CH 7. Cell Suspension Culture

1
CH 7. Cell Suspension Culture
2
7- 1. Introduction
Tissue or Organ Culture Callus Culture
Cell Culture Protoplast Culture
Suspension Cell Culture Single Cell Clones
3
Suspension Cell Culture

• Rapidly dividing
• Homogenous cells or cell aggregates
• Suspended in a liquid medium
• Cultured to produce a cell line?

Single Cell Clones
Cell lines established from single cell origin.
4
Suspension Cell Culture
Cell culture
Embryogenic cells
5
7- 2. Techniques of cell culture
7 - 2 - 1. Initiation of cell suspension culture
 Fragments of undifferentiated callus 2 - 3 g
/ 100 mL   ? Liquid
medium ? ?
? ?
Subculture ? ?
?   Suspension cell cultures
aeration --------
agitation --------
screen small size clumps
6
7- 2- 2. Small batch culture
  Culture volume in a small fixed
volume
lt 100mL
7
7- 2- 2. Small batch culture
Gaseous exchange   Moving
The Steward apparatus
tumble tube
nipple flask
8
(No Transcript)
9
7- 2- 2. Small batch culture
Plateform shaker   speed   stroke range
Orbital shaker
30-150 rpm
3/4 - 3/2 in.
10
7- 2- 2. Small batch culture
  Measuring of cell growth
FW
DW
Cell No.
Packed Cell Volume (PCV)
11
mL cells / mL medium
12
7- 2- 3. Single cell clones
Bergmann (1960), Nicotiana tabacum, Phaseolus
vulgaris, Single cell isolated from plant
tissue materials ?

suspension cell cultures
sieve cells to obtain true single cell ?
plating culture
?   single cell clones
13
plating culture
single cells suspended in agar medium
layer, ca. 1mm thick   observe the cell
growth with inverted microscope,
count the plating efficiency   No. of
colony formed / No. of cells plated
14
plating culture
15
plating culture
16
7- 3. Growth patterns in suspension cell culture
Sigmoidal (S) growth Lag phase --
Logarithmic (log, exponential) -- Stationary
phase
Stationary
Progressive deceleration
FW, DW,
Linear
Log
Lag
Exponential
17
(No Transcript)
18
Factors affect the growth cycle
1. Interval of subculture   Subculture at
stationary phase --gt
Long lag phase
19
  1. Interval of subculture Subculture
at log phase --gt
20
Factors
2. Initial cell density High initial cell
density --gt
Low initial cell density --gt
short lag phase few cell
division
long lag phase long exponential growth
21
Factors
2. Initial cell density
  Critical initial density --gt
In general, 0.5 2.5 X 105 cells / mL
4 6 division 1 4 X 106 cells / mL
22
3. Cell growth rate
23
7 - 4. Synchronous culture

• Cold treatment temperature shocks at 4? for few
  days.
• Starvation method
• Deprivation of an essential growth compound from
  suspension culture leads to a stationary growth
  phase.
• Resupplying the missing compound or subculturing
  to a fresh complete medium will allow growth to
  resume and may result in synchronization of cell
  growth.

24

• 3. Use of inhibitors
• Cell synchrony at G1/S stage used below
• 5-fluorodeoxyuridine (FudR)
• Excess thymidine
• Hydroxyurea (HU)
• 4. Colchicine method
• One of most effective spindle fiber inhibitors.
• Suspension cultures in exponential growth are
  supplemented with 0.02 (w/v) colchicine.

25
7 - 5. Characteristics of plant cell lines
1. A high degree of cell separation,
small size of cell clumps 2. Homogeneous cell
morphology 3. Distinct nuclei and dense
cytoplasm 4. Formation of starch granules 5.
Relatively few tracheal elements
26
7 - 5. Characteristics of plant cell lines
6. Doubling time of 24-72 hr., superior
growth rate than that of callus 7. Loss of
totipotency 8. Hormone habituation 9. Increased
ploidy levels 10. Low resistance to shear
stress 11. Contamination during long term culture
27
5 - 6. Applications of plant cell culture
Suspension culture
