of a charged
  particle accelerated through potential V
• Assume that the particles have mass m and charge
  q
• Equate kinetic energy of the particles with the
  electrostatic energy
• K m v 2/2 q V
• momentum p m v
• We can express kinetic energy in terms of
  momentum
• K p 2/(2 m) q V
• Reorganise to get
• p (2 m q V )1/2
• de Broglies hypothesis gives
• l h / p
• Substitute for p to get

15
Does Matter Really Have a Wavelength

• The wavelength of matter waves is very small.
  This is why we do not see them in our every day
  experience
• To see diffraction a grating a very small slit
  width is required (eg the space between two atoms
  in a crystal)
• This is exactly how electron diffraction was
  first found!
• G. P. Thompson of Scotland and Davisson and
  Germer from the USA used the close spacing
  between atoms in a crystal lattice to diffract
  electron waves thus proving that matter can also
  exhibit diffraction and interference

16
Sir Joseph John (JJ) Thomson
17
C.J.Davisson and L.G.Germer
dNi0.215nm
diffraction
de Broglie
18
Example of Measuring the Lattice Spacing

• Consider an electron accelerated to V 50 V
  scattered through angle q. Note that 2 f q
  180, i.e. f 90-q /2

Figs. from R. Eisberg R. Resnick Quantum Physics

• The condition for constructive interference is
• 2 d sinf n l n integer

19
Example

• Electron scattering in nickel
• Electrons are accelerated through V 54V.
• The maximum of scattering is found to be at f
  65 (q 50 )
• Calculate the lattice spacing for nickel
• 2 d n l / sinf
• Verify that d 0.092 nm

20
Electron interference
a, b, c computer simulation d - experiment
21
Electron Microscope
22
Electron Waves

• Electrons with 20ev energy, have a wavelength of
  about 0.27 nm
• This is around the same size as the average
  spacing of atoms in a crystal lattice
• These atoms will therefore form a diffraction
  grating for electron waves
• Several pictures are shown left (see the web
  links on the course home page)

http//www.chem.qmw.ac.uk/surfaces/scc/scat6_2.htm
23
from this lecture

• The solution to the blackbody spectrum leads to
  the concept of photons, and to a solution for the
  photoelectric effect
• The maximum excess energy of a photoelectron is
• The particle nature of light is also shown by
  Compton scattering of electrons by photons
• Scattering shows that photons have momentum given
  by
• This implies that matter also has wavelike
  properties given by the de Broglie formula
• The de Broglie wavelength leads to phenomena such
  as electron diffraction. A common tool in modern
  crystallography
