Application of Hip Arthroscopy

1
Application of Hip Arthroscopy

• Nadhaporn Saengpetch, MD.

2
Objectives

• To understand the spectrum of disease that is
  compatibly treated with hip arthroscopy
• Have a basic understanding of the relevant
  anatomy , history and examination for hip pain
• To introduce the surgical technique and its
  limitation

3
Once upon a time.

• 1802 Dr. Phillipp Bozzini Lichtleiter
• 1931 Dr. Micheal S. Burman
• 20 cadaveric hip joints

4
First Clinical Application 1939

• Dr. Kenji Takagi
• 2 Charcot joints
• 1 Tbc arthritis
• 1 Supparative
• arthritis

J Jpn Orthop Assoc 1939
5
Anatomy
6
Hip Arthrogram
7
Tip of Physical Exams

• Differential diagnosis to intra/extra-articular
  pain, pubic pain
• One joint above and below
• Gait LLD, pelvic obliquity
• foot-progression angle muscle contraction

8
Impingement Sign
9
Tip of Physical Exams

• Intra-articular lesion log rolling, McCarthy
  hip extension sign
• SI problem FABER test
• Hip flexion contracture Thomas test
• Piriformis syndrome sit active ER
• Hip dysplasia anterior apprehension test (
  extend ER)

10
FABER Test
11
Differential Diagnosis of Groin Pain
4 zones of groin pain
12
Differential Diagnosis of Groin Pain
13
Osteitis Pubis Soccer Player
14
(No Transcript)
15
F 20 yo. w/ hx of posterior dislocation for 4 y.
PTA
16
CT scan
17
3D-CT scan
18
Disorders That May Benefit from Hip Arthroscopy
19
Labral Tears
20
Labral Tears

• Traumatic tears
• posterior hip dislocation
• pain/catching after twisting or slipping
• repetitive hyperflexion

21
Labral Tears

• N. America 436 hips, 96 were anterior lesion
  (twist, pivot)
• McCarthy JC. JBJS Am May 2005

Asian hips were most postero-superior lesion
(hyperflex, squat) Ikeda T. JBJS Br June 1988
22
MRI Labral Tears
23
Labral Tears

• Degenerative tears
• OA hip
• relieve mechanical symptom in some pts
• did scope in early OA pts worsen outcome
• (Walton NP. Int Orthop June 2004)

24
Arthroscopic Classification of Hip Labral Tears
Radial flap
Radial fibrillated
Lage LA. Arthroscopy Dec 1996.
Longitudinal
Complex
25
Debridement of Labral Tears
26
Arthroscopic Labral Repair
27
Labral Tears

• Hip dysplasia
• selected patient
• literatures devoid of studies this patient
  population, open acetabular osteotomy remains
  reasonable well-described treatment
• shollow acetabulum subluxate
  distribute abnormal stress from a head on the
  labrum

28
Chondral Lesions

• Lateral impact mechanism ( by GT)
• Associated labral tears 55.3
• (McCarthy JC. Clin Orthop 2001)
• Cartilage stimulation
• ACI
• Future more predictable cartilage-resurfacing
  procedure

29
Chondral Flap Tear and Microfracture
30
Labral Lesion with Chondral Lesion

• Subchondral cyst
• formation
• Synovial fluid
• burrows beneath
• the delaminating
• cartilage and
• subchondral bone

31
Risk Factors of 2º OA from Labral Tears

• With developmental dysplasia
• Tears gt 5 years old
• Full-thickness chondral lesion

32
Ligamentum Teres
33
Ligamentum Teres Rupture

• Deep anterior groin pain
• Mechanical symptoms
• History of significant trauma
• Associated pathology labrum, LB, chondral
  damage
• ? Incidence
• (Byrd JWT. Arthroscopy April 2004)

34
Ligamentum Teres Rupture
35
Snapping Hip(Coxa Sultans Interna)
Iliopsoas bursitis
36
Iliopsoas Tendon Release
37
Iliopsoas Tendon Release
38
Pipkin Fracture
39
Loose Bodies Removal
40
Synovial Abnormalities

