Fibonacci Heaps

1
Fibonacci Heaps

• CS 252 Algorithms
• Geetika Tewari 252a-al
• Smith College
• December, 2000

2
My Contribution

• - Understanding Fibonacci Heaps. This involved
  understanding
• - Operations of Creation,
  Union, Insert, Extract-Min, Delete, Decrease Key
• - The circular linked list data
  structure used for the heap
• - Reading about Amortized
  analysis, the Potential Function and Binomial
  heaps
• - The proof which gives the
  name Fibonacci to these heaps
• Understanding an application of Fibonacci Heaps
  in the Shortest Paths problem
• Researching Leda implementations of Fibonacci
  Heaps or other data structures that use these
  heaps
• Implementing Dijkstras Shortest Path algorithm
  in Leda using different priority queues, one of
  which is the Fibonacci Heap
• Experimenting, Recording and Comparing the
  running times of Dijkstra using 6 different LEDA
  priority queues that use 6 different heaps

3
Research Tools and Resources Used

• Books Consulted
• - Algorithms, by Cormen, Leiserson, and Rivest,
  page 420-439. All examples taken from there.
• Data Structures, Algorithms and Program Style, by
  James F. Korsh, page 247-248 provide a good
  explanation of the proof by Induction on how
  Fibonacci Heaps get their name
• Websites Consulted
• Complete Web Tutorial on Fibonacci Heaps
  http//wwwcsif.cs.ucdavis.edu/fletcher/classes/11
  0/lecture_notes/lec17.html
• Example of the implementation of a LEDA Priority
  Queue
• http//www.cs.umbc.edu/zwa/Algorithms/CMSC641.htm
  l
• Online Tutorial and Animation of Fibonacci Heaps
• http//www-cse.uta.edu/holder/courses/cse5311/lec
  tures/l13/node13.html
• Programming Tools
• LEDA Online User Manual
• http//www.cs.bgu.ac.il/cgproj/LEDA/Index.html

4
Programs and Excel Files created that are
submitted for project

• The main program used to run all tests is
• dpq.cpp
• The compilation line used to compile it is in the
  file
• dpq_compile
• A typescript is included to show how the program
  runs and expects user interaction.
• 252a-al_typescript
• A bash shell file runs all the dpq.cpp tests many
  times so that average time can be collected
• rundijtests
• An input data file is also provided called
• data_dij

5
Outline

• Introduction What is a Fibonacci Heap?
• - Why Fibonacci Heap, proof of
  D(n), some definitions
• 2. Fibonacci Heap operations, with step by step
  focus on
• Insertion
• Extract-Minimum Node
• Decrease-Key
• 3. Comparison of Running Times with other Heaps
• 4. Application to Shortest Path Problem
• 5. Experiments
• LEDA Dijkstra Performance using different
  priority queues based on different heaps
• Graphical Results
• Comparison of running times
• 6. Concluding Remarks

6
What is a Fibonacci Heap? data structure
advantages of removal concatenation
- Heap ordered Trees
root list of Fibonacci Heap
Minimum node
- Rooted, but unordered
- Children of a node are linked together in a
Circular, doubly linked List, E.g node 52
child list of node 52
Node Pointers - left x -
right x - degree x - number of
children in the child list of x -
- mark x
7
Properties of Binomial Heaps relevant for the
understanding of Fibonacci Heaps
Quick Summary 1. 2k nodes 2. k height of tree
3. (ki) nodes at depth i 4. Unordered binomial
tree Uk has root with degree k greater than any
other node. Children are trees U0, U1, .., Uk-1
in some order.
8
What is a Fibonacci Heap?.. (cont.)

• Collection of unordered Binomial Trees.
• Support Mergeable heap operations such as Insert,
  Minimum, Extract Min, and Union in constant time
  O(1)
• Desirable when the number of Extract Min and
  Delete operations are small relative to the
  number of other operations.
• Most asymptotically fastest algorithms for
  computing minimum spanning trees and finding
  single source shortest paths, make use of the
  Fibonacci heaps.

