Load Balancing in Structured P2P Systems (DHTs)

1
Load Balancing in Structured P2P Systems (DHTs)

• Sonesh Surana
• sonesh_at_cs.berkeley.edu
• Brighten Godfrey, Karthik Lakshminarayanan,
• Ananth Rao, Ion Stoica, Richard Karp

2
Definitions, Goal, Assumptions

• Definitons
• Load could be storage, bandwidth, etc.
• Target the load a node is willing to take (ex.
  capacity, avg. util. slack)
• Goal
• To maintain the system in a state where load on a
  node is below its target
• Assumptions
• Nodes are cooperative
• Only one bottlenecked resource

3
Motivation for Load Balancing in DHTs

• In DHTs, item identifiers determine which node
  items are mapped to
• Items and nodes are assigned Ids randomly
• This can cause a log(N) imbalance in the number
  of items at a node
• Aggravating problems
• Sizes of items may not be the same
• Some applications want to choose identifiers
  themselves, not randomly (ex. Database
  applications)
• Nodes themselves might have heteregeneous
  capacities

4
Virtual Servers

• A virtual server is a contiguous region of the Id
  space

5
Virtual Servers

• A virtual server is a contiguous region of the Id
  space
• Each node can be responsible for many virtual
  servers

Node A
Node B
Node C
6
Static Mapping of Virtual Servers

• Imbalance Give each node log(N) virtual servers.
  This causes constant factor imbalance
• Heterogeneity Each node has number of virtual
  servers proportional to its target

Node A
T50
Node B
T35
Heavy
Node C
T15
Chord Ring
7
Dynamic Re-Mapping of Virtual Servers
Allow dynamic re-mapping of load in a
system. Virtual server is the basic unit of load
movement.
11
20
Node A
T50
15
3
Node B
T35
Heavy
Node C
10
20
T15
Chord Ring
8
Dynamic Re-Mapping of Virtual Servers

• Allow dynamic re-mapping of load in a system.
• Virtual server is the basic unit of load movement.

11
20
Node A
T50
15
3
Node B
T35
Node C
10
30
T15
Chord Ring
9
Dynamic Re-mapping of Virtual Servers

• Advantages
• Flexibility in being able to move load from any
• node to any other node, not just to neighbour
• Easily supported by the underlying DHT because
  movement of virtual server appears as join and
  leave to the DHT

10
Load Balancing Scheme 2 Actions

• Take periodic action
• Try to bring the nodes below target to bring the
  system in a good state
• Take emergency action
• If the arrival of an item causes a node to go
  over capacity, then seek help immediately
• Analogy Go to hospital for regular checkups but
  rush to the hospital if youve fractured an arm

11
Load Balancing Scheme - Directories

• Directory Nodes
• All nodes, heavy or light, periodically report
  information to directories. Soft State
• Directories periodically compute the transfer
  schedule and report it back to the nodes, which
  then do the actual transfer.

12
Basic Load Balancing Computation

• Unload
• Insert

13
Unload
Pool
T6, L7
T6, L5
2
5
A
A
T20, L17
7
6
4
B
T24, L25
T24, L22
10
8
4
3
C
14
Insert
Pool
T6, L5
5
2
A
3
T20, L17
T20, L20
7
6
4
B
T24, L22
T24, L24
10
8
4
C
15
Emergency

• If an item comes that will make node overloaded
  (emergency), node asks help from its directory
• Only this node unloads
• Inserts happen as before, however we make sure
  the accepting node does not become heavy
• If not solved by this directory, tries offloading
  remaining offending virtual servers in another
  directory.

16
Dynamicity in P2P

• Object Churn Rate
• Objects are inserted into and deleted from the
  P2P system
• Load Impulses
• Sudden popularity
• Object ids might not be hashed
• Node Churn Rate
• Nodes might come and go
• We assume there are external methods to make sure
  nodes leaving does not cause loss of data objects
• Replication

17
Evaluation

• Static vs Dynamic mapping ?
• How well we do under impulses ?
• How well we do when nodes enter and leave the
  system ?
• How much load is moved around due to load
  balancing ?

18
Evaluation

• Static vs Dynamic mapping ?
• How well we do under impulses ?
• How well we do when nodes enter and leave the
  system ?
• How much load is moved around due to load
  balancing ?

19
Simulation Setup

• 4096 nodes in the system
• 16 directories
• 12 virtual servers per node
• Steady state 100,000 data items
• Load Balancing frequency is 1 minute
• Distributions
• Node capacities Pareto
• Item Sizes Uniform
• Arrival and Departure process for items Poisson.
  We look at steady state. Arrival Rate 100
  items/sec
• At the moment, everything is synchronized

20
Static Mapping vs. Dynamic Re-Mapping
21
Impulse
22
Future Work

• Investigate what happens with different
  distributions for item size and item id
  distributions
• zipf, bi-modal, traces
• Finally, implement on chord

23
Conclusion

• Plain hashing and static mapping of virtual
  servers may not be enough
• Dynamic re-mapping. Flexible and easily supported
  by DHT
• P2P systems are dynamic bursts happen
• So do emergency in addition to periodic

24
Questions?Feedback