• Chondromatosis
• Crystalline disease
• RA/SLE
• Ehler-Danlos
• capsular
• shrinkage

41
Femoral Acetabular Impingement (FAI)

• Leads to OA hip
• anterior head-neck offset or acetabular
  overcoverage

42
Radiographic Workup

• AP view
• Lateral view (Cross-table)
• Lateral view (Dunn, false-profile)

Alpha angle Control 42º FAI pt 74 º
(Notzli HP. JBJS Br March 2002)
43
MRI coronal plain
44
Cam Type

• Caused by shear forces of the non-spherical
  position of the head against the acetabulum
• Anterosuperior cartilage
• Predisposing factors SCFE, abnormal epiphyseal
  extension, malunion neck/head fracture, and
  femoral retroversion

45
Cam Type
46
Pincer Type

• Repetitive stresses of a normal neck against an
  abnormal acetabular rim (over-coverage)
• Antero-superior labrum coup
• Postero-inferior head contre-coup
• Predisposing factors acetabular
  protrusio/retroversion, malunion acetabulum, 2
  from osteotomy

47
Pincer Type
Normal
Cross-over sign
48
Mixed Type

• Combine head/cup
• lesions
• Less isolated type
• (Cam 9, Pincer 5)
• (Beck M. JBJS Br Jan 2005)

49
Chilectomy (Osteochondroplasty)
50
Arthroscopic Osteochondroplasty
51
Arthroscopic Osteochondroplasty
52
Osteonecrosis

• Limited role only in a good spherical head to map
  a chondral lesion
• Procedure before free fibular grafting/core
  decompression
• Reserved for mechanical symptoms

is still debating
53
Other Indications

• Biopsy of lesions
• Synovectomy /
• bursectomy
• Diagnosis of pain
• Septic arthritis
• After THR

54
What is this?
PVNS
55
Contraindication

• Advanced arthritis
• Stiff hip
• Heterotopic ossification
• Severe dysplasia

56

• A surgeon is just a regular doctor,
• with few special skills.
• Dr. B.F. Bryd, Jr.

57
Equipments Set up
Fluoroscope
Fracture table
Well-padded booties
Perineal post
Well trained flu technicians
58
Booties
59
Standard Portals
60
Peroneal Post or Bean Bag?

• Hip arthroscopy without a perineal post a
  safer technique for hip distraction
• Decrease risk of pudendal nerve palsy
• Deflated beanbag contoured around the flank and
  thorax
• (Merrell G. Arthroscopy Jan 2007 23(1)10)7)

61
Traction Time

• Not more than 1-2 hrs
• The lesser time, the lower complication
• HA without traction
• peripheral lesions
• younger age pts

62
Approach Techniques

• Supine

Lateral
63
3 Common Portals

• Anterior portal
• Lateral portals
• - Lateral-anterior portal
• - Lateral-posterior portal

64
Portals
Vulnerable structures



Landmark anterior portal
65
Adequate Distraction
Distracted joint space 7-10 mm.
66
Surgical Instruments
67
Surgical Instruments
Spinal needle
Glick Arthrex Set Extra-long scopes both 30º and
70º
Nitinol wire
Cannulated obturator
68
Common Steps

1. Peripheral area assessment
2. Do the labral or chonral procedures
3. Flex an affected hip 45º, release traction
4. Exam the L. teres lesion or osteo-chondroplasty
   (Chilectomy)
5. Move the leg check adequacy of cartilage/bony
   removal

69
Complications

• 1.4-7
• sciatic and femoral neurapraxia (resolve in 2-3
  d)
• Perineal injury
• Portal bleeding
• Trochanteric bursitis
• Intra-articular instrument breakage

70
Catastrophic Complications

• O.5 permanent
• (Sampson TG. Clin Sports Med 2001)
• Permanent sciatic and femoral nerve damage
• Femoral vascular injury
• Septic arthritis
• Cardiac arrest intra-abdominal extravasation
  of fluid (Acetabular fx)
• (Bartlett CS. J Orthop Trauma Dec 1998)

71
Metallic Stain
72