9
Why is it called a Fibonacci Heap? 0 1
1 2 3 5 8 .
1. Lemma If x has degree K in a Fibonacci
heap, then size(x) (nodes rooted at x and x
itself) is at least F(K2), meaning the
Fibonacci number of index k2. Proof Let sk be
the maximum possible value of size(z) over all
nodes z such that degreez k. So s01, s12,
s33.Let y1, y2,yk be the children of x in
the order in which they were linked to x. To
compute the lower bound on size(x), we count one
for x itself and one for the first child y1 (for
which size(y1)gt1) and then apply the Lemma for
the other children- Use this Lemma Let x be
any node in a Fibonacci heap, and suppose that
degreexk. Let y1,y2,,yk be the children of x
in the order in which they were linked to x, from
the earliest to the latest. Then, degreey1gt0
and degreeyigti-2 for i2,3,,k.
10
Proof continued
We thus have Size(x) gt sk gt
2 Sum of(si - 2) from i2.k We can now show by
induction on k that sk gt Fk2 for all
nonnegative integers k. For the Inductive step we
assume, kgt2 and sigtFi2, for i0,1, .,k-1. We
have Sk gt 2 Sum of (si 2) from i2k
gt 2 Sum of (Fi) from i2k gt 1 Sum
of (Fi) from i0Fi Fk2
follows from the Lemma described on previous
slide Hence, Size(x) gt sk gt Fk2
Hence the name Fibonacci Heap arises.
11
An Upper bound on D(n), the maximum degree of a
node, in an n-node Fibonacci Heap
2. Corollary For n-node Fibonacci Heap, D(n)
(the maximum degree of a node) is largest if all
nodes are in one tree. Recall Binomial tree
properties The maximum degree is at depth1,
(k1) k nodes at depth 1 for tree with 2k nodes.
If n 2k, then k lg n D(n) lt k lg n D(n)
O(lg n)
12
Amortized analysis . a quick definition
The complexity analysis of Fibonacci Heaps
is heavily dependent upon the potential method
of amortized analysis

• The time required to perform a sequence of data
  structure operations is averaged over all the
  operations performed.
• Can be used to show that average cost of an
  operation is small, if you average over a
  sequence of operations, even though a single
  operation might be expensive

13
Fibonacci Heap Operations
1. Make Fibonacci Heap -
Assign NH 0, minH nil
Amortized cost is O(1)
2. Find Min -
Access MinH in O(1) time
3. Uniting 2 Fibonacci Heaps
- Concatenate the root lists of Heap1 and Heap2
- Set the minimum node of the new Heap
- Free the 2 heap objects
- Note No consolidation of trees occurs!
Amortized cost is equal to actual cost of O(1)
14
Insert amortized cost is O(1)- Initialize the
structural fields of node x, add it to the root
list of H- Update the pointer to the minimum
node of H, minH- Increment the total number of
nodes in the Heap, nH
Example
15
Insert (continued) Notice - Node 21 has been
inserted - Red Nodes are marked nodes they will
become relevant only in the delete operation
Example
- Note No consolidation of trees occurs!
16
Extract Minimum Node amortized cost is
O(D(n))- make a root out of each of the minimum
nodes children- remove the minimum node from
the root list, min ptr to right(x)- Consolidate
the root list by linking roots of equal degree
and keyx lt keyy, until every root in the
root list has a distinct degree value. (uses
auxiliary array)
Auxiliary Array
Here is a step by step Example
17

• Extract Minimum Node (Example continued)
• Root Nodes are stored in the auxiliary array in
  the index corresponding to their degree
• Hence node 7 is stored in index 3 and node 21
  is stored in index 0

18

• Extract Minimum Node (Example continued)
• Further, node 18 is stored in index 1
• There are no root nodes of index 2, so that
  array entry remains empty
• Now the algorithm iterates through the
  auxiliary array and links roots of equal degree
  such that keyx lt keyy,

Extract Minimum Node (continued) Notice - The
pointer minH is updated to the new minimum
19
Extract Minimum Node (Example continued) - Nodes
21 and 52 are linked so that node 21 has degree
1, and it is then linked to node 18
20
Extract Minimum Node (Example continued) - The
pointers of the auxiliary array are updated -
But there are now no more remaining root nodes of
duplicate degrees
21
Extract Minimum Node (Example continued) -
Extract-Min is now done - The pointer minH is
finally updated to the new minimum
22
Understanding marked nodes (red in previous
slides) essential for understanding Fibonacci
Heap Decrease Key Operation

• A node is marked if
• - At some point it was a root
• - then it was linked to anther node
• - and 1 child of it has been cut
• Newly created nodes are always unmarked
• A node becomes unmarked when ever it becomes the
  child of another node.
• We mark the fields to obtain the desired time
  bounds. This relates to the potential function
  used to analyze the time complexity of Fibonacci
  Heaps.

23
Decrease-Key - amortized cost is O(1)

• Check that new key is not greater than current
  key, then assign new key to x
• - If x is a root or if heap property
  is maintained, no structural changes
• - Else
• -Cut x make x a root, remove
  link from parent y, clear marked field of x
  -Perform a Cascading cut on xs
  parent y(relevant if parent is marked)
• - if unmarked mark
  y, return
• - if marked Cut y,
  recurse on node ys parent - if
  y is a root, return
• The Cascading cut procedure recurses its way up
  the tree until a root, or an unmarked node is
  found
• - Update minH if necessary

24
Decrease-Key - amortized cost is O(1)- We
start with a heap- Suppose we want to decrease
the keys of node 46 to 15
Here is a step by step Example
25
Decrease-Key (example continued)- Since the
new key of node 46 is 15 it violates the min-heap
property, so it is cut and put on the root-
Suppose now we want to decrease the key of node
35 to 5
26
Decrease-Key (example continued)- So node 5
is cut and place on the root list because again
the heap property is violated- But the parent of
node 35, which is node 26, is marked, so we have
to perform a cascading cut
27
Decrease-Key (example continued)- The
cascading cut involves cutting the marked node,
26, unmarking it, and putting it on the root
list- We now repeat this procedure (recurse) on
the marked nodes parent until we hit a node on
the root list
28
Decrease-Key (example continued)- Since the
next node encountered in the cascading cut
procedure is a root node node 7 the procedure
terminates- Now the min heap pointer is updated
29
Delete-Key - amortized cost is O(D(n))
- Call Decease-Key on the node x that needs to
be deleted in H, assigning negative infinity to
it - Call Extract-Min on H
30
Now that we have gone through the operations of
the Fibonacci Heaps, we can do a comparison of
the time taken for these operations with other
heaps

Procedure Binary Heap (worst case) Binomial Heap (worst case) Fibonacci Heap
Make-Heap ?(1) ?(1) ?(1)
Insert ?(lgn) O(lgn) ?(1)
Minimum ?(1) O(lgn) ?(1)
Union ?(n) O(lgn) ?(1)
Decrease-Key ?(lgn) ?(lgn) ?(1)
Extract-Min ?(lgn) ?(lgn) O(lgn)
Delete ?(lgn) ?(lgn) O(lgn)

(Amortized)
For dense graphs which have many edges, the O(1)
amortized call of Decrease-Key adds up to a big
improvement over the ?(lgn) worst case time of
Binomial or Binary Heaps.
31
Applications to Shortest Path Problem
Recall single-source/all nodes shortest path
problem
Find shortest path from node s in graph to every
other node, given non-negative weights on
edges This algorithm runs in O(N2) time if the
storage set for nodes is maintained as a linear
array. For instance, each ExtractMin operation
takes O(N) time and there are N such operations.
32
Instead, implement the priority queue as a
Fibonacci heap!

• Selecting next shortest distance is Extract-Min
  on heap
• Updating distance estimates is Decrease-Key on
  heap
• Total Extract mins O(N log(N))
• Update edges O(E) since each of the E
  Decrease-Key operations takes O(1) amortized time

• Total cost O(N logN E)
• which is good if number of edges is smaller than
  N2, graph is sparse.

33
Experiments using LEDA

• LEDA does not provide the Fibonacci Heap data
  structure in its libraries, so a Fibonacci Heap
  LEDA object cannot be instantiated.

• Priority Queue Implementations based on
  different types of heap structures are available.
  The default implementation uses a Fibonacci Heap.

• The LEDA PQ object provide a good basis for
  testing and analyzing the complexity of some well
  known algorithms, such as ..

Dijkstras Shortest Path Algorithm
34
Implementation Plan - Graph density -
Time function - Accuracy

• Create program dpq.cpp that Implements the LEDA
  provided dijkstra() function with type of
  Priority Queue as a function argument
• Program reads input by LEDAs read_int()
  function
• - n Nodes
• - m Edges
• - max Maximum Cost Edge
• - Type of Priority Queue that
  Dijkstra will use (1-6 where 1 is Fibonacci Heap)
• Run the program on graphs of density 1000-128000
  (n) nodes and 3n edges(multiples of 2)
• - Write a bash file to run tests overnight
• Record the program running times using Ledas
  used_time() function. Repeat 10 times to get an
  average running times
• Plot the running times against the graph density
  for each Priority Queue
• Use Logarithmic Scale to better visualize the
  results

35
Results and Analysis
Table Displaying the average time complexity of
Dijkstra on random graphs of different density
using 6 different LEDA Priority Queue
Implementations.
36
Graph of Results
List PQ dominates! delete_min and find_min O(n)
37
Graph of Results - Logarithmic Scale
Fibonacci Heap . PQ
38
Asymptotic Running Times of Dijkstras Algorithm
with different Priority Queues The best worst
case and average case time is achieved by
Fibonacci Heaps and Pairing Heaps.
Type of Heap Worst Case Running Times Expected Running Time
Fibonacci heap O(m n log n) O(m n log n)
Pairing heap O(m n log n) O(m n log n)
K-ary heap O(m log k n nk log k n) O(m n( log (2m /n) k) log k n)
Binary heap O(m log n n log n) O(m n log(m/n) log n)
List Priority Queue O(m n2) O(m n2)
Bucket heap O((m n)n M) O((m n)n M)
Redistribute Heap O(m n log M) O(m n log M)
Monotone Heaps O(m max_dist M) O(m max_dist M)
(source Leda Manual)
39
Concluding Remarks
- Fibonacci Heaps are mostly of theoretical
interest, but are quite tedious to implement.
If a much simpler data structure with the same
amortized time bounds as Fibonacci Heaps were
developed, it would be of great practical use as
well.
- However, some source code is available, so
borrow. http//www.boost.org/libs/pri_queue/f_
heap.html
